Shishido Electrostatic CABX350 Manual

THREE COMMITMENT FROM SHISHIDO
Develop "AC" + "Shock-less" ionizer.
Superior ion balance
●
Long-term stability
●
Shock-free
●
Ordinary ones...
Require constant cleaning and maintenance.
In general, the emitter needle requires cleaning every few weeks
to several months
Filter: New
Emitter Needle:
After 3months
With SSD HDC-AC technology, the new ionizer does not require
cleaning over the long-time. HDC-AC ionizer have "Breaking-time" as
non discharging time. It makes less damage onto the discharge emitter.
2
Long-term Stability in Ionizing
Minimize the impact from the
●
dust on the emitter needle
Minimize the impact from the
●
abrasions of emitter needle
Magnified photo on emitter needle
After 4000H
Filter: After 3 months
Quick Cleaning
Cleaned by IPA
Emitter Needle: Magnified x 300
After cleaning
AC 60Hz
AC 50Hz
AC 33Hz
HDC-AC 200Hz
Characteristic Decay Time（Running：4000 hours）
8
7
6
5
4
3
2
1
0
0 500 1000 1500
The white crystals such as silica
(SiO2) and ammonium nitrate
(NH4NO3) adheres to the tip of the
emitter needle even being used in
the clean room (shown on the right).
Reluctant in maintenance could
cause contamination due to the fall
off of accumulated particles.
* Prolong cleaning intervals
* Substaintially decreased on the abrasions
of emitter needle
* Minimum ozone production
Long-term Maintenance-Free
Prolong cleaning intervals for
●
the filter and emitter needle
(+)Decay Time
(-)Decay Time
2000 2500 3000 3500
Running Time(h)
4000
