Active Key AK-C7000F-F Instructions

Active Key GmbH & Co. KG
Brunnenäcker 6
D-91257 Pegnitz
www.activekey.de
Phone: +49(0)9241/48337-0
FAX: +49(0)9241/48337-29
E-Mail: info@activekey.de
Instructions
Safety Information
Wireless 2,4 GHz RF Keyboard
AK-C7000F-F
The AK-C7000F-F is a high quality, highly reliable hygiene keyboard with numpad.
Particularly designed for the use at hospitals and in practitioners. The keyboard is
sealed by a silicone membrane.
Installation
1. Insert the 4 batteries as shown on the bottom of the keyboard.
2. Plug the wireless receiver (dongle) into a USB port on the computer.
3. If the keyboard does not yet have a function, please activate the "Connect function" of the
keyboard by pressing "Fn" + "Esc" (now the "Scroll Lock LED" flashes). Wait about 5
seconds (until the LED stops flashing).
4. Now the keyboard should be connected and ready. If this is not the case, please carry out
the commissioning again from point 1. If there is no function, please contact us.
Please hold these information ready when you contact us:
- Article and serial number of the product
- Name and producer of your PC/notebook or motherboard
- Operating system and if installed version of the service pack
When the batteries are discharged, the status LEDs light up by each keypress. Please
replace the batteries as soon as possible.
Note: The Micro-USB interface is only to be used for the implementation of firmware
updates!
Function of Fn key:
Key combination effect
Fn + Clean on/off Activates/deactivates the key field.
This function is used for cleaning the
keyboard, without unplugging it from
the PC.
Fn Shows LED status of Num Lock, Caps
Lock, Scroll Lock
Fn + Esc Activates connect-function (look above
by installation)
All rights reserved. Copy or duplication, except for personal use, not permissible without specific prior written consent by Active Key GmbH
& Co. KG. Contents are subject to change without notice. Errors excepted. Copyright by Active Key GmbH & Co. KG.
LED status
All LEDs are
flashing
On
Scroll Lock LED
flashes
Version 20200922
Possible errors
Batteries are empty
Connection between keyboard and
computer does not work
Operating system or hardware does not
support a USB keyboard
As distributor of batteries, we have the following obligations under §18 BattG:
1. Batteries can be returned free of charge after use in the commercial firm.
2. End users are legally obliged to return used batteries.
3. Manufacturers of batteries are required to mark batteries
symbol before placing them on the market for the first time:
batteries shall label batteries containing more than
mercury, more than 0.002% by mass of cadmium or more than 0.004% by mass of lead,
before placing them on the market for the first time with the chemical symbols of metals (Hg,
Cd, Pb) in which the limit is exceeded. The characters are to be applied below the symbol.
Safety Note: The enclosed batteries must not be charged!
Hereby Active Key GmbH & Co. KG declares that the aforementioned type of radio equipment
with the product models CK103A-RF (2.4G Wireless Keyboard) and GD-001 (Wireless
Keyboard Dongle) complies with the RED 2014/53 / EU directive. The full text of the EU
declaration of conformity is available at the following internet address
http://www.activekey.de/ce-doc/CE_DOC_RED_AK-C7000F-F.pdf
Specification
Compatibility
Temperature Range
Chemical Resistance
Interface
Supply Voltage
Current Consumption
Connector
Dimensions (incl. Membrane)
Weight
LED Status Indicators
Key Switch Technology
Key Travel
Key Actuation Force
Frequency-band
Maximum transmission power
Agency Approvals
*No Medical Device acc.to Regulation (EU) 2017/745
Delivery Content
- 2,4 GHz wireless keyboard - 4 AAA batteries - 2,4 GHz USB-receiver - Instructions
Repair
Use new batteries
Repeat installation procedure
To check if your system supports the
keyboard you can plug a standard wired
USB keyboard into the USB port. If the
wired USB keyboard does not work, the
usage of the keyboard is not possible.
with the following
The manufacturer of
0.0005% by mass of
:
All OS that support Standard USB Keyboards
Storage -20° to +60°C - Operation 0° to +50°C
Wipe Disinfection according to Guidelines Cleaning and
Disinfection DGHM/VAH
USB 1.1 (1.2 Mbit/s)
6 V by 4x AAA Batteries
Typ. 5 mA (USB: Low Power Device)
USB Type A (Nano Dongle), Range 10m
Approx. 374x139x25mm
0,73kg (without packaging)
Num Lock, Caps Lock, Scroll Lock
Scissors Balancing Key Guidance
Approx. 2 +/- 0,5 mm
Approx. 60 grams
2400 MHz – 2483,5 MHz
CE, RoHS, Certification FCC, EN 60601-1-2:2015*
10 mW
