Page 1: User Manual
TouchKit TouchScreen Controller User Manual for Windows 9X / ME Version: 3.4.0 TouchKit Manual for Win9X/ME v3.4.0... -
Page 2: Table Of Contents
CONTENT CHAPTER 1. TOUCH PANEL CONTROLLER ... 2 1.1 C ... 2 ONTROLLER 1.2 S PECIFICATIONS AND EATURES CHAPTER 2. INSTALLING TOUCHKIT... 4 CHAPTER 3. CONFIGURATION UTILITY AND RIGHT BUTTON EMULATOR ... 8 CHAPTER 4. MONITOR ROTATION SETTING ... 23 4.1 R OTATING DISPLAY BY WAY OF N 4.2 R... -
Page 3: Chapter 1. Touch Panel Controller
Chapter 1. Touch Panel Controller This touch panel controller provides the optimal performance of analog resistive touch panels for 5 wire models. It communicates with PC system directly through RS232, PS/2 or USB connector. Users can see how superior the design is in sensitivity, accuracy and friendly operation. - Page 4 Table 2. Specifications for TouchKit controller Features Calibration Compensation Draw Test Language Advanced Feature Controller Setting Mouse Emulator Sound Notification Double Click OS support COM port support Table 3. Features for TouchKit software TouchKit Manual for Win9X/ME v3.4.0 Fast full 4 points position Accurate 25 points linearity compensation.
-
Page 5: Chapter 2. Installing Touchkit
Chapter 2. Installing TouchKit TouchKit is software, which contains drivers for the touch panel controllers. For the specified communication connectors, RS232, PS/2 and USB, and the other two utilities: • Touch Tray support This utility is for emulating the right and left button of mouse through the touch panel. - Page 6 5. Then check the check box if PS/2 touch controller is to be installed. The default is unchecked. Then Press [Next >] to continue installation. System will give you a warning, if user checks the PS2AUX check box, 6. Choose the setup type that best suits your needs. There are two TouchKit accessory utilities to choose from, Rotation Monitor Utility and Shutdown Utility.
- Page 7 7. Select the appropriate folder where set-up files will be installed. Then Press [Next >] to continue installation. 8. Then type in the name of program folder for TouchKit or press [Next >] to continue. There will be a default name for it. During driver installation, the setup program will scan COM port for RS232 Touchkit controller.
- Page 8 9. Windows will copying files once that is done it will request to re-boot computer. Press [Yes >] to re-boot immediately or [No >] to re-boot later. The installation will not be finished until system re-boot. 10. Setup is complete. After TouchKit installation, the USB device will be found automatically as soon as it is plugged into the computer.
-
Page 9: Chapter 3. Configuration Utility And Right Button Emulator
Chapter 3. Configuration Utility and Right Button Emulator There are five property pages in TouchKit utility, they are General, Setting, Edge coefficient, Monitors and About. Each property page contains different functions for users to make adjustments. Therefore, users can easily manage all the TouchKit controllers through the TouchKit utility. - Page 10 <Language> TouchKit supports multi-language user interface. Users could select native language that is compatible to operation system support. For example, if the operation system is a traditional Chinese version, users could see the normal display words under the traditional Chinese and English mode. There are ten different languages, English, Traditional Chinese, Simplified Chinese, French, Spanish, German, Japanese, Italian, Korean and Dutch supported in this feature of TouchKit.
- Page 11 Device is found in COM1 The controller is displayed on the Panel List box. Users can get interface type, firmware version and baud rate for each controller. If more than one device is added select the proper device from the panel list window.
- Page 12 There are three buttons, [4pts Cal] [Draw Test] [Advanced], at the lower section of the General property page. <4pts Cal> Correct 4 point locations on screen with the panel. Press [4 pts Cal], screen displays as follows. Touch the blinking symbol on panel until it beeps or it stops blinking. TouchKit Manual for Win9X/ME v3.4.0...
- Page 13 <Draw Test> Test the drawing position related to the display screen on panel. Click on the [Draw Test] button. There will be a blue square display showing. In drawing test window, users can click [Clear] button to clear the window. Also, users can click [Quit] or press mouse right button to quit from the drawing test.
- Page 14 Press [Yes] to clear previous records. The new record will become default record. Press [25ptCal] to do 25 points calibration. Calibrate the 25 point locations on screen using the touch panel. Touch the blinking symbol on panel until it beeps or stops blinking. After the calibration, the new record will overwrite the old one.
