Profile ADAGIO PAC-312 User Manual

ADAGIO SET – Cordless doorbel set
PAC-312 / PAC-314 / PAC-316 / PAC-318
Thank you for purchasing this Profile product. Please
note: It is important that you read this manual before
using the product. And be sure to save this manual for
possible use later.
The cordless doorbell consists of 2 separate
components:
1. Push-button unit (transmitter)
2. Bell unit (receiver)
These items are completely independent of each other
and require no wiring.
When the push-button is pressed in, a signal is sent to
the bell, whereupon the bell is activated. Since it has a
range of up to 100 meters (in open spaces) you can use
the bell virtually anywhere in the house, workshop,
office, set it up in the garden or just carry it with you.

Battery installation

Push-button unit
1. The push-button unit works using 1 x 3v
(CR2032) lithium battery (included).
2. The lithium battery is already installed. Open
the push-button and remove the insulator
strip.
3. Snap the rear side back into position, and the
push-button is ready for use.
To replace the battery:
1. Open up the push-button unit.
2. Remove the metal plate using a screwdriver.
3. Place a 3v battery (CR2032) in the battery
compartment, making sure the positive
terminal (+) is uppermost.
Bell unit
1. Slide the rear cover open.
2. Place 2 AA alkaline batteries into the battery
compartment.
3. The bell unit will produce a two-tone signal,
indicating that it is ready to read a digital code
(see channel selection).
4. Slide the cover firmly back into place; the bell
is now ready for use.

Installation

Push-button unit
Use the two small holes on the
rear of the push-button to mark
the position for securing in
place. Drill small holes and
mount the push-button in
position with screws (self-
tapping 3 x 16mm, included) or
use the double-sided adhesive
tape (included).
Important: If you secure the
push-button onto a metal
upper surface or PVC type of
door (with metal), its maximum range of transmission
will be greatly reduced.
Bell unit
This bell can be used as a portable device - or fixed into
position. On the reverse side, there are two suspension
slots, with which the bell can be hung up using a screw,
and can easily be taken down again. Drill a small hole
and fix a rawlplug in place. Mount the hook (included)
onto the wall using a screw. The bell unit can hung up
safely in this way.

Choice of bell tone

The bell-tone selector button is inside the push-button
unit, below letter "S". Press the button once to hear the
bell tone already set. Press again to hear and select the
next tune.
1. Long Westminster chime 2. Ding-Dong
3. Telephone ring
5. Banjo on my knee
7. It's a small world
Optionally: It is possible to install an extra push-button
by your back door. By applying the procedure given
above, each push-button can produce a different tune.

Channel selection

The unit is supplied with a pre-set radio frequency. If by
chance the bell should sound for no apparent reason,
it's possible that another device nearby is using the same
frequency. To get round this problem, you can change
the frequency of the push-button and bell.
1. remove the cover behind the push-button.
2. To program or change: remove the batteries
from the bell unit for at least 30 seconds to
prime the memory.
3. place the batteries back into position within.
Press the push-button after the two-tone signal
sound (with a second press of the button if
need be) to confirm the new code. Do this
within 1 minute. Don't use any other cordless
products for the next 5 minutes.
4. Test for correct operation.

Volume selection

There is a volume-selector button inside the bell unit.
Slide the button to 'high' (85 dB) or 'low' (82 dB) to set
at the desired bell volume.

Trouble-shooting and tips

Problem: Bell rings, but LEDs fail to light up
Possible cause: - The bell is out-of-range (max.
100m in open spaces)
Possible solution: - Move the bell within range
- Reprogram the channel (see
channel selection)
Problem: Bell does not ring, nor do the LEDs
light up
Possible cause: - Push-button battery is flat
UK - 1
4. Circus theme
6. Twinkle-twinkle
8. Barking dog
