ATTACH YOUR RECEIPT HERE
Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at +1 (866) 870-9930, 9 a.m. - 5 p.m., EST, Monday - Friday.
INSTRUCTION SHEET
20-inch Polypropylene
Surface Cleaner with Wheels
1
ITEM #5194342
MODEL #SGY-PWA1002
www.surfacemaxx.com

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SGY-PWA1002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SurfaceMaxx SGY-PWA1002

  • Page 1 ITEM #5194342 INSTRUCTION SHEET 20-inch Polypropylene Surface Cleaner with Wheels MODEL #SGY-PWA1002 ATTACH YOUR RECEIPT HERE Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at +1 (866) 870-9930, 9 a.m. - 5 p.m., EST, Monday - Friday.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Package Contents ........................Product Specifications ........................Introduction ..........................4 Safety Instructions ........................4 Installation & Preparation ..........................Operation ..........................Maintenance ..........................Troubleshooting .......................... 9 Replacement Parts List ......................10 PACKAGE CONTENTS www.surfacemaxx.com...
  • Page 3: Product Specifications

    Nozzle Cleaning Tool PRODUCT SPECIFICATIONS COMPONENT SPECIFICATIONS Connections 3/8 in. Quick Connect Inlet; 1/4 in. Quick Connect Outlet Maximum Pressure 4000 PSI Minimum Pressure 2500 PSI Maximum Water Flow 4.0 GPM Maximum Water Temperature 194 °F/ 90 °C Weight 29.7 lbs. www.surfacemaxx.com...
  • Page 4: Introduction

    3. Test the Surface Cleaner in an inconspicuous area. 4. Not to be used on vertical surfaces. INTENDED USE 1. The Surface Cleaner can be used with gas pressure washers from 2500 to 4000 PSI. 2. Use on horizontal surfaces like driveways, patios, sidewalks, etc. www.surfacemaxx.com...
  • Page 5: Installation & Preparation

    Push the handle fixing bolt Fixing Bolt through the aligned hole and tighten. (See Figure 3) Lower Handle Figure 3 4. Attach the inlet pressure hose to the handles. (See Quick Connect Plug Figure 4) Inlet Pressure Hose Figure 4 www.surfacemaxx.com...
  • Page 6 (See Figure 8) Quick Quick Connect Disconnect Plug Figure 8 9. Insert the quick disconnect of the pressure hose onto Quick Connect Plug the quick connect plug on the trigger. (See Figure 9) Quick Disconnect Figure 9 www.surfacemaxx.com...
  • Page 7: Operation

    1. Turn the pressure washer off. 2. Turn the water supply off. 3. Squeeze both trigger guns to relieve the water pressure. 4. Disconnect and drain the water inside the pressure hose. Wipe down the unit and store in a nonfreezing environment. www.surfacemaxx.com...
  • Page 8: Maintenance

    NOTE: If the nozzles continue to get clogged, you may want to consider adding an in-line filter. You can contact us at +1 (866) 870-9930 or email us at Support@surfacemaxx.com for more details. www.surfacemaxx.com...
  • Page 9: Troubleshooting

    3. Cleaning too fast. 3. Slow down pace. Water coming from 1. Internal issue with inlet assembly. 1. Contact customer service. weeping hole on the underside of the shroud. Water shooting from 1. Seal malfunction. 1. Contact customer service. swivel. www.surfacemaxx.com...
  • Page 10: Replacement Parts List

    Bridge Pin Handle Support Clevis Ring Bolt Bolt Water Broom Support Plate Quick Connect Plug U-type Bolt Spray Bar End Plug Quick Connector Spray Tip Bolt Wheel Bracket Bolt Wheel Plastic Housing Brush Skirt Locating Plate, Housing Spray Bar www.surfacemaxx.com...
  • Page 11 ARTÍCULO #5194342 HOJA DE INSTRUCCIONES Limpiador de superficies de polipropileno de 50,8 cm con ruedas MODELO #SGY-PWA1002 ADJUNTE SU RECIBO AQUÍ Fecha de compra ¿Preguntas, problemas, piezas faltantes? Antes de volver a la tienda, llame a nuestro Departamento de Servicio al Cliente al +1 (866) 870-9930, de lunes a viernes de 9 a.m. a 5.
  • Page 12: Contenido Del Paquete

    Especificaciones del producto ........................Introducción ..........................14 Instrucciones de seguridad .......................14 Instalación y preparación ......................Operación ..........................Mantenimiento ..........................Solución de problemas ....................... 19 Lista de piezas de repuesto ....................... 20 CONTENIDO DEL PAQUETE www.surfacemaxx.com...
  • Page 13: Especificaciones Del Producto

    Conexiones Entrada de conexión rápida de 3/8 pulg.; salida de conexión rápida de 1/4 pulg. Presión máxima 4000 PSI Presión mínima 2500 PSI Flujo de agua máximo 15,14 LPM Temperatura de agua máxima 90 °C/194 °F Peso 13,47 kg www.surfacemaxx.com...
  • Page 14: Introducción

    USO ESPECIFICADO 1. La limpiadora de superficies se puede usar con equipos de lavado con agua a presión a gasolina de 2500 PSI a 4000 PSI. 2. Use el equipo en superficies horizontales como entradas de garaje, patios, senderos, etc. www.surfacemaxx.com...
  • Page 15: Instalación Y Preparación

    (Consulte la Figura 3 figura 3) 4. Conecte la manguera de presión de entrada a las Enchufe de conexión rápida manijas. (Consulte la figura 4) Manguera de presión de entrada Figura 4 www.surfacemaxx.com...
  • Page 16 (Consulte la figura 8) conexión rápida rápida Figura 8 9. Inserte la desconexión rápida de la manguera de Enchufe de conexión rápida presión en el enchufe de conexión rápida del gatillo. (Consulte la figura 9) Desconexión rápida Figura 9 www.surfacemaxx.com...
  • Page 17: Operación

    2. Cierre el suministro de agua. 3. Apriete ambos gatillos de pistola para disminuir la presión del agua. 4. Desconecte y drene el agua dentro de la manguera de presión. Limpie la unidad y guárdela en un ambiente que no se congele. www.surfacemaxx.com...
  • Page 18: Mantenimiento

    NOTA: si las boquillas continúan obstruyéndose, es posible que desee considerar agregar un filtro en línea. Puede llamarnos al +1 (866) 870-9930 o enviarnos un correo electrónico a Support@surfacemaxx.com para obtener más detalles. www.surfacemaxx.com...
  • Page 19: Solución De Problemas

    1. Póngase en contacto con Servicio del orificio de ensamble de entrada. al Cliente. drenaje en la parte inferior de la cubierta. Disparo de agua 1. Mal funcionamiento del sello. 1. Póngase en contacto con Servicio desde la pieza al Cliente. giratoria. www.surfacemaxx.com...
  • Page 20: Lista De Piezas De Repuesto

    Placa de soporte de la escoba hidráulica Enchufe de conexión rápida Perno tipo U Barra de chorro Tapón terminal Conexión rápida Boquilla rociadora Perno Tuerca Abrazadera de las ruedas Perno Rueda Carcasa plástica Camisa de cepillo Placa de ubicación, carcasa Barra de chorro www.surfacemaxx.com...
