- Page 1 311-4141100-041 Part no. 機器說明書/NO LOGO/EN(BG+CHOL+UA)/.標準品/ Product name Spec L148*W105mm/模造紙/40頁/80P/黑/騎馬釘 Designer Emily K100 Color...
- Page 2 Multi-Functional Monitoring System Owner’s Manual...
- Page 3 Version 4.0 2021/08 311-4141100-041...
-
Page 4: Table Of Contents
TABLE OF CONTENTS Important Safety Precautions Meter Overview Display Screen Test Strip Letter Indicator Guide Setting The Meter Quality Control Tests Prepare For Blood Tests Perform Blood Tests Blood Glucose Tests Total Cholesterol Tests Uric Acid Tests Review Test Results Data Transfer via Cable Data Transfer via Bluetooth dongle Maintenance... - Page 5 Dear E1 System Owner: Thank you for choosing the E1 Multi-Functional Monitoring System. This manual provides important information to help you to use the system properly. Before you begin, please read the following contents thoroughly and carefully. If you have other questions regarding this product, please contact the local customer service or place of purchase.
-
Page 6: Important Safety Precautions
Important Safety Precautions Please read the following carefully before use: 1. Use this device ONLY for the intended use described in this manual. 2. Do NOT use accessories that are not specified by the manufacturer. 3. Do NOT use the device if it is not working properly or is damaged. 4. - Page 7 13. Before using this device to test blood glucose, total cholesterol, or uric acid, read all instructions thoroughly and practice the test. Carry out all the quality control checks as directed. 14. Blood glucose test strips can be used for the testing of newborns; total cholesterol and uric acid test strips must NOT be used for the testing of newborns.
-
Page 8: Meter Overview
Meter Overview Test Strip Ejector Eject the used test strip by pushing up this button. Display Screen Down Button (▼) Up Button (▲) Test Strip Slot / Strip Port Communication Insert test strip here to turn the meter on for testing. Connect strip port cable for data transfer. -
Page 9: Display Screen
Display Screen Measuring Mode Measurement Unit General (no show) – Date / Time any time of day Low Battery Symbol AC – before meal PC – after meal Total Cholesterol Symbol Auto QC Mode Blood Glucose Symbol QC – control solution test Uric Acid Symbol Face / Low / High Symbol Blood Drop Symbol... -
Page 10: Test Strip
Test results might be inaccurate if the contact bar is not fully inserted into the test strip slot. ● The E1 Multi-Functional Monitoring System should only be used with E1 test strips. Using other test strips with this meter can produce inaccurate results. -
Page 11: Letter Indicator Guide
Letter Indicator Guide Refer to this letter indicator guide when necessary. -
Page 12: Setting The Meter
Setting The Meter Setting your meter to the correct date and time will ensure the accuracy of the test results. Follow the steps below when you first start using the meter. When you change the meter battery or start using the meter again after taking the batteries out for a period of time (ie 3 months), you should check and update the following settings: Entering the Setting Mode (a) - Page 13 7. Setting the reminder alarm Your meter has 4 reminder alarms. The meter will display “On” or “OFF” and “ AL1 ”. If you don’t want to set an alarm, press ▼ to skip this step. Or press ▲ to select “On”, then press ▼. With the HOUR / MINUTE flashing in sequence, press ▲...
-
Page 14: Quality Control Tests
Quality Control Tests When to Perform a Control Solution Test? ● if it is mandatory following the local regulations in your country; ● if you suspect the meter or test strips are not working properly; ● if your test results are not consistent with how you feel, or if you think the results are not accurate;... - Page 15 Important Control Solution Information ● ONLY use TAIDOC’s control solutions with your meter. ● Do not use the control solution beyond the expiration date or 3 months after first opening. Write the opening date on the control solution vial and discard the remaining solution after 3 months.
-
Page 16: Prepare For Blood Tests
Prepare For Blood Tests Before The Test You must calibrate the meter every time you begin to use a new box of total cholesterol / uric acid test strips by setting the meter with the correct code. You need to make sure that the code number displayed on the meter matches the number on the test strip packaging before you proceed to the test. -
Page 17: Perform Blood Tests
Follow the steps listed below before obtaining a blood sample: ● Wash and dry your hands before you begin; ● Select a puncture site; ● Rub the selected site for about 20 seconds before penetration; and ● Clean the puncture site using cotton moistened with 70% alcohol and let it air dry. - Page 18 NOTE ● Do NOT press the punctured site against the test strip or try to smear the blood. ● Always apply a blood sample after the test strip is inserted into the meter. ● If you do not apply a blood sample to the test strip within 3 minutes, the meter will automatically turn off.
-
Page 19: Blood Glucose Tests
Blood Glucose Tests The meter provides you with three measuring modes: General (no show), AC and PC. You can switch between each mode by: ● Insert a test strip to turn on the meter. The screen will display “ ”, a flashing “ ”... - Page 20 Result Readings MESSAGE WHAT IT MEANS Result is < 10 mg/dL (0.5 mmol/L) Out of measurement range. Result is between 10 to 69 mg/dL (0.56 to 3.8 mmol/L) Result is between Result is between Result is between 70 to 129 mg/dL 70 to 179 mg/dL 70 to 119 mg/dL (3.8 to 7.1 mmol/L)
-
Page 21: Total Cholesterol Tests
Total Cholesterol Tests The meter provides you with one measuring mode: General. ● Insert a test strip to turn on the meter. The screen will display “ ”, a flashing “ ” and “CHOL”. ● After obtaining the first drop of blood, wipe it off. Squeeze again to obtain another drop of whole blood as the sample for the test. - Page 22 Result Readings MESSAGE WHAT IT MEANS Result is < 100 mg/dL (2.5 mmol/L) Out of measurement range. Result is between100 to 400 mg/dL (2.5 to 10.3 mmol/L) Result is > 400 mg/dL (10.3 mmol/L) Out of measurement range. Please consult your doctor to determine a target range that works best for you.
