ASSEMBLY AND USAGE INSTRUCTIONS INSTRUKCJA MONTAŻU I UŻYTKOWANIA for Photovoltaic Module konstrukcji wsporczej Support Structure dla modułów fotowoltaicznych FWD1 HBM FWD1 HBM 3x2 3x1 3x2 3x1...
Page 2
Assembly Kit Components Component Name Description 3x2 layout 3x1 layout FWD1 HBM SP Front post L2420 2 pcs. L2420 1 pcs. Fig. 2.1 FWD1 HBM ST Rafter L3353 2 pcs. L3353 1 pcs. Fig. 2.2 FWD1 HBM K Purlin L3615 2 pcs. L3615 1 pcs.
Page 3
Stock Issue Confirmation or on any other equivalent document, on which comments regarding the product, provided there are any, should be written down. 3. Assembly The assembly is to be conducted in accordance with the instructions issued by Budmat. Recommended tightening torques during the assembly: •...
Page 4
7. When working with Magnelis-coated profiles, comply with OHS regulations at all times. Transport and unloading 1. The profiles should be transported in their original Budmat steel packaging. 2. The vehicle transporting Magnelis-coated profiles should be adapted to this kind of transportation. The loading, unloading and proper fastening of the goods for the time of transport should be made easy for the person carrying out these activities.
Page 5
LAYOUTS OF STEEL SUPPORTS DRIVEN/CONCRETED INTO THE GROUND (SP / ST) UKŁADY STALOWYCH PODPÓR WBIJANYCH / BETONOWANYCH W PODŁOŻE (SP / ST) Post positioning – Wind rose Post Rys. 1 Fig. 1 3X2 Layout 3X1 Layout Rear post Rear post Front post Front post Rys.
Page 6
RAFTER ASSEMBLY (R) MONTAŻ KROKWI (K) Post positioning – Wind rose Post 3X2 Layout 3X1 Layout Rys. 3 Fig. 3 Miejsca łączeń krokwi z słupem (elementy łączne tabela punkt 11) Rafter-post connection points (Connecting components: Table, no. 11) Rys.4 Fig. 4 MONTAZ PŁATEW (P) S t r o n a...
Page 7
3X2 Layout 3X2 Layout Rys. 5 Fig. 5 3X2 Layout 3X1 Layout Rys.6 Fig. 6 MONTAŻ PANELI FOTOWOLTAICZNYCH S t r o n a...
Page 8
3X2 Layout 3X1 Layout Rys. 7 Fig. 7 A - ŁĄCZENIA KLEM KOŃCOWYCH A – END CLAMP CONNECTIONS Rys. 8 Fig. 8 S t r o n a...
Page 9
B – ŁĄCZENIA KLEM ŚRODKOWYCH B – MID CLAMP CONNECTIONS Rys. 9 Fig. 9 MOCOWANIE TĘŻNIKÓW BRACE ASSEMBLY Rys. 10 Fig. 10 MOCOWANIE FALOWNIKA INVERTER MOUNTING S t r o n a...
Page 10
Rys. 11 Fig. 11 TABLE CONNECTION ŁĄCZENIE STOŁÓW Stół 3x2 jest stołem bazowym do niego dołączamy stół 3x1 3x2 Table is the base table. A 3x1 table is connected to it. 10 | S t r o n a...
Page 11
WIDOK 1 VIEW 1 WIDOK 2 VIEW 1 11 | S t r o n a...
Page 13
FWD1 HBM Date of Sale by the Warrantor Data sprzedaży przez Gwaranta Warrantor’s Seal Pieczęć Gwaranta ul.Ziejkowa 2A 05-900 Gostynin systemypv@budmat.com Podpis i pieczęć instalatora oraz data montażu Installer’s Seal and Signature with Assembly Date Dane Uprawnionego z Gwarancji Warrantee’s Data...
Warrantor The enterprise Budmat. Bogdan Więcek, 09-407 Płock, ul. Otolińska 25, Poland, NIP [Tax ID] 774-001-50-83, provides a warranty, hereinafter referred to as “the Warranty”, on freestanding support structure components for photovoltaic modules (hereinafter referred to as “Structure Components”).
17. Complaints under this Warranty shall be filed immediately after the discovery of a defect covered by the Warranty. The filing shall be made in writing, within 14 days of the day of the discovery, and sent by e-mail to reklamacje@budmat.com, or by letter to Budmat.
Page 16
Warranty Card Date / Seal and Visual Structure Owner’s Seal and Inspection Period Inspection Date Screw Force Signature of Authorised Assessment Cleanliness Signature Service Provider Assembly Confirmation Within 12 Months of Assembly Date Within 24 Months of Assembly Date Within 36 Months of Assembly Date Within 48 Months of Assembly Date...
