Summary of Contents for ClodPi Labs ATOM Hub
-
Page 2: Table Of Contents
Ethernet Internet supply For ecological reasons, this guide has been not printed on physical paper! In order to provide the most updated technical documentation, as well as considering and saving the environmental resources, ClodPi Labs is providing preferably “Online documentation”. -
Page 3: Product Introduction - Atom Hub
2. Package Contents ClodPi Labs ATOM Hub For Home Assistant comes with below contents: ATOM Hub Device (preinstalled Raspberry Pi CM4 module) Power Adapter with power cord – two pole, Flat pin... -
Page 4: Know Your Device
3. Know your device... -
Page 5: Settings Guide And Usage
Sr No ITEM / LABEL QUANTITY DESCRIPTION Power supply – connect device using adapter 12V-DC Standard cable connection interface – allows to connect external module like Standard cable connection interface – allows to connect external module Ethernet Ethernet / Internet supply. *One needs to buy ethernet cable to connect the device with Home router Push button to reset the device Red LED - shows power status Blue LED - blinking shows activity status... - Page 6 c. Ethernet For wired ethernet connection, you need an ethernet cable to connect the router and the Ethernet connector jack located at the back side of the device. • Switch ON the power. • After connecting the power and Ethernet port, if the red light keeps on, it means the device is powered.
-
Page 7: Technical Specification
• Notice the Red and Blue LEDs on the device are ON • Take a laptop / smart phone • Connect it to the same network as your ATOM Hub device is connected to • On your Laptop / Smart phone, open a browser •... - Page 8 Bluetooth 5.0, BLE Integrated smart-home wireless (Silicon Labs MGM210P x 2): MGM210P - 1: Supports Zigbee 3.0 2.4 GHz radio with TX power up to +20 dBm 1024 KB flash program memory, 96 KB RAM data memory Pre-installed with Zigbee 3.0 firmware (EZSP), can be upgraded MGM210P - 2: Supports Open Thread and Matter 2.4 GHz radio with TX power up to +20 dBm...
-
Page 9: Caution
ClodPi Labs ‘ATOM Hub or Home Assistant’ is designed to work on Home Assistant Operating System [HAOS]. Before you decide to purchase and install Home Assistant compatible ClodPi's ATOM Hub device, please read through below information to understand Home Assistant, Hub and its nuances: •... -
Page 10: Manufacturer
Terms of Service Privacy Policy Shipping Policy Return and Refund Policy 11. Manufacturer: ClodPi Labs (India) Private Limited, 2nd floor, No.25 & 26, Vivekananda Nagar, Electronic City - Phase 1, Bengaluru, Karnataka, India - 560100 Website: www.clodpi.io | Email: sales@clodpi.io...
