INSTRUCTION SHEET

15-in Pressure Washer Surface Cleaner

HEAVY DUTY STAINLESS STEEL CONSTRUCTION

ITEM #0936072

MODEL #SGY-PWA77

www.surfacemaxx.com

Table of Contents

Need help?

Do you have a question about the SGY-PWA77 and is the answer not in the manual?

Page 1 ITEM #0936072 INSTRUCTION SHEET 15-in Pressure Washer Surface Cleaner HEAVY DUTY STAINLESS STEEL CONSTRUCTION MODEL #SGY-PWA77 ATTACH YOUR RECEIPT HERE Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at +1 (866) 870-9930, 9 a.m. - 5 p.m., EST, Monday - Friday.
Page 2 PART DESCRIPTION QUANTITY 15-in Surface Cleaner PRODUCT SPECIFICATIONS COMPONENT SPECIFICATIONS Connections 1/4 in. Quick Connect Plug Deck Width 15 in. Maximum Pressure 4500 PSI Maximum Water Flow 3.5 GPM Maximum Water Temperature 140 °F/ 60 °C Weight 7.5 lbs. www.surfacemaxx.com...
Page 3 Make sure you hear a "click" sound when attaching the 1/4 in. quick connect plug to the quick connect coupler. 2. Pull the Surface Cleaner to make sure it is seated properly before operating your unit. www.surfacemaxx.com...
Page 4 Align the nozzle opening as shown in Figure 4. as spray bar Note: If your spray pattern begins to change, it could mean that the nozzles are worn and they will need to be replaced. Figure 4 www.surfacemaxx.com...
Page 5 Protection Ring Manifold Body Bearing Snap Ring Bottom Plate Brush PART DESCRIPTION Screw Spray Tip Shaft SS Shroud Snap Ring O-ring Washer O-ring Screw Locking Pin Wheel Support Bracket O-ring Screw Wheel Washer O-ring O-ring Spray Bar End Plug www.surfacemaxx.com...
