- Page 1 ® WALLACE & TIERNAN DIAPHRAGM PULSATION DAMPER INSTRUCTION MANUAL...
- Page 2 Diaphragm pulsation damper Please note Original manual! WT.470.600.010.DD.IM.0714...
-
Page 3: Table Of Contents
Diaphragm pulsation damper Contents Contents Introduction Documentation 1.1.1 Target groups Conventions Safety Intended use General safety instructions Handling chemicals 2.3.1 Prevention of risks 2.3.2 First aid measures 2.3.3 Environmental protection measures Description General Technical data Scope of supply 3.3.1 Pulsation damper 0,08 l with connections 3.3.2 Pulsation damper 0,25 l with connections 3.3.3... - Page 4 Diaphragm pulsation damper Contents WT.470.600.010.DE.IM.0714...
-
Page 5: Introduction
Diaphragm pulsation damper Introduction 1. Introduction Documentation 1.1.1 Target groups This instruction manual provides the responsible personnel with information that is required for the installation, operation and maintenance of the diaphragm pulsation damper. It contains information that is important to the secure, fault-free, and economical operation of the diaphragm pulsation damper. -
Page 6: Conventions
Diaphragm pulsation damper Introduction Conventions Notes This operating manual contains a number of notes with different priorities, which are marked with symbols. Picto- Note Meaning gram Warning! Danger to life and limb! If the situation is not handled properly, death or serious injury may be the result. -
Page 7: Safety
Diaphragm pulsation damper Safety 2. Safety Intended use The diaphragm diaphragm pulsation damper is intended to dampen pressure peaks and pulsations. Maximum pressure is 10 bar (g). The operational safety of the system can only be guaranteed if it is used in accordance with its intended purpose. -
Page 8: General Safety Instructions
Diaphragm pulsation damper Safety General safety instructions Siemens attaches great importance to the safety of all work relating to the diaphragm pulsation damper . This was already taken into account in the design of the system, by the integration of safety features. Safety instructions The safety instructions in this documentation must always be observed. - Page 9 Diaphragm pulsation damper Safety Spare parts / components The trouble-free operation of the diaphragm pulsation damper can only be guaranteed, if original spare parts and components are used in the combination described in this instruction manual. Otherwise there is a danger of malfunction or damage to the system.
-
Page 10: Handling Chemicals
Diaphragm pulsation damper Safety Handling chemicals Warning! Chemical hazard! For safe operation and to prevent harm to persons, be sure to follow the safety instructions and warnings by the supplier, on the system and in this instruction manual. Everyone involved must be informed about the dangers arising from fluids in the system and the connected pipes, and be instructed regarding the first aid measures to be employed. -
Page 11: Prevention Of Risks
Diaphragm pulsation damper Safety 2.3.1 Prevention of risks The following applies to all substances: • Avoid all contact. Wear protective clothing. • Do not open any covers while the system is preparing the product • Only work on the pipes when the system has been emptied and rinsed. - Page 12 Diaphragm pulsation damper Safety WT.470.600.010.DE.IM.0714...
-
Page 13: Description
Diaphragm pulsation damper Description 3. Description General Piston and membrane metering pumps produce pressure variati- ons in the discharge line. Diaphragm pulsation dampers are used to flatten the pressure peaks and to reduce the pressure variati- ons. The diaphragm pulsation dampers with separating diaphragm de- scribed here do not exceed the limit described in the pressure equipment directive (PS x V = 25 bar x liters). -
Page 14: Technical Data
Diaphragm pulsation damper Description Technical data Part no. W3T160469 W3T160464 W3T164397 W3T164398 W3T164399 W3T164400 Volume 0,08 l 0,08 l 0,25 l 0,25 l 0,75 l 0,75 l Diaphragm Hypalon Viton Hypalon Viton Hypalon Viton Body PVC-U Operating pressure max. 10 bar (g) Pre-pressure max. -
Page 15: Scope Of Supply
Diaphragm pulsation damper Description Scope of supply 3.3.1 Pulsation damper 0,08 l with connections Part number incl. pulsation Connections damper for pvc hose for pvc tube thread W3T172565 W3T160469 ID 10 x 3 DN10/d16 DIN 228 - G 3/4 A (CSM) ID 6 x 3 DIN 228 - G 1/2 A... -
Page 16: Pulsation Damper 0,25 L With Connections
Diaphragm pulsation damper Description 3.3.2 Pulsation damper 0,25 l with connections Part number incl. pulsation Connections damper for pvc hose for pvc tube thread W3T172569 W3T164397 DN15/d20 DIN 228 - G 1 1/4 A (CSM) DN20/d25 W3T172570 W3T164398 (FPM) 3.3.3 Pulsation damper 0,75 l with connections Part number incl. -
Page 17: Installation
Diaphragm pulsation damper Installation 4. Installation Mounting In order to dampen pressure peaks and pulsations perfectly dia- phragm pulsation dampers have to be installed correctly. There- fore it is necessary to mount them very close to the point where pressure peaks are produced. For metering pumps, this place would be right after the discharge valve, using a tee-fitting or direct flow through the diaphragm pul- sation damper. -
Page 18: Filling
Diaphragm pulsation damper Installation Filling Warning! Danger of ignition Use air for filling the diaphragm pulsation damper. Never use oxygen! The diaphragm pulsation damper is most effective if the initial pressure is about 0.6 times the final average operating pressure. It is suitable to have a pressure gauge permanently installed at the diaphragm pulsation damper (W3T158497). -
Page 19: Operation
Diaphragm pulsation damper Operation 5. Operation Check Warning! Chemical hazard! Leaks can release chemicals that can cause chemical burns. Wear protective clothing. Follow the safety instructions and warn- ings on the system or on the product and in this instruction manual. Consult and follow the EC safety data sheets. -
Page 20: Filling
Diaphragm pulsation damper Operation Filling Warning! Chemical hazard! Leaks can release chemicals that can cause chemical burns. Wear protective clothing. Follow the safety instructions and warn- ings on the system or on the product and in this instruction manual. Consult and follow the EC safety data sheets. Danger of ignition Use air for filling the diaphragm pulsation damper. -
Page 21: Maintenance
Diaphragm pulsation damper Operation ning volume remains too small although the gas pressure can be brought up to the desired level. By interrupting the liquid flow, the gas pressure is able to displace the liquid and optimally fill the gas chamber. -
Page 22: Spare Parts
Diaphragm pulsation damper Operation Assembly: 1 Insert the new separating diaphragm so that the ends project the same distance on both sides. 2 Push one sealing cone with the support pipe through the sepa- rating diaphragm and place the second cone against it. 3 Fasten flanges / union nuts evenly after pressing the sealing cones mechanically against each other (using e.g. - Page 23 Diaphragm pulsation damper...
- Page 24 All information presented herein is believed reliable and in accordance with accepted engineering practices. Evoqua makes no warranties as to the completeness of this information. Users are responsible for evaluating individual product suitability for specific applications. Evoqua assumes no liability whatsoever for any special, indirect or consequential damages arising from the sale, resale or misuse of its products.
