March 2023
Quick Start Installation Guide
Rev 2.3 En
For detailed instructions, download the full guide at:
Installation Guides and Manuals - Humidex
Quick Start Installation Guide
English
This Guide Covers the Following Models:
(Basement)
(Crawl Space)
DVS-BS
DVS-CS
(BoosterFan)
DVS-BH
DVS-CH
DVS-CR
DVS-HW
DVS-CE
HCS-BSF myHome
HCS-BS
HCS-CS
HCS-BS myHome
HCS-CS myHome
Manufactured by:
ClairiTech Innovations Inc.
1095 Ohio Rd.
Boudreau-Ouest, NB
Canada E4P 6N4
1-888-533-1348
support@clairitech.com
Register Warranty at:
https://clairitech.com/en/support/register
READ AND SAVE THESE INSTRUCTIONS
Advertisement
Table of Contents
Related Manuals for ClairiTech Innovations DVS-BS
Summary of Contents for ClairiTech Innovations DVS-BS
- Page 1 DVS-BS DVS-CS (BoosterFan) DVS-BH DVS-CH DVS-CR DVS-HW DVS-CE HCS-BSF myHome HCS-BS HCS-CS HCS-BS myHome HCS-CS myHome Manufactured by: ClairiTech Innovations Inc. 1095 Ohio Rd. Boudreau-Ouest, NB Canada E4P 6N4 1-888-533-1348 support@clairitech.com Register Warranty at: https://clairitech.com/en/support/register READ AND SAVE THESE INSTRUCTIONS...
-
Page 2: Combustion Appliance Present In Dwelling
Quick Start Installation Introduction Congratulations on the purchase of your new system which will provide you with year-round moisture control and improved air quality for a healthy fresh and drier indoor environment. Please take note the following safety information: CAUTION For general ventilating use only. Do not use to exhaust hazardous or explosive material and vapours WARNING!! To reduce the risk of fire, electric shock, or injury to persons, observe the following: Installation work and electrical wiring must be done by qualified person(s) in accordance... -
Page 3: Consumer Limited Warranty
Service and Warranty Consumer Limited Warranty ClairiTech Innovations Inc. warrants to the first consumer that this product, when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its discretion, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for the period(s) set forth below. -
Page 4: Pre-Installation
Quick Start Installation Pre-Installation Tools Required for Installation Electric reciprocal or hole saw 6¼” Drill with a ¼” concrete bit Phillips or Robinson Screw Driver Measuring Tape Hammer Pencil Key Installation Facts 1) Unit must be installed at floor level – up to 3” off the floor. 2) Unit should be installed as far away as possible from the source of replenishment air. -
Page 5: Replenishment Air To Basement From Upstairs
Quick Start Installation Installation Replenishment air to Basement from Upstairs The damp air exhausted by the system must be replaced by the warmer/drier air from the upper levels. If there is no open stairwell, the airflow is restricted from coming down, then install a passive return grille with 100 sq. - Page 6 Quick Start Installation Ducting The basement models come in two sections that allow for flexibility in positioning the duct at the most convenient height. For both models you can duct from the back of the unit, or from the top of the unit by removing the top cover.
-
Page 7: Preparing The System For Installation
Quick Start Installation Preparing the System for Installation Now that an installation location has been chosen a hole must be made for the vent. Start by measuring the required Unit height and mark the location of the hole. Remember that the units cannot be higher than 3” off the ground. From the inside, drill a pilot hole of approximately ¼”... - Page 8 Quick Start Installation Fasten the unit to the wall With the help of a tie wrap attach the flex pipe to the collar on the back of the unit before attaching the unit to the wall. Insert the other end of the flex pipe inside the hole in the wall.
-
Page 9: Typical Installation Diagram
Quick Start Installation Installation BoosterFan 1. To minimize noise propagation, install at least 6 ft. of 6 in. insulated flex between the universal duct boot (connected to the floor register) and the Booster Fan. 2. To further decrease noise propagation, 6 ft. of insulated flex can be used on the exhaust side of the unit. - Page 10 Quick Start Installation Installing and Wiring the Booster Fan To allow the booster fan to draw air from the upper levels, a universal boot must be installed. First locate a safe place to cut out a hole to fit the universal boot. Once a safe and adequate area had been found, proceed by cutting the hole. With the hole cut, install the universal boot which will allow the unit to pull the air down.
- Page 11 Failure to comply could see your request denied. Fees Unless the product is defective or the return is a direct result of a Clairitech Innovations Inc., the refund or credit does not include any shipping and handling charges shown on your packing slip or invoice;...
- Page 12 Any product returned to Clairitech Innovations Inc. without the prior approval of Clairitech Innovations Inc. will be considered an unauthorized return; the customer will not receive any credit or refund for the product and Clairitech Innovations Inc. will not return the product to the customer.
