IMPORTANT
The packaging has a QR code
necessary for registration, and it may
contain smaller, overlooked items.
Do not discard until the installation
is complete.
This Guide contains several similar
install types for the same unit.
Each type is color-grouped. Consider
reducing the potential for confusion
by physically removing irrelevant
types from this document prior to
installation.
Clarity Solo Kit (STD)
»
Main power cable
MicroSD card (pre-installed)
»
»
ATOF 32 V / 2 A blade fuses x2
»
Fuse holders x2
Lens covers x2
»
»
Cable ties x2
HR003108A Windshield kit
»
Windshield mounting plate (with adhesive pad)
Cleaning wipe
»
»
Allen/Hex key (2mm)
»
EROAD Windshield sticker
I/O Port guard
»
Clarity Connected Kit
Everything in STD, + Windshield Kit, AND:
»
»
HR003101A 3-wire loom (No GPIOs), or
HR003100A loom, GPIO-ready, or
»
HR003105A loom, GPIO-ready, and/or
»
»
ECM Y-cable
Clarity Dashcams
EROAD
GPIO Remote Record Button kit
(HR003107A)
Remote Record button 2-wire attachment
»
»
Button O-ring
Mounting washer
»
»
Mounting nut
»
Cable ties x2
ATOF 32 V / 2 A blade fuse
»
»
Fuse holder
GPIO Remote Record button kit
(HR003106A)
Remote Record button 2-wire connector
»
»
12-2 wire loom
Button O-ring
»
»
Mounting washer
»
Mounting nut
Cable ties x2
»
»
ATOF 32 V / 2 A blade fuse
Fuse holder
»
There are no user-serviceable parts.
Installation Guide
Advertisement
Related Manuals for EROAD Clarity Dashcams
Summary of Contents for EROAD Clarity Dashcams
- Page 1 Clarity Dashcams Installation Guide EROAD IMPORTANT The packaging has a QR code necessary for registration, and it may contain smaller, overlooked items. Do not discard until the installation is complete. This Guide contains several similar install types for the same unit.
- Page 2 Dashcam Parts Windshield Cable Insert + cable mounting plate I/O Port guard Road camera Cab camera Road lens cap Cab lens cap Camera locking bolts Manual record CAUTION The Clarity cameras each have a RESTRICTED RANGE OF ROTATION. Do NOT attempt to rotate them with the locking bolts tightened, or past their tolerance limits (approximately 90°...
-
Page 3: Mounting The Dashcam
Mounting the Dashcam Clean the mounting area with the alcohol Press the MIDDLE of the mounting plate firmly wipe provided. into the windshield, working outwards, so the entire adhesive pad touches the windshield Re-wipe the area with a clean cloth to remove (you can better check this occasionally from any residue. - Page 4 3-wire Install Using the HR003101A Loom The diagram shows a basic connection for the Clarity Connected and Clarity Solo dashcams using the HR003101A 3-wire loom along with a basic Ehubo wiring diagram. If you are installing a Clarity Connected camera, your Ehubo is likely to be fused and connected already. RED wire fused to vehicle DC power.
- Page 5 Remote record button install (HR003106)- Optional Note 4 The 12-2 wire loom that comes with this remote button kit IS NOT USED for this install. Drill a 14 mm (0.55 in) diameter hole into a dashboard panel (or similar site within comfortable reach of the driver).
- Page 6 3-wire Install Using the HR003100A Loom (GPIO) The diagram shows a basic connection for the Clarity Connected and Clarity Solo dashcams using the HR003100A 12-wire loom along with a basic Ehubo wiring diagram. If you are installing a Clarity Connected camera, your Ehubo is likely to be fused and connected already. Red wire fused to vehicle DC power.
- Page 7 Remote record button install (Kit HR003107A) - Optional Drill a 14 mm (0.55 in) diameter hole into a dashboard panel (or similar site within comfortable reach of the driver). Ensure the O-ring remains near the head of the button-thread while removing the nut and washer. Thread the wires through the washer and nut.
- Page 8 Hybrid ECM Install Using the HR003105A Loom (GPIO) The diagram shows a basic connection for the Clarity Connected and Clarity Solo dashcams using the HR003105A 12-wire loom along with a basic Ehubo wiring diagram. If you are installing a Clarity Connected camera, your Ehubo is likely to be fused and connected already.
- Page 9 Unless this attached cable is another ECM Y-cable, detach it. If it is a Y-cable you could tap on to its free end and continue the chain. Insert the dashcam ECM Y-cable onto the free end of the existing ECM Y-cable.
- Page 10 Remote record button install (Kit HR003107A) - Optional Drill a 14 mm (0.55 in) diameter hole into a dashboard panel (or similar site within comfortable reach of the driver). Ensure the O-ring remains near the head of the button-thread while removing the nut and washer. Thread the wires through the washer and nut.
- Page 11 Full ECM Install (non GPIO) The diagrams show a basic connection for the Clarity Connected and Clarity Solo dashcams using a full ECM connection. A basic Ehubo wiring diagram is also shown. If you are installing a Clarity Connected camera, your Ehubo is likely to be fused and connected already. »...
- Page 12 Unless this attached cable is another ECM Y-cable, detach it. If it is a Y-cable you could tap on to its free end and continue the chain. Insert the dashcam ECM Y-cable onto the free end of the existing ECM Y-cable. Ensure the cables are twist-locked and/or secured firmly.
- Page 13 Remote Record Button install (Kit HR003106A) - Optional Drill a 14mm (0.55in) diameter hole into a dashboard panel (or similar site within comfortable reach of the driver). Connect the 12-way connector on the main camera power cable to the HR003106A Kit (12-to-2 wire loom).
-
Page 14: Install Wizard
Note 16 If unable to use QR codes, go to: Tighten BOTH the camera locking bolts. https://install.eroad.com. Once the unit has passed its tests, attach the I/O port guard to the mounted unit using an Open a browser on your mobile device Allen key. - Page 15 Note the vehicle make/model for future reference. NOTE Photos are evidence of a compliant install. They protect EROAD and the Installer’s liability if a future 3rd party alteration or incident affects compliance integrity. General Purpose In/Out (GPIO) About Engine Control...
-
Page 16: Specifications
Equipment (PPE) for the install risk and are not invulnerable to water, fire or impact customer requirements. Appropriate PPE damage. Do not subject EROAD units to may include safety glasses, safety shoes, work extreme heat, water force or intense forces.