- Page 15 The capacitive controller will restart, DO NOT touch the screen before the warning Warning: Do not adjust the sensitive and sampling time without RD help Setting There are three functional groups in the Settings property page, the upper section of the property page is the sound option;...
- Page 16 The Mouse Mode provides users different operating options. They are as follows: Mouse Mode <Mouse Button> Click it to show / hide Touch Tray on the right bottom corner of the desktop. The touch panel system starts with the computer booting, and a mouse icon shows in the taskbar.
- Page 17 <Shutdown utility> Shutdown utility Click on shutdown utility in the task bar There are five modes in shutdown utility for users convenience. [Standby] to enter standby mode that saves power consumption. [Shutdown] to turn off PC. [Reboot] to restart PC. [Cancel] to escape from the Shutdown utility dialog.
- Page 18 <Option> Touchkit provides an option for advanced Mouse Emulation settings. When the Option button is pressed, a setting property sheet will pop up. Support Constant Touch and Support Auto Right Button check boxes are shown in the property sheet to enable / disable Constant touch and Auto right button support. [Constant Touch] Enable Constant Touch to force driver to stop reporting touch point when the movement is within the range which users can adjust.
- Page 19 If users want to cancel the function of TouchKit Hide Cursor, do the steps again and choose the other scheme. Double Click adjustment provides users the ability to set up the tolerance while double clicking. Double Click Adjustment <Double Click Speed> TouchKit Manual for Win9X/ME v3.4.0...
- Page 20 Double Click Speed is the double click response time for Windows system. Users can adjust the proper speed for easy double clicking using the touch panel. <Double Click Area> Each touch area has its own touch tolerance. If the Double Click Area is set to <Smaller>, the panel will be very sensitive to small movements.
- Page 21 Set the Edge to <Smaller>, TouchKit will reduce the vertical position of the left edge. Set the Edge to <Larger>, TouchKit will extend the vertical position of the left edge. <Right> Set the Edge to <Smaller>, TouchKit will reduce the vertical position of the right edge.
- Page 22 orientation to touch screen, and the cursor will be moved 10 pixel of X and Y Axis to left and bottom. If users want the value back to the default value, choose Default button. Monitors There are three functions in this property page, and they are Multiple Monitors, Split Monitor and One point Calibration.
- Page 23 After finish monitor mapping, Press [Apply] to apply the mapping relation. <Split Monitors> To use the Split Monitor function, users need to select which controller you want to launch this function, then check the Multiple Monitors box and Split Monitor at the same time.
-
Page 24: Chapter 4. Monitor Rotation Setting
Chapter 4. MONITOR ROTATION SETTING TouchKit driver package for Windows 98/ME/2000/XP provides two easy ways to rotate the touch panel while the display is rotated. Rotating display by way of nVidia or ATI driver Rotating display by way of Pivot. 4.1 Rotating display by way of nVidia or ATI driver 1. -
Page 25: Rotating Display By Way Of Pivot
One touch blinking symbol adjustment 2. However, 180 degree rotation of touch panel can not be done in one step, users need to rotate 90 degrees twice. 4.2 Rotating display by way of Pivot There are two ways to rotate the display by way of Pivot. Rotating display by way of Pivot hotkey or function menu Rotating display by way of RotTray icon provided by TouchKit. - Page 26 4. However 180 degree rotation of touch panel can not be done in one step, users need to rotate 90 degree twice. < Rotating display by way of RotTray icon provided by TouchKit> 1. To rotate the display, please install Pivot pro 6.05 first. Then reboot PC to activate Pivot.
- Page 27 6. For Windows 95/98/ME OS, The Registry Editor will show as the follow picture. Then go to HKEY_LOCAL_MACHINE\System\CurrentControlSet\Services\VxD\TKIT. Right click on the MaxRotation, and choose Modify. Right click on MaxRotation to Modify Value data 7. Choosing the Hexadecimal Base, and replace the value data “4”(default) with “FFFFFFFF”.
-
Page 28: Chapter 5. Uninstalling Touchkit
8. Here bellow are the value data for different version of Pivot: Version of Pivot Pivot pro 6.05 Pivot 5.1 Other Version Chapter 5. Uninstalling TouchKit Follow these steps to uninstall TouchKit. 1. Go to Start / Programs / TouchKit / Uninstall, and execute it. 2. - Page 29 4. Start to uninstall TouchKit. If users do not want to uninstall TouchKit at this moment, press [Cancel] to terminate the uninstall process. 5. TouchKit will not be removed until system re-boots. Press [Yes] to re-boot immediately or [No] to re-boot later. TouchKit Manual for Win9X/ME v3.4.0...
