MODEL
ESP-J & ESP-JV
INSTALLATION,
OPERATION
& MAINTENANCE
MANUAL
Central Air Conditioning Series
2 to 5 Tons
Fan Coil Unit/Air Supply
Components
SpacePak System Design........................................
Code Compliance.....................................................
Air Distribution Requirements...................................
Model Number Description.......................................
Air Distribution Components.....................................
High Altitude Guidelines............................................
Shipment of Unit.......................................................
Step 1: Locating The Unit.........................................
Step 2: Cutting Return Air Opening..........................
Step 4: Setting The Unit............................................
Step 9: Wiring The Unit..............................................
Layouts.................................................................
IN UNITED STATES: 260 NORTH ELM ST. WESTFIELD, MA 01085 (413) 564-5530/FAX (413) 564-5815
IN CANADA: 7555 TRANMERE DRIVE, MISSISSAUGA, ONTARIO, L5S 1L4 (905) 670-5888/FAX (905) 670-5782
Controls Overview................................................
2
System Commissioning.......................................
2
2
Charging Cooling Only Systems..........................
2
3-6
6
Before Each Cooling Season................................
6
If System Fails To Operate....................................
Troubleshooting Guide..........................................
Troubleshooting Flow Charts................................
7
Service/Troubleshooting Form..............................
10
Parts List...............................................................
10
11
WARRANTY INFORMATION.................................
12
13-17
13-17
17,18
19
20-24
ESPJ2-0323
45W30-WG1283
26-36
37
37
38
39
39
40, 41
42-45
46
47,48
49
