Page 1: Table Of Contents
Contents 1. Introduction 1.1 Profile 1.2 Feature 1.3 Dimension 1.4 Specification 2.How to work 2.1 Working flow 2.2 Other warnings 2.3 Led indicator 2.4 Speaker 3. Installation 4.Configuration 4.1 Tools 4.2 Install CP210x driver for wireless configuration tool 4.3 Configuration process 5. -
Page 2: Introduction
Introduction 1.1 Profile AN-102D LoRaWAN Smoke Detector support standard LoRaWAN™ protocol. With high-precision, the device emit red light when it detects a fire alarm. The device sends alarm data to the platform to remind relevant personnel on the site to deal solve it. Test mode and low battery warning functions available. - Page 3 Dimension: Dia119 x 48.3mm Figure: Exploded view Description Smoke Box Cover ① ② Smoke Box ③ Smoke Box Steel Net ④ Speaker ⑤ Upper Shell ⑥ PCBA ⑦ Lower Shell ⑧ Battery ⑨ Battery Compartment Cover Base ⑩ On/off Button ⑪...
-
Page 4: Specification
1.4 Specification Description Parameter Protocol LoRaWAN 1.0.2/ 1.0.3 Alarm way Led indicator, voice message, beep sound Alarm >80dB (at 3m ) Smoke detecting Red and blue light electrical detecting Temperature detecting detecting ambient Temperature CN470MHz~510MHz EU863MHz~870MHz Frequency US902MHz~928MHz AU915MHz~928MHz AS923MHz; RU864-870MHz; IN865-867MHz Data transmission rate 300bps～5.4Kbps Max Tx power... -
Page 5: How To Work
2.How to work 2.1 Working flow Turn on After the device is powered on, press the button on the front, and the led indicator lights in red. If releasing the hand, the led indicator will go off. Press and hold the button for 5 seconds, it sounds the voice message “Turn on”. Then it goes to initialization with the led indicator in yellow. -
Page 6: Speaker
calibration ⑥Detection Lights on in red Flash every 10msec mode/ Fire alarm ⑦ Working Lights on in red Flash every 50 seconds Lights on in red Flash every second ⑧ Malfunction 2.4 Speaker Status Voice message/ Sound Remark Device turn on Turn on Press and hold the button for 5 seconds to turn on. -
Page 7: Install Cp210X Driver For Wireless Configuration Tool
Winext manage App Figure: Tool List a) Install the CP210x driver for wireless configuration tool, file as below: b) Install Winext manage App, file as below: 4.2 Install CP210x driver for wireless configuration tool (1) Open CP210x driver for wireless configuration tool (2) Select the driver program to install depending to the system type. - Page 8 Select Accept the License Agreement and click on Next, as below: Wait for a while and click on Finish, as below:...
-
Page 9: Configuration Process
Check the driver program after installation finished. Click on Computer-Attribute- Device manager, as below: 4.3 Configuration process Insert the wireless serial port tool into the USB port of the laptop. Open the web-based configuration tool folder, “serialport-win32-x64” folder, double-click “serialport.exe” to open the web-based configuration tool software. Note: The serial port number may different on different laptop. - Page 10 Open the web-based configuration tool software- Winext Manage App. Click LoRaWAN icon. Please follow step 1,2,3, 4, 5. 1.Open Winext Manage App-LoRaWAN 2. Reboot device and its DevEUI will be shown in the dropdown list. 3. Select the target device, 4.Click on Device Locked...
-
Page 11: Communication Format
Communication format Fport=210, it is in hexadecimal. 5.1 Data report 5.1.1 Smoke alarm event Item Type Byte number Description Reserved field Data 0X00 Device type Data type 0X01 Data 0X05 Device status Data type 0X31 Data 0X00, normal; 0X01, alarm 5.1.2 Device abnormal event Item Type... - Page 12 Data 0x00: normal; 0x01: abnormal Smoke Data type 0X31 transmitter Data 0x00: normal; 0x01: alarm status 6. Trouble-shooting 6.1 FAQ Failure Reason Solution Send alarm after power on Inside circuit board Return factory for repair damaged Device is in abnormal Reboot status Red light on and it flashes...
- Page 13 Version Description Editor Date V1.0 Initial version Zijun Liang 27th-Oct-2020 Shenzhen Winext Technology Co., Ltd. Address: 5 Floor, Building B50, Zhongchuang Industrial Park, Liuxian Rd, Taoyuan Street, Nanshan District, Shenzhen 518055, China Tel：(+86) 0755-23990916 Web: www.winext.cn http://winext.en.alibaba.com ------------------------------------------------------------------------------------------------------------------------------------------ This is a product manual as an installation, operation and use file. Specifications subject to change are without...
