Page 1: User Manual
TouchKit TouchScreen Controller User Manual for Windows CE Version: 2.0.9 TouchKit Manual for WinCE v2.0.9... -
Page 2: Table Of Contents
CONTENT CHAPTER 1. TOUCH PANEL CONTROLLER ... 2 1.1 C ... 2 ONTROLLER 1.2 S PECIFICATIONS AND EATURES CHAPTER 2. INSTALLING TOUCHKIT... 4 2.1 F CE 2.12 / 3.0 ... 4 INDOWS 2.2 F CE.NET S INDOWS TYLUS 2.3 F CE.NET INDOWS CHAPTER 3. -
Page 3: Chapter 1. Touch Panel Controller
Chapter 1. Touch Panel Controller This touch panel controller provides the optimal performance of analog resistive touch panels for 5 wire model. It communicates with PC system directly through RS232, PS/2 or USB connector. Users can see how superior the design is in sensitivity, accuracy and friendly operation. - Page 4 Table 2. Specifications for TouchKit controller Features Calibration Compensation Draw Test Language Advanced Feature Controller Setting Mouse Emulator Sound Notification Double Click OS support COM port support Table 3. Features for TouchKit software TouchKit Manual for WinCE v2.0.9 Fast full 4 point positioning Accuracy 25 points linearity compensation.
-
Page 5: Chapter 2. Installing Touchkit
Chapter 2. Installing TouchKit TouchKit is software, which contains drivers, configuration and right button utilities of the touch panel controllers for RS232 and USB on x86 CPU and Windows CE operation system. The two utilities are as follows: • Configuration support The calibration and draw test of touch panel are done by this support. -
Page 6: For Windows Ce.net Stylus
2.2 For Windows CE.NET Stylus There are two driver package versions and showed as below: CE.NET bundle calibration utility Stylus dedicated configuration utility. USB interface driver installation with CE.NET bundle calibration utility. File List: USBPort.dll Touchp.dll Calibration.exe the path while building the image of CE platform. This program is not necessary for CE.NET) Note: Select the UHCI or OHCI USB Host Controller driver for the platform, which is supported by the target device, and check the USB mouse can go... - Page 7 1. Create a sub-folder “CEDB” under C:\ 2. Copy files USBPort.dll and Touchp.dll to the directory. 3. Launch platform builder and open the platform workspace. 4. Edit the PROJECT.BIB in the Parameter View of Platform Builder. 5. Add these two lines in Modules: usbport.dll touchp.dll TouchKit Manual for WinCE v2.0.9...
- Page 8 6. Edit the PROJECT.REG in the Parameter View of Platform Builder. 7. Add these lines for registry: [HKEY_LOCAL_MACHINE\HARDWARE\DEVICEMAP\TOUCH] “DriverName”=”Touchp.dll” “CalibrationData”=”102,102 1945, 102 1945,1945 102,1945” “BCLEFT”=dword:64 “BCRIGHT”=dword:64 “BCTOP”=dword:64 “BCBOTTOM”=dword:64 Then copy the following sentences to the PROJECT.REG [HKEY_LOCAL_MACHINE\Drivers\USB\LoadClients\14371_1\0_0_0\255 _255_255\USB_TOUCH_Driver] “DLL”=”USBPort.dll” [HKEY_LOCAL_MACHINE\Drivers\USB\LoadClients\14371_2\0_0_0\255 _255_255\USB_TOUCH_Driver] “DLL”=”USBPort.dll”...
- Page 9 8. After building the image of CE.NET and loading it to the hardware platform. Users can use the stylus to do the calibration, which can be found in the control panel. TouchKit Manual for WinCE v2.0.9...
- Page 10 9. To keep the calibration data after WINCE reboot, please write WINCE REGISTRY to FLASH or other storage on target. RS232 interface driver installation with CE.NET bundle calibration utility. File List: Touchp.dll Calibration.exe the path while building the image of CE platform. This program is not necessary for CE.NET) Note: TouchKit Manual for WinCE v2.0.9...
- Page 11 Select the Touch Display [stylus] on the platform. Users can see: “Catalog\Core OS\Display based devices\Shell and User Interface\Touch Display[Stylus]” Select the Mouse on the platform. Users can see: “Catalog\Core OS\Display based devices\Shell and User Interface\Mouse” 1. Create a sub-folder “CEDB” under C:\ 2.
- Page 12 6. Edit the PROJECT.REG in the Parameter View of Platform Builder. 7. Add these lines for registry: [HKEY_LOCAL_MACHINE\HARDWARE\DEVICEMAP\TOUCH] “DriverName”=”Touchp.dll” “CalibrationData”=”102,102 1945, 102 1945,1945 102,1945” “COMM”=”COM1:” “BCLEFT”=dword:64 “BCRIGHT”=dword:64 “BCTOP”=dword:64 “BCBOTTOM”=dword:64 TouchKit Manual for WinCE v2.0.9...
