CSM DD-Logger
Installation Manual
Liability remarks
This installation manual and other documents are part of the product and contain important information for its
safe and efficient use. To maintain the high quality level the product is continuously being developed, which may
result in the product's technical details changing at short notice. As a result, the contents of this documentation
may differ from the technical specifications of the product. No claims against the manufacturer can therefore be
derived from the contents of the product documentation.
CSM GmbH is not liable for technical or editorial errors or missing information.
CSM GmbH assumes no liability for damage resulting from improper use of the product and/or non-observance of
the product documentation, in particular the safety instructions.
General instructions
NOTE!
The latest information concerning the status of the software and detailed installation instructions
can be found on the CSM Website.
i
Please read this document carefully before installing the DD-Logger hardware and software.
The equipment should not be used without prior familiarisation with the installation manual. The equipment
should not be used beyond the limits which are specified in the technical data.
All hardware, software and documentation rights belong to CSM GmbH. It is allowed to create backup copies of
the software.
Hardware installation
CAUTION!
The host system should be switched off before doing the following.
f
Modifications to the connections should only be made with the system switched off.
f
Emc hints have to be regarded, see chapter "EMC" later on.
f
CAUTION!
Before you start with the hardware installation take care that there is no static electrical discharge
on the DD-Logger or on any other system component. Discharge yourself by touching a grounded
object before you remove the DD-Logger from its package. Be always sure that you do no touch any
component before you are well discharged.
CSM GmbH
Computer-Systeme-Messtechnik
Advertisement
Table of Contents
Related Manuals for CSM DD-Logger
Summary of Contents for CSM DD-Logger
- Page 1 Before you start with the hardware installation take care that there is no static electrical discharge on the DD-Logger or on any other system component. Discharge yourself by touching a grounded object before you remove the DD-Logger from its package. Be always sure that you do no touch any component before you are well discharged.
- Page 2 If the DD-Logger is used in a 5¼" bay, you can obtain a suitable mounting frame from CSM GmbH. 4. Plug one of the free power connectors from your computer's power supply into the DCIN plug of the DD-Logger. NOTE! In most computers you will find a power connector that is ready for use.
- Page 3 DD-Logger PCB, DD-Logger 3½" and DD-Logger 19" should be installed in a EMI-shielded cabinet. While installing the device, make a electric contact with a large surface area from the cabinet shield to the case of DD-Logger 3,5", to the front of DD-Logger 19", to the fixing holes of the DD-Logger PCB, respectively. CAUTION! Shield, case and fixing holes are connected directly to the negative line (GND) of power supply.
- Page 4 Serial interface CAUTION! There are several versions of DD-Logger with different interfaces. See product label for identification. RS232 Name Signal Name Signal transmit data (output of DD-Logger) Mode select (input of DD-Logger, optional) Control out (output of DD-Logger) receive data (input of DD-Logger) signal ground RS422 (product label "RS422/RS485")
