CW363 - 6.5" Coaxial Speaker System
• Perfect balance at the listener location with rotatable
midrange-tweeter assembly
• SonicGuide™ mounted 3/4 inch pivoting tweeter
• Three Driver, 3-way system with stiff fi berglass textured
polypropylene cones, higher cone mass and enhanced
motor strength to optimize them to their restricted
enclosure volume
• Performance Enclosure and new construction bracket
available
• Midrange and tweeter switches allow for response
adjustments
9-1/2"
241mm
8-1/2"
216mm
PSB Speakers reserves the right to change specifications or features without notice.
© 2006 PSB Speakers, a division of Lenbrook Industries Limited.
PSB is a registered trademark of Lenbrook Industries Limited. Printed in Canada 08/06. All rights reserved.
No part of this publication may be reproduced, stored or transmitted in any form whatsoever without the written permission of PSB Speakers
875 CW363 data.
15-3/8"
389mm
14-3/8"
364mm
3-1/2"
89mm
Frequency Range (-6dB):
Recommended Power:
Impedance (Nominal):
Sensitivity (2.83V @1m)
Drivers:
Overall Dimensions (W x H x D):
Cut-out Dimensions (W x H):

Installation Notes

• Try to install the systems at a height between
seated and standing ear level.
• Optimal distance between speakers should
approximately equal the distance from the
listening area to the wall.
• Make a small exploratory hole and check
for obstructions in wall cavity before cutting
mounting hole.
• Mounting template provided.
• Lightly fi ll wall cavity with fi berglass 2 feet
above and below system. Use standard 4"
fi berglass split to half thickness. Use 1" thick
fi berglass behind system.
• Adjust electric screwdrivers to appropriate
torque. Tighten mounting screws fi rmly but
do not over tighten!
• Direct pivoting tweeter towards listening
area.
• The Midrange/Tweeter array should be
rotated until the listener is on the bisecting
plane between midrange and tweeter.
• Midrange and treble switches can be
adjusted to suit room acoustics and personal
taste.
• See manual for more installation hints.
To Reach US Customer Service dial 1 888 772 0000 ext 4445 or 4342
w w w. p s b s p e a k e r s . c o m
1 8 8 8 7 7 2 0 0 0 0
50-21,000Hz
20-125 Watts
4 Ohms
87dB SPL
6-1/2" Woofer
3" Midrange
3/4" Dome Tweeter
9-1/2 x 15-3/8 x 3-1/2"
8-1/2 x 14-3/8"
