maxx
Wiring & Installation
Instructions
#896097

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the proxSafe maxx and is the answer not in the manual?

Questions and answers

Summary of Contents for Deister electronic proxSafe maxx

  • Page 1 maxx Wiring & Installation Instructions #896097...
  • Page 2 GmbH. deister electronic GmbH reserves the right to make changes to any and all parts of this documentation without obligation to notify any person or entity of such changes.
  • Page 3: Table Of Contents

    Contents 1. Technical Data ............. 4 2. proxSafe maxx Delivery ..........5 3. proxSafe maxx Installation ......... 6 3.1 Installation of proxEntry Reader ................. 6 3.2 Prepare Terminal for left-side mounting ............. 7 3.3 Open Cabinet ....................9 3.4 Mount Terminal to Cabinet ................
  • Page 4: Technical Data

    1. Technical Data Dimensions (mm): 513 x 600 x 210 Housing: sheet metal, powder coated ASA, PC Weight: approx. 26 kg Operating temp.: -5...50 °C, for indoor use, non-condensing Closing force of roller shutter: max. 30 N Power supply: 13.8 V/DC, max.
  • Page 5: Proxsafe Maxx Delivery

    2. proxSafe maxx Delivery Before you start installation of your proxSafe system, please carefully check that you have received all components that are listed on your delivery note. The Cabinet package contains: • the proxSafe cabinet • 2 keys for opening the cabinet •...
  • Page 6: Proxsafe Maxx Installation

    3. proxSafe maxx Installation Installation of proxEntry Reader If your system includes a proxEntry card reader, then this reader has to be installed into proxSafe terminal: Attention: The following instructions are solely intended for installing a reader into a...
  • Page 7: Prepare Terminal For Left-Side Mounting

    Close the terminal housing and fix the two Put the two screw covers in place. housing screws. Prepare Terminal for left-side mounting The terminal is delivered for mounting on the right side of the cabinet. If you want to mount the...
  • Page 8 Now turn the base plate of the terminal Remove the four screws, which hold the bracket half way around so that the curved base plate of the bracket to the back of the slot is facing towards the left side (when terminal.
  • Page 9: Open Cabinet

    Open Cabinet For the further steps of installation you need to open the proxSafe Cabinet. You find the key for opening the cabinet Slide down the key covering and open the lock. attached to the cabinet. Carefully move the cabinet insert towards Unplug the connection cable between the you.
  • Page 10 Unhook the red safety-wire Now you can fully remove the cabinet insert. Carefully push open the roller shutter. You can now remove the packages with the accessories: - 32 keyTags - 32 keyRings - 50 pairs of one-time seals - 2 cabinet connection cables.
  • Page 11: Mount Terminal To Cabinet

    Mount Terminal to Cabinet The cabinet is supplied for right-side mounting. If you want to mount the Terminal on the left side of the cabinet, please make sure before that the cable length is sufficient. If not, please contact your dealer in order to obtain the correct cables.
  • Page 12: Operating Cabinet Without Proxsafe Terminal

    Operating Cabinet without proxSafe Terminal In case the proxSafe Cabinet should be operated without the proxSafe Terminal, pay attention to the following steps: 3.5.1 Install Communication Adapter (e.g. SNG3) In case of operation without the proxSafe Terminal the communication adapter (e.g.
  • Page 13: Install Ethernet Adapter

    Install Ethernet Adapter There are two types of Ethernet adaptors, which can be supplied with the proxSafe maxx: Digi Connect ME Adapter, see instruction in paragraph 3.6.1 ● MOXA N-Port Adapter, see instruction in paragraph 3.6.3 or ●...
  • Page 14: Install Digiconnect Adapter

    3.6.1 Install DigiConnect Adapter The DigiConnect adapter is supplied on a Remove the cables from the backplane PCB piggyback PCB and can be mounted on and loosen the backplane PCB by carefully the backplane PCB. pressing the clip on the plastic studs with a screw driver.
  • Page 15 Return the backplane PCB to its position and Connect the network cable into the carefully click it back on the plastic studs. DigiConnect. Jumper Settings for DigiConnect Adaptor Set the jumpers as per this drawing. V08/07/09 ps_maxx_wi_en...
  • Page 16: Install Usb-Serial-Converter Sng3

