Kon-TEC KT-LFPES512100 Installation Manual

Lifepo 4 lithium iron phosphate lifepo4 battery pack
Hide thumbs Also See for KT-LFPES512100:

Advertisement

Quick Links

OPERATION AND MAINTENANCE
MANUAL
LITHIUM IRON PHOSPHATE
LIFEPO4 BATTERY PACK
51,2V 100Ah
KT-LFPES512100
LEGAL PROVISIONS
This manual describes in detail the requirements and procedures for safe installation and operation of Kon-TEC lithium battery pack. Please read this manual carefully,
only qualified persons are allowed to install, operate and maintain the system, otherwise it may cause product damage or personal safety risks.
Any actions against safety operation, or do not follow rules of this manual and limited warranty letter, will void warranty and qualification of this product. Meanwhile, the
manufacturer will be not responsible for the product damage, property damage, personal injury or even death.
The information contained in this manual is accurate when it's issued. Kon-TEC reserve right to change specification (such as optimization, upgrade or other operations)
without prior notice, please always view the latest document via QR code. In addition, please noted that the diagrams/schematics in this document are used to help
understand system configuration and installation instructions, which may be different from the actual items at the installation.
LEGAL TERMS
Kon-TEC will retain the copyright of this document, do not extract, copy or translate in any ways without the written permission.
ON-LINE INSTRUCTIONS IN POLISH AND ENGLISH
CONTENT
1. Information...........................................................................................................................................................................2
1.1 Validity....................................................................................................................................................2
1.2 Target Group.....................................................................................................................................2
1.3 Levels of warning messages................................................................................................2
1.4 Symbol Description....................................................................................................................2
1.5 Abbreviation Description.......................................................................................................3
2. Safety.......................................................................................................................................................................................3
2.1 Safety precautions......................................................................................................................3
2.2 Safety instructions.....................................................................................................................4
2.2.1 Safety gear........................................................................................................4
2.2.2 Emergency safety measures.............................................................4
2.2.3 Other Tips.........................................................................................................4
3. Product Overview..........................................................................................................................................................5
3.1 Introduction........................................................................................................................................5
3.2 Features................................................................................................................................................5
3.3 Specification.....................................................................................................................................6
3.3.1 Dimension..........................................................................................................6
3.3.2 Parameters.......................................................................................................6
3.3.3 Panel Interface...............................................................................................7
3.4 Protection function....................................................................................................................9
4.4 Installation....................................................................................................................................................................10
4.1 Preparation.......................................................................................................................................10
4.1.1 Safety Compliance.....................................................................................10
4.1.2 Environment...................................................................................................10
4.1.3 Tools......................................................................................................................10
1/28
https://kon-tec.eu/kt-lfpes512100
Instrukcje on-line w języku polskim i angielskim
4.2 Inspection.........................................................................................................................................10
4.2.1 Unpacking........................................................................................................10
4.2.2 Scope of delivery......................................................................................10
4.2.3 External cable kits.....................................................................................14
4.3 Start Installation...........................................................................................................................15
4.3.1 Remainder.........................................................................................................15
4.3.2 Procedures.......................................................................................................15
4.3.2.1 Rack mounted..............................................................16
4.3.2.2 Stack mounted...........................................................16
4.3.2.3 Wall mounted...............................................................17
4.3.2.4 Floor mounted...........................................................18
4.3.3 Tips........................................................................................................................19
5.5. Cable connection and commissioning.................................................................................................20
5.1 Get battery ready.......................................................................................................................20
5.2 Grounding cable connection...........................................................................................20
5.3 Communication cable connection..............................................................................20
5.4 DC power cable connection................................................................................................21
5.5 Connecting with inverter.....................................................................................................22
5.6 Commissioning............................................................................................................................24
5.7 Switch off battery......................................................................................................................24
6. Troubleshooting and FAQ....................................................................................................................................25
7. Transport, Storage......................................................................................................................................................25
8. Disposal of battery....................................................................................................................................................25
9. Appendix - inverters / chargers connections........................................................................................26
