Operating Your Unit
Converting to Sofa
Standing at the side of the unit (from bed position), lift backrest to the desired position and secure in
place by releasing to the sound of a click.
Converting to Lounger
In bed position, lift backrest upwards with each click sound until the desired lounge position is reached.
Converting to Bed
From sofa or lounge position, lift backrest all the way upwards until the last click is heard which unlocks
the mechanism and carefully return to a flat position.
4-4
© 2011 Dwell Home Inc. 2011/04
PUZZLE BODY
Your Puzzle unit comes in separate boxes. This box contains ONLY the body unit.
Depending on your unit, you will require two to three more boxes to complete assembly of
the sofa convertible - legs, upholstery cover and armrests (if applicable).
Please refer to the assembly instructions accordingly.
BODY
ARMRESTS (OPTIONAL)
OR
ADULT ASSEMBLY REQUIRED
If you are missing any parts or have any questions regarding assembly, do not return
this item to the retailers store. Please call our toll- free customer service number and
have this assembly manual open to the parts list ready to provide the model name,
and part name or number.
Customer Service
1-877-864-5752
8:30 AM PST - 4:30 PM PST (Monday - Friday)
Website: www.dwellhom.com
Missing Parts: parts@dwellhom.com
Warranty Information: www.dwellhom.com/warranty
WARNING: This Product contains small components, please ensure they are kept away from
small children.
Model:
Lot No:
Date of Purchased:
LEGS
OR
UPHOLSTERY COVER
