- Page 1 Assembled in the USA USER MANUAL OCTOPUS 3000 100 Niantic Avenue – Suite 100 – Providence, Rhode Island 02907 – USA TEL: 401-273-3300 FAX: 401-273-3328 www.equipex.com e-mail: service@equipex.com 03/30/2023...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed, including the following: 1. Read all the instructions before use. 2. The manufacturer cannot be held responsible for any damage related to non-compliance with safety and installation instructions. 3. -
Page 3: Instructions And Safety Information
INSTRUCTIONS AND SAFETY INFORMATION Technical information Model OCTOPUS 3000 Power 3000W Volts 208/240V/60/1 Control panel 1 dual capacitive touches control panel Product dimensions 24in.W x 16-1/4in.D x 6.7/8in.H (plus 7in.ea.side) Net weight 105 lbs. with accessories Shipping weight 145 lbs. Principals of Induction When the appliance is switched on, as soon as a power level is selected, the electronic circuits produce induced currents into the bottom of the pan or cooking plate which instantly transmits the... - Page 4 HOW TO USE YOUR DEVICE Connect your appliance to a dedicated 208/240v grounded receptacle. The unit must be installed on a dedicated circuit rated not less than 25% over the maximum amperage indicated for that model, in accordance with NEC standards. An electrical plug has been appropriately installed to meet these requirements.
- Page 5 b. PLANCHA MODE (smooth cooking surface): This accessory is recommended for cooking fish, seafood and vegetables i. Your product is equipped with a program specially designed for the use of your cast iron plancha accessory. This program has been developed to heat the plancha to the ideal temperature.
-
Page 6: Control Panel
CONTROL PANEL Control panel Displays Switch on/off your device 1-30 Power level Residual heat (allow to cool) Turn on double plancha mode. 30° - 250° Temperature (Celsius) Choose between power level, tE / Po Temperature or power Mode temperature, grill or levels plancha accessories mode Grill... - Page 7 3. Setting a zone in power level a. Once the product is on press the Mode button until the display shows Po. b. The P indicator light comes on, then use the +/- selection buttons to adjust the power level. c.
- Page 8 POWER LEVEL CORRESPONDS TO A STEP OF 100W Power level Power in watts Power level Power in watts 1600 1700 1800 1900 2000 2100 2200 2300 2400 1000 2500 1100 2600 1200 2700 1300 2800 1400 2900 1500 3000 4. Setting a zone in temperature setting a.
- Page 9 TEMPERATURE CONVERSION C° F° 30° Chocolate Tempering Water Boiling Typical Baking Temperatures Searing 6. Switch off your device a. To turn off your device, press the button again until you hear an audible signal. b. Once off, the display panel will continue to show the residual heat indicator (H) which remains on until the unit the hotplates have cooled down sufficiently.
- Page 10 OPERATING DETAILS SUMMARY Cycling of Mode Touch Press 1 – PLAN = Plancha Press 2 – GR = Griddle Press 3 – Po = Power Press 4 – tE = Temperature (C◦) Temperature (CELSIUS) – “tE” Start: 30C◦ x 1C◦ each touch until 120C◦ Then: +10C◦...
- Page 11 COOKWARE Only use cookware suitable for induction cooking. • Container test Place your cookware on the induction zone in the POWER mode. If the indicator light stays lit, then the cookware is compatible. If the indicator light blinks constantly, then the cookware is not compatible.
-
Page 12: Care And Maintenance
CARE AND MAINTENANCE • Avoid impacts on the vitroceramic glass cook top. The glass is very strong, but it is not unbreakable. • Avoid scraping cookware on the cook top, which could scratch the glass and wear off screen printing on the surface. •... - Page 13 CARE AND MAINTENANCE - CONTINUED • Cleaning your cast iron accessories Cleaning your cast iron grill or plancha accessories is essential to ensure their efficiency and durability. Cleaning the cast iron preserves the quality of the food as well as the performance of your appliance. o Cold cleaning cast iron accessories ▪...
-
Page 14: Troubleshooting
You should inspect all parts on a regular basis to ensure that all are in proper working order. If a part is damaged, have the unit repaired by the manufacturer prior to returning the unit to operation. If you need any further assistance, please email us at service@equipex.com, or call us at 1-800-649-7885 ext. 240. Troubleshooting... - Page 15 EQUIPEX, to affect its reliability. In many cases, the unit or parts requiring service may be replaced with a new or rebuilt unit/part at the discretion of Equipex.
