- Page 1 Addressable fire alarm sounder SPP-400 Firmware version 1.00 spp-400_en 02/23 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
- Page 2 IMPORTANT The device should be installed by qualified personnel. Prior to installation, please read carefully this manual in order to avoid mistakes that can lead to malfunction or even damage to the equipment. Disconnect power before making any electrical connections. Changes, modifications or repairs not authorized by the manufacturer shall void your rights under the warranty.
-
Page 3: Installation
The SPP-400 indoor sounder is used for acoustic alarm signaling. It is designed to operate in the detection line of the ACSP-402 addressable fire alarm control panel. 1. Features Acoustic signaling by means of piezoelectric transducer. Signaling controlled by the control panel: –... - Page 4 SPP-400 SATEL 8. Connect the detection line wires to the sounder (Fig. 5 – loop; Fig. 6 – radial circuit). To terminals A+ and A-, connect the wires from the control panel / previous device. Connect the wires to terminals B+ and B- to connect the sounder to the next device /...
- Page 5 SATEL SPP-400 connect the wires to terminals B+ and B- (Fig. 6). Connect the cable shields to the E / terminals. 9. Replace the cover and turn it clockwise (Fig. 7). 10. Lock the cover with a screw (Fig. 8).
-
Page 6: Acoustic Signaling
SPP-400 SATEL 3. Acoustic signaling Configure the acoustic signaling settings in the control panel. For each alarm condition you can select one of the 32 available tones (see: Table 1). - Page 7 SATEL SPP-400 Acoustic signaling Frequency Hz Description 2 Hz (250 ms – 250 ms) 800 & 970 800-970 7 Hz (7/s) 800-970 1 Hz (1/s) 2850 Continuous 2400-2850 7 Hz 2400-2850 1 Hz 500-1200 3 s sound, 0.5 s silence, repeated...
- Page 8 SPP-400 SATEL Angle-dependent [°] minimum sound level [dBA] Tone / supply voltage 15° 45° 75° 105° 135° 165° 5 / 26 VDC 76.2 84.6 86.5 87.1 84.9 76.0 6 / 18 VDC 78.0 86.7 88.0 86.8 85.1 75.8 6 / 26 VDC 77.5...
-
Page 9: Maintenance
The fire alarm system elements require regular maintenance. The periodic checks of the SPP-400 sounder should be carried out at least every 6 months. In spaces where working conditions are difficult (e.g. dust, aggressive environment that may cause corrosion, etc.), the periodic checks should be carried out more often. - Page 10 SPP-400 SATEL The SPP-400 fire alarm sounder conforms to the essential requirements of the EU Regulations and Directives: CPR 305/2011 Regulation of the European Parliament and of the Council of 9 March 2011 laying down harmonized conditions for the marketing of construction products and repealing the Council Directive 89/106/EEC on construction products;...