    3.6.2 Install USB-Serial-Converter SNG3 If your system includes a USB adapter, you can connect this adapter as follows: Set both dip switches on the adapter to Connect as follows: position “ON”. a) “proxSafe” to backplane “ISO PC” b) USB Connector to PC...
  • Page 17: Install Moxa N-Port Adapter

    3.6.3 Install MOXA N-Port Adapter Put the dip switches on the adapter housing Mount the TCP/IP adapter into the cabinet to the following positions: frame below the cable slot. Use the two switch 1: OFF screws from the enclosed cable set switch 2: ON package.
  • Page 18 Now you can connect your network cable to the Ethernet adapter (plug “Ethernet”). Jumper Settings for TCP/IP Converter (i.e. Moxa DE-311) Set the jumpers on the backplane as per this drawing. ps_maxx_wi_en V08/07/09...
  • Page 19: Install Power Supply And Back-Up Battery

    Install Power Supply and Back-up Battery Your proxSafe system needs a supply voltage of 13.8 V in order to charge the battery during operation. If the battery is not operated, you can supply the system with 12 V DC.
  • Page 20: Install/Activate Tamper Switches

    Install/Activate tamper switches The insert of the proxSafe maxx Cabinet is equipped with two tamper switches (see also 3.11 „Close Cabinet“, picture 1). The left tamper switch is independent (potential-free) from the Cabinet Software and the Cabinet power supply. For this one you will find the...
  • Page 21: Mount Cabinet To The Wall

    3.10 Mount Cabinet to the Wall For a first adjustment of the cabinet to the wall, please use the provided wall hooks (see drawing). Mount them to the wall and hook in the cabinet. For the final wall assembly use the prefabricated boreholes.
  • Page 22: Close Cabinet

    3.11 Close Cabinet These are the final steps before you can operate your new cabinet. Remove the safety tape from the tamper Position the cabinet as shown. switch on the back of the cabinet insert. Re-attach the red safety-wire.
  • Page 23: Assembling A Proxsafe Keyring

    Make sure that the locking spring on the Tightly push in the lock and remove the key. right side glides completely back into the frame while pushing the cabinet insert back into the cabinet! 4. Assembling a proxSafe keyRing For a proxSafe keyRing you need one ring, Put one or more keys on the keyRing.
  • Page 24 Place the keyring into the keyTag. Put one of the seal plugs into one side of the keytag hole. Put the other seal plug into the opposite side Push the seal plugs together until they lock of the keytag hole.
  • Page 25: Commissioning Of The Proxsafe System

    • With each cabinet you see the number of connected proxCylinders per row. For proxSafe maxx this should always be “8 8 8 8”. Note: This message may only be correct after full commiss- ioning of your proxSafe cabinet.
  • Page 26: Creating An Administrator Card

    Creating an Administrator Card After the self-test the terminal shows the following screen: Now please present one of your proximity cards to the card-reader. deister electronic Present Card Mo 01.01.01 12:12:12 0-9:PIN :History (Note: depending on your system...
  • Page 27: Addressing Of Cabinets

    Addressing of Cabinets After creation of the administrator card, the terminal starts the cabinet addressing procedure. If you operate only one cabinet with your terminal, you can skip this procedure by pressing the red key <C>. The terminal will then continue with the teach-in of the keyTags.
  • Page 28: Teach-In Of Keytags

    Teach-in of keyTags Now the system is ready to teach-in your keyTags. The first cabinet will open and show the following screen. Now please insert all your keyTags into the slots of the open cabinet. Once you have...
  • Page 29: Emergency Opening Of Roller Shutter

    6. Emergency Opening of Roller Shutter If normal operation failed (e.g. power failure, damaged shutter motor etc.), the roller shutter can be opened by hand. In this case the Cabinet has to be opened (see first steps in 3.3 Open Cabinet) and the insert has to be carefully pulled forward out of the frame.
  • Page 30: Regulatory Notices

    8. Regulatory Notices Hereby, deister electronic declares that the radio equipment type maxx is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://go.deister.com/ce Approved for use in all European countries.
  • Page 31 Notes: V08/07/09 ps_maxx_wi_en...
  • Page 32 Fax: +32 (0) 15 – 48 02 16 Tel.: +81– (0)3 – 4540 – 1350 info.be@deister.com Fax: +81– (0)3 – 4540 – 1000 info.jp@deister.com France: deister electronic France SARL Americas and Caribbean: 15 avenue du Québec Deister Electronics USA, Inc. Bâtiment STERNES 2 8576 Wellington Road...
