- Page 1 INSTRUCTION MANUAL AIR 76 AIR 75 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 30MIN. ASSEMBLY HARDWARE M3.5x45mm SCREW M6.0x30mm SCREW 8PCS+1spare 6PCS+1spare M3.0x14mm SCREW M3.0x18mm SCREW 10PCS+1spare 10PCS+1spare Hinge M3.0x12mm SCREW 2PCS 4PCS+1spare Lock... - Page 4 PARTS Back panel Left side panel Right side panel Back metal bar-left Back metal bar-right Bottom pad Bottom pad Bottom floor Front panel 2PCS 2PCS...
- Page 5 PARTS Front metal bar-right Front metal bar-left PVC curtain Plastic feet Roof 4PCS...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach the plastic feet Part M to the metal bars Part D & E with the buckle. Attach the panel Part A, B, C with the metal bars Part D & E by 4xP1 screws. - Page 7 PRODUCT ASSEMBLY Attach the plastic feet Part M to the metal bars Part K & L with the buckle. Screw the curtain Part J to the INSIDE of Part I by 4xP3 screws.
- Page 8 PRODUCT ASSEMBLY Attach the Part I to the house with the metal bars Part K & L by 4XP1 screws. ①Attach the bottom pad Part G & F to the side of bottom floor Part H by 3XP2 screws. Attach the bottom pad Part G to the side of bottom floor Part H by 1XP2 ② ...
- Page 9 PRODUCT ASSEMBLY Put down the left bottom floor first,and then put down the right bottom floor,finally connect the bottom floor with bottom pad Part F by 2XP2 screws. Screw the roof Part N on asphalt part from bottom by 6xP3 screws. Notice: The roof edges of back are relatively flat，pls pay attention the position...
- Page 10 PRODUCT ASSEMBLY Screw the roof hinge P6, one side to the roof by 2xP4 screws, the other side to the side panel by 2xP4 screws in left and right sides. Screw the lock P7, screw one side to roof by 2xP4 screws,screw the other to front panel by 4xP5 screws.
- Page 11 PRODUCT ASSEMBLY Complete. Finish...
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
