JohnsonSuisse Barossa Pivot Semi-frameless 900 Installation Manual

barossa
pivot - semi-frameless shower screen
INSTALLATION GUIDE
These installation guidelines are for to the following shower screens:
Model Door + Fixed Panel Set
Barossa Pivot
Semi-frameless 900
Actual size 860-885mm
Barossa Pivot
Semi-frameless 1000
Actual size 960-985mm
Barossa Pivot
Semi-frameless 1220
Actual size 1180-1205mm
IMPORTANT PRE-INSTALLATION NOTE:
• Immediately on receipt inspect the product for transit damage, missing packs/parts or manufacturing faults.
• Damage reported later cannot be accepted.
• Please handle the product with care avoiding knocks and shock loading to all sides and edges of glass.
• Damaged glass or missing parts will not be replaced under warranty if the installation process has begun.
• SAFETY GLASS CANNOT BE REWORKED, IF BROKEN IT HAS TO BE REPLACED
• Please read these instructions carefully before you start installation. Special care should be taken when drilling walls
to avoid hidden pipes or electrical cables.
• Securing into a stud or timber brace is highly recommended, if unable to do so, other secure means of fixing must
then be considered.
Return Panel Set
KSSPV26CHP SSPV26CHR
Actual size 860-885mm
KSSPV40CHP SSPV40CHR
Actual size 960-985mm
KSSPV34CHP
TOOLS REQUIRED
-
This product is heavy and awkward to handle.
Two-person installation is recommended.
1
