- Page 1 INSTRUCTION MANUAL AIR 33 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
- Page 3 TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x35mm SCREW M3.5x40mm SCREW 14PCS+1spare 20PCS+1spare Plastic Feet M3.0x25mm SCREW 4PCS 12PCS+1spare...
- Page 4 PARTS Back panel Left panel Right panel Upper hutch floor Down hutch front panel Upper hutch front panel Bottom right floor Balcony floor Bottom left floor...
- Page 5 PARTS PVC curtain Fence Down supporter 2PCS 2PCS Upper stair Upper supporter Down stair 2PCS Divider Back roof Front roof...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Screw the curtain Part J to the inside of the front panels Part D &E by 2xP3 each. Attach the supporter Part L & M to the outside of the left panel Part A by 8xP2. - Page 7 PRODUCT ASSEMBLY Attach the back panel Part C to the side panel Part A & B by 6xP1. Attach the front upper panel Part E to the side by 4xP1.
- Page 8 PRODUCT ASSEMBLY Attach the front down panel Part D to the side by 4xP1. Put in the floor Part H & I to the bottom.
- Page 9 PRODUCT ASSEMBLY Put in the floor Part F & G to the upper layer. ① Put in the divider Part R to close the up and down space. ② If you want a open space, the Part R is useless.
- Page 10 PRODUCT ASSEMBLY Attach fence Part K by 4xP2. Screw down the stair Part N & O by 8xP3.
- Page 11 PRODUCT ASSEMBLY Attach the roof panel Part P & Q by 8xP2. Attach the plastic feet to the leg. Finish...
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
