modway Render MOD-7070 Assembly Instructions Manual page 2

Let's get started!
Read through all of
the instructions
before starting
Approx. 60 minutes
assembly time
2 people recommended
for assembly
Furniture components:
1 Top Panel
2 Right Side Panel
3 Left Side Panel
4 Bottom Panel
5 Back Panel
6 Front Leg Panel
7 Back Leg Panel
8 Right Leg Support
9 Left Leg Support
Provided hardware:
A JCBC M6 x 70mm
B Wooden Dowel Ø6 x 30mm x28
C Cam Lock- Ø15 x 12mm
D Cam Bolt- Ø6 x 32mm
E Floor Glide-B321
F C/board Screw Ø3.5 x 16mm x16
G C/board Runner Left
H C/board Runner Right
I Drawer Runner Left
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
Care instructions are
listed in the last step
of this manual
Make sure you have all
parts and components
before discarding any
packing materials
x1
10 Drawer Right
11 Drawer Left
x1
x1 12 Drawer Head
13 Drawer Base
x1
x1 14 Drawer Back
x1
15 Fixed Shelf
x1
x1
x1
x2 J
K
L
x12
x14 M
x4 N
O
x1
P
x1 Q
R
x1
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined
up and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the
hardware or cracking the item.
Assemble your item on a flat, carpeted area, with plenty of space to
work. This will prevent damage and scratches to your floors or the item
while you're assembling the product.
Keep all components and packaging out of reach of children or
animals to avoid risk of choking or suffocation.
x1
x1
x1
12
x1
11
14
x1
13
10
12
x1
Drawer Runner Right x1
JCBC M6 X 60mm x2
Cam Lock- Ø12 x 9.9mm x2
Plastic Corner Block x4
JCBCW M6 x 50mm x4
Screw Ø4 x ¾ Inch x4
C/board Screw Ø4 x 38mm x2
Allen Key x1
Cam Lock Cap x4
1
3
15
4
9
7
6
8
What you need:
Phillips Head Screwdriver
Phillips
5
2
Page 2 of 12
