CORE LEG
Your Core unit comes in three separate boxes. This box contains only the Legs.
You will require two more boxes to complete assembly of the Core sofa convertible (body and sofa upholstery cover).
Please refer to the assembly instructions accordingly
BODY
Parts and Hardware
Allen Key
Bolt
ADULT ASSEMBLY REQUIRED
If you are missing any parts or have any questions regarding assembly, do not return this item to the retailers store. Please call
our toll- free customer service number and have this assembly manual open to the parts list ready to provide the model name,
and part name or number.
Customer Service
1-877-864-5752
8:30 AM PST - 4:30 PM PST (Monday - Friday)
Website: www.dwellhom.com
Missing Parts: parts@dwellhom.com
Warranty Information: www.dwellhom.com/warranty
WARNING: This Product contains small components, please ensure they are kept away from small children.
LEGS
or
or
Model:
Lot No:
Date of Purchased:
UPHOLSTERY COVER
Advertisement
Summary of Contents for Well CORE LEG
- Page 1 Lot No: Date of Purchased: CORE LEG Your Core unit comes in three separate boxes. This box contains only the Legs. You will require two more boxes to complete assembly of the Core sofa convertible (body and sofa upholstery cover).
- Page 2 Assembly Instructions 1. Carefully place sofa body unit on a clean flat surface with the metal plates facing up. 2. Align all four legs onto designated metal plates and secure two bolts for each legs using provided Allen key. 3. Finally, carefully lift and turn assembled unit onto its legs. Two persons required to avoid personal injury. 2011/04...
