Commercial Refrigerators and Freezers
Undercounter Refrigerators and Freezers
178AU27FHC, 178AU27RHC, 178AU48FHC, 178AU48RHC,
178AU60FHC, 178AU60RHC, 178AU72RHC
Worktop Refrigerators and Freezers with Backsplash
178AWT27FHC, 178AWT27RHC, 178AWT48FHC, 178AWT48RHC,
178AWT60FHC, 178AWT60RHC, 178AWT72RHC
www.AvantcoRefrigeration.com
User Manual
User Manual
01/2023
1
Advertisement
Table of Contents
Related Manuals for Avantco 178AU27FHC
Summary of Contents for Avantco 178AU27FHC
- Page 1 User Manual User Manual Commercial Refrigerators and Freezers Undercounter Refrigerators and Freezers 178AU27FHC, 178AU27RHC, 178AU48FHC, 178AU48RHC, 178AU60FHC, 178AU60RHC, 178AU72RHC Worktop Refrigerators and Freezers with Backsplash 178AWT27FHC, 178AWT27RHC, 178AWT48FHC, 178AWT48RHC, 178AWT60FHC, 178AWT60RHC, 178AWT72RHC 01/2023 www.AvantcoRefrigeration.com...
-
Page 2: Table Of Contents
User Manual Please read the manual thoroughly prior to equipment set-up, operation, and maintenance. NOTE: Save these instructions for future reference. Contents Warning ....................3 Installation ..................4 Safety / Warning ................. 7 Operation / Maintenance ..............8 Troubleshooting .................. 9 www.AvantcoRefrigeration.com... -
Page 3: Warning
User Manual Warning DANGER – RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT USED. TO BE REPAIRED ONLY BY TRAINED SERVICE PERSONNEL. DO NOT PUNCTURE REFRIGERANT TUBING. PELIGRO - RIESGO DE INCENDIO O EXPLOSION. REFRIGERANTE INFLAMABLE UTILIZADO. PARA SER REPARADO SOLAMENTE POR PERSONAL DE SERVICIO CALIFICADO. NO PINCHAR LA TUBERÍA REFRIGERANTE. -
Page 4: Installation
User Manual Installation Please read this manual thoroughly prior to equipment set-up, operation, and maintenance. This unit is intended for use in a temperature-controlled environment less than 75 degrees Fahrenheit and 60% relative humidity. Malfunction due to improper conditions is not covered under warranty. IMPORTANT!!! PLEASE READ BEFORE INSTALLATION: •... - Page 5 User Manual • Select a location away from heat and moisture-generating equipment. a. Ambient temperatures above 75 degrees Fahrenheit may cause the compressor to malfunction. b. The unit should not be used in areas over 90 degrees Fahrenheit. c. Malfunction due to ambient temperatures above 75 degrees Fahrenheit will void warranty. d.
- Page 6 User Manual Adjusting the temperature changes the minimum temperature your unit will run at. Your unit will not run constantly at this setting. To change it, follow these instructions: Digital Control Units • Hold “SET” for 1 sec. The display will flash the current minimum temperature. •...
-
Page 7: Safety / Warning
User Manual Defrost System Refrigerator coils are kept below the freezing point (32 degrees Fahrenheit). During compressor downtime, the evaporator fan continues to circulate air through the evaporator coil. This air circulation raises the coil temperature above the freezing point, melting any accumulated frost. Run-off water is drained into the evaporator pan and evaporated. -
Page 8: Operation / Maintenance
User Manual Operation / Maintenance WARNING: DISCONNECT POWER CORD BEFORE CLEANING ANY PARTS OF THE UNIT. NOTE: We strongly recommend that any servicing be performed by an authorized service technician. Loading Product • Make sure there is at least 4” of clearance from the evaporator. •... -
Page 9: Troubleshooting
User Manual A dusty condenser may lead to high energy consumption, less cooling effectiveness, and compressor damage. Condenser Coil Cleaning Instructions: The condenser coil is located at the bottom behind the panel. 1. Disconnect the electrical power from the unit. 2. - Page 10 User Manual Cabinet Temperature is too Warm Thermostat set too warm. Set thermostat to lower temperature. Re-arrange product to allow for proper air flow. Airflow blocked. Make sure there is at least four inches of clearance from evaporator. Excessive amount of warm product placed in Allow adequate time for product to cool down.
