O Y S T E R P E R P E T U A L
C O S M O G R A P H D A Y T O N A

Advertisement

loading
Need help?

Need help?

Do you have a question about the Oyster Perpetual Cosmograph Daytona and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rolex Oyster Perpetual Cosmograph Daytona

Summary of Contents for Rolex Oyster Perpetual Cosmograph Daytona

  • Page 1 O Y S T E R P E R P E T U A L C O S M O G R A P H D A Y T O N A...
  • Page 2 WEARING THE WATCH FOR THE FIRST TIME Before being worn for the first time, or if it has stopped, a Rolex watch must be wound manually in order to function correctly and precisely. To wind the watch manually, unscrew the winding crown completely, then turn it several times clockwise.
  • Page 3 The green seal accompanying your Rolex watch is a symbol of its status as a Superlative Chronometer. This exclusive designation attests that it has successfully undergone a series of specific final controls by Rolex in its own laboratories in addition to the official COSC certification of its movement.
  • Page 4 THE HEART OF THE COSMOGRAPH DAYTONA MODEL OYSTER PERPETUAL COSMOGRAPH DAYTONA USING YOUR WATCH OVERVIEW SETTING THE WATCH 8-13 EASYLINK COMFORT EXTENSION LINK 14-15 ROLEX GLIDELOCK FINE-ADJUSTMENT SYSTEM 16-17 ROLEX SERVICE CARING FOR YOUR ROLEX 18-19 AFTER-SALES SERVICE 20-21 WORLDWIDE SERVICE NETWORK...
  • Page 6 The dial offers exceptional legibility an anti-reflective coating. thanks to its Chromalight display elements filled with a high-performance The Oyster Perpetual Cosmograph Daytona luminescent material. is equipped with a self-winding mechanical movement entirely manufactured by Rolex.
  • Page 7 THE HEART OF THE USING ROLEX COSMOGRAPH DAYTONA MODEL YOUR WATCH SERVICE OVERVIEW Hour hand Upper pusher (start/stop) Minute hand Lower pusher (reset) Small seconds Bezel with tachymetric scale Chronograph seconds hand Triplock winding crown with triple waterproofness system 30-minute counter...

  • Page 9: Setting The Watch

    THE HEART OF THE USING ROLEX COSMOGRAPH DAYTONA MODEL YOUR WATCH SERVICE SETTING THE WATCH Screwed-down position (crown in for the first time or after the watch position 0, pushers screwed down) has stopped, complete a minimum of The crown and pushers are completely 25 turns for partial winding.
  • Page 10 Initial winding and setting A. Wind the watch manually (position 1). B. Set the time (position 2). Unscrew and then pull out After every use, carefully screw the crown back down against the case to guarantee the waterproofness. Return the crown to position 1 and apply light pressure on it while screwing it down clockwise against the case.
  • Page 11 THE HEART OF THE USING ROLEX COSMOGRAPH DAYTONA MODEL YOUR WATCH SERVICE MEASURING ELAPSED TIME – Press the upper pusher again to To measure elapsed time, follow the stop timing. steps in the order given: – Read the elapsed time. The center –...
  • Page 12 Starting and stopping the timing Resetting the chronograph seconds hand and counter hands to zero * Elapsed time in this illustration is 8 h 06 m 04 s...
  • Page 13 THE HEART OF THE USING ROLEX COSMOGRAPH DAYTONA MODEL YOUR WATCH SERVICE CALCULATING AVERAGE SPEED – Press the lower pusher to reset the chronograph seconds hand and PER HOUR The Oyster Perpetual Cosmograph counter hands to zero. Daytona can be used to calculate –...
  • Page 14 Starting and stopping the timing Resetting the chronograph seconds hand and counter hands to zero * Over a distance of 1 km, the average speed in this illustration is 160 km/h...
  • Page 15 SERVICE EASYLINK COMFORT EXTENSION LINK To ensure optimal comfort when wearing your watch, Rolex created the Easylink comfort extension link. This exclusive system, fitted on the Oyster bracelet of the Cosmograph Daytona, comprises a link that is pulled out or folded back on itself to adjust the length of the bracelet by approximately 5 mm, without the...
  • Page 16 Adjusting from the short position Adjusting from the long position to the long position to the short position...
  • Page 17 ROLEX COSMOGRAPH DAYTONA MODEL YOUR WATCH SERVICE ROLEX GLIDELOCK FINE-ADJUSTMENT SYSTEM On the Oysterflex bracelet, the Rolex Adjustment of the bracelet Glidelock fine-adjustment system enables the bracelet length to be adjusted in Open the clasp approximately 2.5 mm increments up to around 15 mm.
  • Page 19 YOUR WATCH SERVICE CARING FOR YOUR ROLEX Thanks to Rolex expertise, your watch You can help preserve its luster by will require very little day-to-day care. cleaning it occasionally with a microfiber cloth. You can also wash the case and bracelet from time to time using soapy water and a soft brush.
  • Page 20 Before cleaning your watch, always ensure that the crown is screwed down properly against the case to guarantee waterproofness.

  • Page 21: After Sales Service

    Rolex therefore recommends that you periodically return your watch to one The proper functioning and timekeeping of its Official Rolex Jewelers or Service accuracy of your Rolex watch movement Centers for complete servicing, which is is dependent on high-performance...
  • Page 22 At the end of the process, your Rolex During a complete service, the watch is dismantled and all of its components watch undergoes a series of tests to – the case, bracelet and movement – verify its functions, waterproofness and are closely examined.
  • Page 23 SERVICE WORLDWIDE SERVICE NETWORK The network of Official Rolex Jewelers For a list of Official Rolex Jewelers and and Service Centers covers more than Service Centers, please visit rolex.com. 100 countries around the world and draws on the expertise of highly skilled watchmakers, carefully selected and trained by Rolex.
  • Page 24 ROLEX.COM We invite you to visit rolex.com, a privileged place to learn more about the functions of your Rolex watch and about the quality, know-how and fundamental values of the brand. Welcome to the world of Rolex.
  • Page 25 RL X, ROLESIUM, ROLESOR, ROLE X GLID ELOCK , SA ROS, SE A- DW ELLER, SK Y- DW ELLER, SUBMARINER, SUNDUST, SYLOXI, TRIPLOCK, TWINLOCK, YACHT-MASTER. CELLINI. Rolex reserves the right to modify the models illustrated in this publication at any time. © Rolex Watch USA, Inc., Rolex Building, 665 Fifth Avenue, New York, NY 10022 IMR-DAY-US-23 - 4.2023 - Printed in Switzerland...
