HDSX TV Sound Optimizer HDMI ARC Reference Manual

CAUTION
Keep naked flames (e.g. burning candles) away from the appliance.
Do not place the unit in a location where there is insufficient air supply,
for example in a narrow shelf.
The unit is designed to operate in conjunction with your TV set and
receives its operating power from its 5V USB port. Do not operate the
unit with uncertified power adapters or other power supplies that are
not proven to be safe.
Note for customers: The following information applies only to appliances
sold in countries where EU directives apply.
This product was manufactured by or for Kronoton GmbH. EU Importer:
Kronoton GmH. Please send enquiries to the importer or about product
conformity based on legislation in Europe to Kronoton GmbH, Völckers
Park 13, 21465 Reinbek.
The validity of the CE and FCC marks is limited only to those countries
where they are required by law.
Disposal of used electrical and electronic equipment (to be applied in
the countries of the European Union and other countries with a separate
collection system for these products).
The symbol on the product indicates that the product should not
be treated as normal household waste. By helping to dispose of the
product correctly, you are protecting the environment and your fellow
human beings. The environment and health are endangered by incor-
rect disposal.
Material recycling helps to reduce the consumption of raw materials. To
ensure that the product is disposed of correctly, take the product to an
appropriate collection point for the recycling of electrical and electro-
nic equipment.
SECURITY MEASURES
Line-Up
To avoid the risk of malfunction, avoid the following locations when
placing or storing this unit:
• A place exposed to high temperatures, e.g. under direct sunlight or
lighting or in a sauna
• In a vehicle with closed windows (especially in summer)
• A place exposed to excessive dust
• A place exposed to strong vibrations
Depending on the conditions of how the unit is placed or fixed, it may
tip over or fall off the surface. Do not leave valuables near the unit.
Miscellaneous
Do not use this unit in an extremely cold or extremely hot environment
(temperature outside the range 5º C - 35º C).
Turn down the volume of your audio system before switching on the
device for the first time (Passthrough mode off), as there may be a
sharp jump in volume depending on the audio material you are using.
Do not open the unit under any circumstances. Opening the unit
irrevocably voids its warranty. For more information on the warranty
conditions, please visit https://www.hdsx.com.
The software contained on the device is provided to you by Kronoton
by licence, which you acquire with the purchase of this device. The
licence contains the rights to use the device in the sense of correct
commissioning. The other rights, in particular the copyright and IP
rights and the right to change, edit and further develop the software
remain with Kronoton.
Technical data
• Housing: Metal, stone grey
• Power supply: DC 5V via micro USB B connector
• Audio input digital: HDMI ARC IN
• Audio input analog: 3.5mm jack stereo
• Audio output: HDMI ARC OUT
• Weight: 115g
• Dimensions: Length: 5.3cm, Width: 10cm, Height: 2.38cm
• Audio format input: PCM 2.0 uncompressed | Passthrough 5.1, DD+, Atmos
• Sound output: HDSX.TV | HDSX.360 | Passthrough 5.1, DD+, Atmos
• Immersive: HDSX.360 | Virtual 3D Soundstage | intelligible dialogue
• Sound transmission: PCM sound with two channels | In Passthrough
mode: Digital multichannel formats according to ARC standard:
Dolby Digital & DTS up to 5.1, Dolby Digital Plus, Dolby Atmos
based on Dolby Digital Plus
Scope of delivery
• Reference guide
• HDSX TV SOUND OPTIMIZER HDMI ARC
• Cable USB 2.0, USB-A-connector to Micro-USB-B-connector, length 50cm
• HDMI 2.1 cable (50cm), HDSX certified
• 3.5mm stereo jack cable (50cm)
• Self-adhesive Velcro straps for mounting the device behind your TV set
• 4 rubber feet, self-adhesive for placing the unit on a horizontal surface
You will find many more helpful answers to your questions and quick
solutions for problem solving on our website:
www.hdsx.com.
Perfectly
balanced sound
for TV and
streaming
Reference Guide
HDSX TV SOUND OPTIMIZER HDMI ARC
Please read these instructions carefully before using the device and
keep them for future reference.
You will find more helpful answers to your questions and quick solutions
on our website:
www.hdsx.com
