- Page 1 INSTALLATION & OPERATION MANUAL REFRIGERATOR · CFDMH 1834 AW CFDMH 1834 AB CFDMH1834AS...
- Page 2 CONTENTS 1 Safety warnings 2 Proper use of the refrigerator 4 Maintenance and care of the refrigerator 5 Trouble shooting...
- Page 3 1 Safety warnings 1.1 Warning Warning risk of fire / flammable materials THIS appliance is intended to be used in household and similar applications such as staff kitchen areas in shops, offices and other working environments; farm houses and by clients in hotels, motels and other residential type environments;...
- Page 4 REFRIGERANT and cyclopentane foaming material used for the appliance are flammable. Therefore, when the appliance is scrapped, it shall be kept away from any fire source and be recovered by a special recovering company with corresponding qualification other than be disposed by combustion, so as to prevent damage to the environment or any other harm.
- Page 5 Meanings of safety warning symbols This is a prohibition symbol. Any incompliance with instructions marked with this symbol may result in damage to the product Prohibition symbol or endanger the personal safety of the user. This is a warning symbol. It is required to operate in strict observance of instructions marked with this symbol;...
- Page 6 1.4 Warnings for using Do not arbitrarily disassemble or reconstruct the refrigerator, nor damage the refrigerant circuit; maintenance of the appliance must be conducted by a specialist Damaged power cord must be replaced by the manufacturer, its maintenance department or related professionals in order to avoid danger.
- Page 7 Do not store beer, beverage or other fluid contained in bottles or enclosed containers in the freezing chamber of the refrigerator; or otherwise the bottles or enclosed containers may crack due to freezing to cause damages. 1.6 Warning for energy Warning for energy 1)Refrigerating appliances might not operate consistently (possibility of defrosting of contents or temperature becoming too warm in the frozen food compartment) when sited for an extended...
- Page 8 2 Proper use of the refrigerator 2.1 Placement Before use, remove all packing materials, including bottom cushions, foam pads and tapes inside of the refrigerator; tear off the protective film on the doors and the refrigerator body. Keep away from heat and avoid direct sunlight. Do not place the freezer in moist or watery places to prevent rust or reduction of insulating effect.
- Page 9 2.2 Leveling feet. (The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor.) 2.3 Changing the light Any replacement or maintenance of the LED lamp s is intended to be made by the manufacturer,its service agent or similar qualified person.
- Page 10 2.6 Levelling door List of tools to be provided by the user plier Hinge Pliers grommet Fastener ring Lower hinge （The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor） 1) Raise the lower door up to the level of the higher door.
- Page 11 2.7 Disassembly of refrigerator door 1.Use a screwdriver to remove one screw fixing the hinge cover, 2.Then remove the plug terminal and take down the hinge cover; 3. Remove 3 screws fixing the upper hinge with the sleeve and take down the door body. Method for disassembly of freezing door: 1.
- Page 12 3 Structure and functions 3.1 Key components (Refrigerating chamber) Door tray Glass shelf Door tray Door tray Glass shelf assembly Frui and vegetable (Freezing chamber) Refrigerator body Upper drawer assembly Bottom drawer (The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor)
- Page 13 Refrigerating chamber The Refrigerating Chamber is suitable for storage of a variety of fruits, vegetables, beverages and other food consumed in the short term. Cooking foods shall not be put in the refrigerating chamber until cooled to room temperature. Foods are recommended to be sealed up before putting into the refrigerator. The glass shelves can be adjusted up or down for a reasonable amount of storage space and easy use.
- Page 14 LED6 The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor.) 1 Key A. Alarm/power off/power on button B. Frozen thermostat button C. Refrigerated thermostat button 2 Display a) When the initial power is up, it is 3 seconds, While the boot bell rings, and then goes into normal operation display.
- Page 15 7) When the freezer frozen humidification paddle is adjusted to the far right, quick-freezing mode close, the freezer fruit and vegetable box can store vegetables, fruits and other items. 8）When the freezer frozen humidification paddle is adjusted to the far left, quick-freezing mode open, the freezer fruit and vegetable box can not store vegetables, fruits and other easy to freeze bad items, storage drinks and other items.
- Page 17 4.3 Glass shelf cleaning Since the shelf and the box gall have the innermost stop, first lift the shelf up, and then pull out outward can be removed, as needed to adjust or clean, 4.4 Box gall bottom roller groove cleaning 1.First pull out the fruit and vegetable box, because the fruit and vegetable box has a stop, it needs to lift be lifted upward before the fruit and vegetable box can be removed.
- Page 18 4.5 Defrosting The refrigerator is made based on the air-cooling principle and thus has automatic defrosting function. Frost formed due to change of season or temperature may also be manually removed by disconnection of the appliance from power supply or by wiping with a dry towel. 4.6 Out of operation Power failure: In case of power failure, even if it is in summer, foods inside the appliance can be kept for several hours;...
- Page 19 5 Trouble shooting You may try to solve the following simple problems by yourself. If them cannot be solved, please contact the after-sales department. Check whether the appliance is connected to power or whether the plug is in well contact . Failed operation Check whether the voltage is too low.
- Page 20 This warranty only applies in the 50 States of the U.S.A., in Puerto Rico, and in Canada. Product features or specifications as described or illustrated are subject to change without notice. All warranties are made by The Crosley Group, Inc. In Canada, your appliance is warranted by Crosley Canada.
