Summary of Contents for Midland XT50 PRO
- Page 1 XT50 PRO up to WALKIE-TALKIE DUAL BAND PMR446/LPD › User’s manual...
-
Page 3: Main Functions
• Recharge jack: micro USB • Weight: 94g • Dimensions: 102x49x30mm • Category: B The manufacturer, with its effort to constantly improve product quality, reser- ves the right to change characteristics and features without prior notice. XT50 PRO user’s manual... -
Page 4: Content Of The Package
! Do not use detergents, alcohol, solvents, or abrasives to clean the equipment. Just use a soft, clean cloth. If the radio is very dirty, slightly dampen the cloth with a mixture of water and a neutral soap. XT50 PRO user’s manual... -
Page 5: Identifying The Parts
TX - Radio in transmission (PTT pressed) DCS/CTCSS - Type of sub-audio tone selected Code of the selected CTCSS or DCS tone (CTCSS: 1-38; DCS: 1-83) 10. PMR - This simbol indicates that the radio is operating on the PMR446 channels XT50 PRO user’s manual... - Page 6 Transceiver XT50 PRO XT50 PRO XT50 PRO user’s manual...
-
Page 7: Installing/Removing The Battery Pack
The supplied battery packs must be recharged before the first use (see the section “Recharge” for more info). Installing/removing the battery pack Remove the belt clip; Open the battery compartment; Remove or insert the battery pack; Close the battery cover and fix the belt clip. XT50 PRO user’s manual... -
Page 8: Let's Communicate
The following functions can be selected by pressing the Menu button: • VOX • Roger Beep on/off • Channel setting • CTCSS/DCS tone setting • Keypad Beep • High/low power selection (PMR band) • Tone selection for the CALL feature XT50 PRO user’s manual... - Page 9 Press once the Menu button and then select the desired channel by the ▲/▼ buttons. Press PTT to confirm the selection. CTCSS tones selection XT50 PRO can receive in two modes: a. Open traffic: in this case you will hear any communication transmitted on the selected channel;...
-
Page 10: Call Function
By pushing ▲/▼ you will hear the 5 pre-set melodies. Confirm by pressing the PTT key or wait for 5 seconds. Now, each time your XT50 PRO sends out a tone call, it will beep with the selected melody. Choosing high or low transmission power (PMR band) Batteries are drained more quickly during transmission. -
Page 11: Monitor Function
Insert the battery pack into the radio. Plug the USB supplied in the package into the USB port of the radio. The icon with its bars will be displayed to indi- cate that the radio is being charged. Once the batteries are fully charged the XT50 PRO user’s manual... -
Page 12: Auto Power Save
This plug is 2-pin type and is compatible with all Midland accessories. Troubleshooting and radio reset XT50 PRO is designed to provide you with years of optimal performance. If for some reason problems arise, refer to this chapter before contacting a service centre in your region. -
Page 13: Technical Specifications
Jack for ext.mike ................stereo 2,5 mm Jack for ext. speaker .................mono 3.5 mm Maximum transmission time in an hour ..........6 minutes, ................equivalent to a duty cycle of 10% Specifications are subject to change without notice. XT50 PRO user’s manual | 11... - Page 14 Importado por: MIDLAND IBERIA SA C/Cobalt, 48 - 08940 Cornellà De Llobregat (Barcelona España) - www.midland.es El uso de este equipo puede estar sujeto a la obtención de la correspondiente autorización administrativa. Lea atentamente las instrucciones antes de usar el equipo.