- Page 13 8. Set the COMM for the COM port users want to use, it can be setup in the upper registry. 9. After building the image of CE.NET and loading it to the hardware platform. Users can use the stylus to do the calibration, which can be found in the control panel.
- Page 14 10. If the user wants to keep the calibration data after WINCE reboot, please write WINCE REGISTRY to FLASH or other storage on target. TouchKit Manual for WinCE v2.0.9...
-
Page 15: For Windows Ce.net And Ce 5.0
2.3 For Windows CE.NET and CE 5.0 Touch driver installation with TouchKit utility. File List: USBTouch.dll TouchKit.dll TouchKit.exe DrawTest.exe Calibration.exe UpdateEEPROM.exe Note: 1. If using USB controllers, users select the UHCI or OHCI USB Host Controller driver on the platform, which is supported by the target device, and check that the USB mouse can to the same port. - Page 16 1. Create a sub-folder “CEDB” under C:\ 2. Copy files USBTouch.dll, TouchKit.dll, TouchKit.exe, DrawTest.exe, Calibration.exe and UpdateEEPROM.exe to the directory. 3. Launch platform builder and open the platform workspace. 4. Edit the PROJECT.BIB in the Parameter View of Platform Builder. 5.
- Page 17 6. Edit the PROJECT.REG in the Parameter View of Platform Builder. 7. Add these lines to registry: a) Add the registry setting for all modules: [HKEY_LOCAL_MACHINE\Drivers\TouchKit] “RBSIZE”=dword:800 “RBTIME”=dword:989680 “FLAGS”=dword:1-------->set 0x1 sofware filter enable “ZfilterThreshold”=dword:800 “ZfilterBound”=dword:00100001 “SoundType”=dword:0-------->This is the default sound type b) If user wants to use USB module: [HKEY_LOCAL_MACHINE\Drivers\USB\LoadClients\14371_1\0_0_0\255 _255_255\USB_TOUCH_Driver]...
-
Page 18: Chapter 3. Configuration Utility And Right Button Emulator
[HKEY_LOCAL_MACHINE\Drivers\USB\LoadClients\3823_1\0_0_0\255_ 255_255\USB_TOUCH_Driver] “DLL”=”USBTouch.dll” [HKEY_LOCAL_MACHINE\Drivers\USB\LoadClients3823_2\0_0_0\255_2 55_255\USB_TOUCH_Driver] “DLL”=”USBTouch.dll” c) If user wants to use RS232 module1: [HKEY_LOCAL_MACHINE\Drivers\BuiltIn\TouchKit1] “Dll”=”TouchKit.dll” “Order”=dword:00000001 “Prefix”=”TKT” “Index”=dword:00000001 “Context”=dword:1;---->This is the COM Port index which users use If user wants to use RS232 module2: [HKEY_LOCAL_MACHINE\Drivers\BuiltIn\TouchKit2] “Dll”=”TouchKit.dll” “Order”=dword:00000001 “Prefix”=”TKT” “Index”=dword:00000002 “Context”=dword:2;---->This is the COM Port index which users use Chapter 3. - Page 19 <Calibrate 4pt> Calibrate 4 locations on screen with the panel. Press [Calibrate 4pt], screen displays as follows. Touch the blinking symbol on panel until it beeps or stops blinking. There will be a message window after this correction. <Draw Test> Test the drawing position related to the display screen on panel.
- Page 20 Try to write or draw on it to verify the touch position. Press [CLEAR] for clearing touch screen, and press [QUIT] to exit Draw Test. <Clear CalParam> Press [Clear CalParam] to clear the previous calibration records. The record will become default record. <Calibrate 25pt>...
-
Page 21: For Windows Ce.net
Right Button starts with the computer booting. A mouse icon is located in the right corner of screen. Click the right button mouse; there will be a pop-up box. Select the Button, then a square box shows up. Change right / left Button by clicking the icon on screen. Cyan area expresses what button has been selected. - Page 22 <Calibrate 4pt> Calibrate the 4 point locations on screen with the panel. Press on [Calibrate 4pt], screen displays as follows. Touch the blinking symbol on panel until it beeps or stops blinking. There will be a message window after this correction. <Draw Test>...
- Page 23 Press [Calibrate 25pt] to execute 25 point calibration. Correct 25 point locations on screen with the panel. Touch the blinking symbol on panel until it beeps or stops blinking. After the calibration, the new record will overwrite the old one. <Sound>...
- Page 24 Lift Up The system will not make any sound until finger leaves the touch panel. <Right Button> If the users want to emulate right button, the users can touch and keep the finger on the panel for two to three seconds. The last touch will emulate the mouse right button.
