Instruction Manual
FY-2200W
Our equipment is approved by the following car manufacturers

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FY-2200W and is the answer not in the manual?

Questions and answers

Summary of Contents for FY-TECH FY-2200W

  • Page 1 Instruction Manual FY-2200W Our equipment is approved by the following car manufacturers...
  • Page 2: Table Of Contents

    Contents 1. Precautions 2. Specifications 3. Installation 4. Controls 5. Operation 6. Troubleshooting 1) Troubleshooting 2) Lamp Tube Replacement 7. Exploded View 8. Circuit Diagram...
  • Page 3: Precautions

    1. Precaution 1. Read this manual carefully before installing or servicing this equipment. 2. This equipment is designed for paint drying applications. Adjust to the correct temperature and check minimum safe distance from heat source when using. Improper use can cause paint surface damage. 3.
  • Page 4: Specifications

    2. Specifications Model FY-2200W Input Power Source Single Phase 220V 50/60Hz 2 × 1000 Input Power (W) Curing Area (mm) 800 × 1000 Temperature (°C) 35 - 80 Time Setting 0 - 99mins Adjustable Light Intensity (%) 10 - 100...
  • Page 5: Installation

    3. Installation The shortwave infrared curing lamp is divided into 3 parts (a base, a column and a cassette). 1) Installation of the base. a. Open the packing of the base. b. Install the four wheels on the base respectively and tighten up the screws. Usually, the wheels with brakes should be mounted on the rear of the base.
  • Page 6: Controls

    4. Controls OPERATING VOLTAGE AC200-230V 50/60Hz POWER CONTROL SYSTEM TIME CONTROL SYSTEM 1. Operating Voltage 2. Lamp Selector 3. Power Adjustment 4. Time Adjustment Cir c u i t b r e aker m ust b e i nsta l l e d Page 4...
  • Page 7: Operation

    5. Operation Connection of electrical supply. Make sure that the supply cable is at least 4mm at 220V. Note: Make sure that the facility supply voltage and frequency are the same as shown on the equipment name plate. Connect to power supply of AC 220V. Switch on the equipment. The LED display will show the normal voltage as 220V.
  • Page 8: Troubleshooting

    6. Troubleshooting 1. Troubleshooting CAUSE SOLUTION PROBLEM 1) Lamp tube damaged 1) Check lamp tube Lamp tube does not work 2) Lamp tube not plugged in 2) Check connections 3) Check control silicon 3) Control silicon damaged Lamp tube does not turn off 1) Control silicon damaged 1) Check control silicon 1) Unplugged flat wire in circuit...
  • Page 9: Lamp Tube Replacement

    6. Troubleshooting 2. Lamp Tube Replacement 1. Prepare cassette for replacement 2. Remove the grille of cassette 3. Remove the plates from both ends of the cassette 4. Remove the fixed plates from both ends of the cassette 5. Loosen fixed screws and cut off connections, the lamp can be replaced 6.
  • Page 10: Exploded View

    7. Exploded View Name Name Name Upright post Plastic nut Front wheel Connecting axle Base Top cover Back wheel Bottom cover of connector Plastic band Handle Cover plate (lower) Connector Lower connecting rod Flange Top cover of connector Control silicon Upper connecting rod Bracket Lifter...
  • Page 11: Circuit Diagram

    8. Circuit Diagram Page 9...
