  • Page 1 USB-RS232-TTL-STICK Hardware-Description 2012 November...
  • Page 2: Table Of Contents

    INDEX 1. Introduction 1.1. General remarks 1.2. Customer satisfaction 1.3. Customer response 2. Hardware description 2.1. Technical data 2.2. 3pin connection cable 2.3. LED's 3. Software 3.1. “VCP Driver (Virtual COM-Port)” Installation 4. Appendix 4.1. Revisions 4.2. Copyrights and trademarks Index | Seite...
  • Page 3: Introduction

    Introduction Introduction | Seite...
  • Page 4: General Remarks

    1.1. General remarks First of all, we would like to congratulate you to the purchase of a high quality DEDITEC product. Our products are being developed by our engineers according to quality requirements of high standard. Already during design and development we take care that our products have -besides quality- a long availability and an optimal flexibility.
  • Page 5: Hardware Description

    Hardware description Hardware description | Seite...
  • Page 6 2. Hardware description This USB to RS-232 converter (TTL-Level) is suitable for e.g. debugging on microcontroller circuits. Also your processor board will be protected by galvanic isolation. This little USB-Stick transmits serial data with TTL-Level (e.g. debugging informations) on the USB port. Normally there are only TTL-Signals available on serial ports by processors.
  • Page 7: Technical Data

    2.1. Technical data +5V power supply (USB-BUS) USB to RS-232 (TTL-Level) A LED for TX and RX Galvanically isolated 50 Baud ..3MBaud (configurable per software) Windows VCP (Virtual COM Port) Linux Driver inclusive Dimensions: 84,5 x 21 x 12,5/9,5 mm (without cable) Hardware description | Seite...
  • Page 8: 3Pin Connection Cable

    2.2. 3pin connection cable The connection to the stick on the RS-232 side will be made by a 3pin connection cable. The ends of the wires are labeled with "RX", "TX" and "GND". RS-232 Pin Assignment Brown White Green 2.3. LED's Two LED’s visualisation of transmit and receivedata.
  • Page 9: Software

    Software Software | Seite...
  • Page 10: Vcp Driver (Virtual Com-Port)" Installation

    3. Software 3.1. “VCP Driver (Virtual COM-Port)” Installation Insert the DEDITEC driver CD in your CD drive and start “vcp_driver_install. exe”. The “VCP driver (Virtual COM-Port)” software is also available at http:// www.deditec.de/en/entwicklungstools/download.html. Software | Seite...
  • Page 11 Press “Install”. Software | Seite...
  • Page 12 The driver will be installed. The “VCP Driver (Virtual COM-Port)” Software has been installed now. Press “Close” to finish installation. Software | Seite...
  • Page 13: Appendix

    Appendix Appendix | Seite...
  • Page 14: Revisions

    4. Appendix 4.1. Revisions Rev 1.00 First issue Rev 2.00 Design change Rev 2.01 Index added Appendix | Seite...
  • Page 15: Copyrights And Trademarks

    4.2. Copyrights and trademarks Linux is registered trade-mark of Linus Torvalds. Windows CE is registered trade-mark of Microsoft Corporation. USB is registered trade-mark of USB Implementers Forum Inc. LabVIEW is registered trade-mark of National Instruments. Intel is registered trade-mark of Intel Corporation AMD is registered trade-mark of Advanced Micro Devices, Inc.
