- Page 1 Repossi macchine agricole dal 1898 OPERATOR’S MANUAL Mod. 120/1 Mod. 145/1 Mod. 165/1...
-
Page 3: Table Of Contents
INDICE -1- Recommendations for work safety..........3 1.1 Defined use .................3 1.2 Spare parts .................3 1.3 Protection devices ..............4 1.4 Before starting work ..............4 1.5 Transport of persons ..............4 1.6 General ..................4 1.7 Cleaning the machine ..............5 -2- General guidelines for working with the Comb Rakes ....6 2.1 Safety guidelines.................6 2.2 Driving on public roads .............7 2.3 Important warnings ..............7... - Page 5 Dear Farmer, you have just made an excellent choice. Naturally we are very happy and wish to congratulate you for having chosen Re- possi. As your agricultural partner, we offer you quality and efficien- cy combined with reliable servicing. Please read thoroughly and comply with the information provided in this instruction book.
-
Page 6: 1- Recommendations For Work Safety
Before starting with operations check both implement and tractor for working and road safety. 1.1 Defined use a) The “REPOSSI” side delivery rake is intended solely for normal use in agricultural work: The swathing of forage, silage fodder and straw. -
Page 7: Protection Devices
The installation and/or use of such products can, therefore, nega- tively change or influence the construction characteristics of the appliance. We are not liable for damages caused by the use of components and accessories that have not been supplied by us. d) Alterations and the use of auxiliary parts that are not permitted by the manufacturer render all liability invalid. -
Page 8: Cleaning The Machine
Do not use high-pressure washers for the cleaning of bearing and hy- draulic parts. REPOSSI realized a rake compliant with safety requirements. Now depends from you a safe use of this machine, following the next instructions you will always work in safety conditions, you will have high performance and efficiency without failure. -
Page 9: 2- General Guidelines For Working With The Comb Rakes
-2- General guidelines for working with the Comb Rakes 2.1 Safety guidelines (See 1.1 – 1.3 – 1.4) All work in the immediate area of the rakes may only be carried out when the p.t.o. is switched off. Caution! Do not enter rake area while driving mo- tor is running. -
Page 10: Driving On Public Roads
2.2 Driving on public roads Observe the traffic regulations in force in your Country. Going on open roads may only be carried out as described in chapter “Transport position”. 2.3 Important warnings ADOPTED CONVENTIONS: Right side or Left side of the ma- chine are intended as the Right side and the Left side watching the machine from the rear ... -
Page 11: 3- Use Of The Machine
-3- Use of the machine 3.1 Assembling the machine The fitting is normally distributed with the combs on the top of the belt lowered and with the direction lever disassembled. To set up the fitting for use, follow the following instructions: 1) Fit the steering lever (A) in the housings provided, stopping it from sliding out with the cotter pin supplied (B). -
Page 12: Tractor Coupling
3.2 Tractor coupling (See 1.3 – 1.4 – 1.6) Before being used, the rake tedder must be lubricated by greasing (Vedi 4.5) Belt tension does not need any adjustment for start-up. However this must be checked after the first ten hours of operation to tighten any stretching. -
Page 13: For Travelling On Public Roads
3.3 For travelling on public roads Caution! Do not enter rake area while driving motor is running. For road haulage, proceed as follows: a) Lift the support stand (G); b) push in the side swath board (H) and stop it with the threaded han- dles;... -
Page 14: Changing From Transport To Operational Configuration
3.4 Changing from transport to operational configuration Raking The band runs horizontally and must be adjusted about 1÷2 cm above the ground so that fodder is raked up without causing excessive stress on mechanical parts. The swath board (H) must be widened and fitted in a position ade- quate for the amount of hay being raked. -
Page 15: Adjusting The Height Of The Tines
Tedding, airing The machine is adjusted always operating on the wheels (D) as showed in the picture. The swath board is removed in this case (H). CAUTION: The area surrounding the fitting during operation must be kept out of bounds to other people. Do not under any circumstances operate the hay rake tedder if the driver is not on his driving seat. -
Page 16: 4- Maintenance Of The Machine
-4- Maintenance of the machine Safety guidelines (See 1.6) 4.1 General Turn engine off when adjustment, service and repair work is to be done. In order to keep the implement in good condition after long peri- ods of operation, please observe the following points: - The machine must be accurately checked after the first five hours of operation. -
Page 17: Belt Tension
4.3 Belt tension To ensure the right working of the machine, act as follows: a. EVERY 150 WORKING HOURS: Verify the tension of driving belt (from central connection to band group) (O) and the tension of the two band belts (P); generally these belts slocken after sev- eral working hours. -
Page 18: Winter Storage
4.4 Winter storage Before winter proceed as follows: Clean the machine thoroughly. Check and re-tighten all nuts and bolts as necessary. Repair or renew all worn or damaged parts. Touch up paintwork as necessary. Protect the rake from the wear. ... -
Page 19: Lubrication Chart
4.5 Lubrication chart In the following lubrication chart all lubrication points are shown by dots or arrows. Suggested maintenance and lubrication intervals will ensure a long life for your machine. Operate a general grease every 20 working hours. Use the following grease and oil type: Lithium grease NGLI 2... -
Page 20: 5- Technical Data
-5- Technical data (Indicative data) Model 120/1 145/1 165/1 Working width (mm) 1050 1250 1450 Transport width (mm) 1200 1450 1650 Length (mm) 1000 1000 1000 Number of reels Number of tines for each reel Wheels 3.00-6 3.00-6 3.00-6 P.t.o. rpm... -
Page 21: 6- Warning Signs
-6- Warning signs ATTENTION, before using or repairing the machine, you have to read the maintenance book carefully. ATTENTION: the security distance of 5 meters from the work place must be re- spected. ATTENTION, all work in the immediate area of the rotor may only be carried out when the p.t.o. - Page 22 Following the policy of the REPOSSI s.r.l. to improve their products as technical developments continue, REPOSSI reserve the right to make alterations which must not necessarily correspond to text and illustrations contained in this publication, and without incurring obli- gation to alter any machines previously delivered.
- Page 24 A7 uscita Bereguardo Milano Milan Bereguardo Garlasco PAVIA Repossi macchine agricole Via V. Emanuele II, 40 - 27022 Casorate Primo (PV) - Italia Tel. **39 02 905 66 25 - Fax **39 02 905 13 08 e-mail: info@repossi.it - Web: www.repossi.it...