-
Page 23: Uric Acid Tests
Uric Acid Tests The meter provides you with one measuring mode: General. ● Insert a test strip to turn on the meter. The screen will display “ ”, a flashing “ ” and “UA”. ● After obtaining the first drop of blood, wipe it off. Squeeze again to obtain another drop of whole blood as the sample for the test. - Page 24 Result Readings MESSAGE WHAT IT MEANS Result is < 3 mg/dL (178 μmol/L) Out of measurement range. Result is between 3 to 20 mg/dL (179 to 1189 μmol/L) Result is > 20 mg/dL (1190 μmol/L) Out of measurement range. Please consult your doctor to determine a target range that works best for you.
-
Page 25: Review Test Results
Review Test Results The meter stores the most recent 1000 test results along with respective dates and times in its memory. To enter memory mode, start with the meter switched off. 1. Press and release ▲. “ ” will appear on the display and the first reading you see is the last test result with the date, time and measuring mode. -
Page 26: Data Transfer Via Cable
Management System to view test results on your personal computer. To learn more about the Health Care Management System or to obtain a strip port cable separately, please contact TAIDOC or place of purchase for assistance. 1. Obtaining the required cable and installing the software To download the Health Care Management System, please visit the TAIDOC’s website: www.taidoc.com. -
Page 27: Data Transfer Via Bluetooth Dongle
Data Transfer via Bluetooth dongle You can transmit your data from the meter to your device via Bluetooth dongle (optional), please refer to your Bluetooth dongle instruction for further information. The ProCheck app is designed to assist you easily monitoring your biochemical parameters level. How to Install and Update the ProCheck App You must connect to the internet to download the app. - Page 28 WARNING ● While the meter is in transfer mode, it will be unable to perform a test. ● Make sure your device supports Bluetooth Smart Technology. Also make sure the Bluetooth setting on your device is turned on and the meter is within the receiving range before transmitting the data. Please find OS version requirement on App Store or Google Play when you download the app.
-
Page 29: Maintenance
Maintenance Meter Cleaning and Disinfecting ● Wipe the meter exterior with soft damp cloth or mild cleaning agent, then dry the device with soft dry cloth. Do NOT use organic solvents to clean the meter. ● Do NOT rinse or immerse in water or other liquids. ●... -
Page 30: Battery
● Keep the strip vial away from children since the cap and the test strip may be a choking hazard. If swallowed, promptly see a doctor for help. For more information, please refer to the test strip insert. Battery Your meter comes with one 1.5V AAA size alkaline battery. Low Battery Signal The meter will display one of the messages below to alert you when the meter power is getting low... - Page 31 NOTE ● Replacing the battery does not affect the test results stored in the meter. ● All battery should be kept away from children. If swallowed, seek medical assistance immediately. ● battery might leak chemicals if left unused for a long time. Remove the battery if you are not going to use the device for an extended period of time (i.e.
-
Page 32: System Troubleshooting
System Troubleshooting If you follow the recommended action but the problem persists, please call your local customer service. Error Messages MESSAGE WHAT IT MEANS WHAT TO DO Replace the battery The battery is too low. immediately. A used test strip is Repeat with a new test strip. - Page 33 Check the code chip is The code chip is not inserted for coding correctly. inserted before testing Make sure the code chip you or the meter does used supports the parameter. not support certain If the problem persists, please parameters. contact the local customer service for help.
- Page 34 3. If the control solution testing result is out of range: POSSIBLE CAUSE WHAT TO DO Read instructions thoroughly and Error in performing the test. repeat the test again. Control solution vial was Shake the control solution thoroughly poorly shaken. and repeat the test again.
-
Page 35: Symbol Information
Symbol Information SYMBOL REFERENT SYMBOL REFERENT Authorized In vitro diagnostic representative medical device in the European Community Consult instructions Manufacturer for use Temperature limit Caution Use-by date Humidity limitation Batch code CE mark Serial number RoHS compliance Catalogue number This device does not belong to household waste and must be returned to a collection point for recycling electric and electronic devices according to local laws. -
Page 36: Specifications
Specifications Model No.: E1 Dimension: 97.8 (L) x 33.5 (W) x 18 (H) mm Weight: 29.8 g (without batteries) Power Source: One 1.5V AAA alkaline battery Display: LCD with backlight Memory: 1000 External Output: Strip Port Cable / Bluetooth Dongle... - Page 37 Measurement Range: Blood Glucose Test: 10 to 800 mg/dL (0.56 to 44.4 mmol/L) Total Cholesterol Test: 100 to 400 mg/dL (2.5 to 10.3 mmol/L) Uric Acid Test: 3 to 20 mg/dL (178 to 1189 μmol/L) Expected service life: 5 years Operating Altitude: Up to 2000m, for indoor use Degree of Pollution: Pollution degree 2 This device has been tested to meet the electrical and safety...
- Page 41 TaiDoc Technology Corporation B1-7F, No.127, Wugong 2nd Rd., Wugu Dist., 24888 New Taipei City, Taiwan For self-testing. www.taidoc.com MedNet EC-REP GmbH Borkstraβe 10, 48163 Mϋnster, Germany 0123 TD-4141...
