Black & Decker PERFORMANCE HELIX MX610 Series Use And Care Manual

P E R F O R M A N C E H E L I X H A N D M I X E R
T M
B A T I D O R A D E M A N O H É L I C E
P E R F O R M A N C E
u se and c are m anu al
m a nual d e us o y cu id ad o
M X6 10 Se rie s
MX610B
MX610T
MX610P
MX610M
MX610W
MX610R
PARTS AND FEATURES
1
4
1. Storage case 6. Easy eject feature
2. Dough hooks 7. Mixer body
3. Whisk 8. Heel and bowl rest
4. Helix beaters 9. Turbo boost button
TM
5. Speed wheel
Product may vary slightly from what is illustrated.
WHAT SPEED TO USE
1 (Low) 2 (Low/Med) 3 (Medium)
Stir Combine Mix
Combining dry and Preparing puddings; Creaming butter and
wet ingredients. mixing dough or thin sugar; mixing cake
Adding to mixtures: batter. batters and frostings.
nuts, dried fruits,
chocolate chips.
HOW TO CLEAN
Wipe mixer body with damp cloth and dry thoroughly with a dry cloth. Wash attachments in warm water
with dish detergent, or on the top shelf of the dishwasher.
STORAGE
Store all attachments and power cord in the storage case. Insert bottom of mixer into case and snap
together for storage.
MX610_29298_ES_IB_G.indd 1 MX610_29298_ES_IB_G.indd 1
CAB: Document setup: 420mm width x 560mm height
Customer Care Line: 1-800-465-6070
For online customer service:
www.prodprotect.com/blackanddecker
Línea de Atención del Cliente: 1-800-465-6070
Para servicio al cliente en línea:
www.prodprotect.com/blackanddecker
5 , 6 9
Off
2
3
8
9
7
GETTING STARTED
• Remove all packing material, any
stickers, and the plastic band around
the power plug.
• Remove and save literature.
• Please go to www.prodprotect.com/
blackanddecker to register your
warranty.
• Wash all removable parts.
4 (Med/High) 5 (High) TURBO
(high speed burst)
Blend Beat/Whip
Beating whole eggs Whipping cream and Use at any speed
or frozen desserts; egg whites; mashing setting to get
mixing light batter, potatoes. maximum power for
such as for popovers. tough mixing tasks.
When using electrical appliances, basic safety precautions should always be followed, including the following:
• Read all instructions.
• To protect against risk of electrical shock do not immerse cord, plugs or
appliance in water or other liquid.
• Close supervision is necessary when any appliance is used by or near children.
• Turn the appliance OFF. Then unplug it from the outlet: when not in use,
before assembling or disassembling parts, and before cleaning.
To unplug appliance, grasp the plug and pull it from the outlet. Never pull
on the power cord.
• Avoid contacting moving parts. Keep hands, hair and clothing- as well
as spatulas and other utensils- away from beaters during operation to
reduce the risk of injury to persons, and/or damage to the mixer.
• Do not operate appliance with a damaged cord or plug, or after the
appliance malfunctions or has been dropped or damaged in any manner.
Contact Consumer Support at the toll-free number listed in the warranty
section. This appliance has important markings on the plug blade. The
attachment plug or entire cordset (if plug is molded onto cord) is not
suitable for replacement. If damaged, the appliance must be replaced.
• The use of attachments not recommended or sold by the manufacturer
POLARIZED PLUG (120V models only)
This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to fit into a polarized
outlet only one way. If the plug does not fit fully into the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician. Do not attempt to
modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-resistant screw to prevent
removal of the outer cover. To reduce the risk of fire or electric shock, do not
attempt to remove the outer cover. There are no user-serviceable parts inside.
Repair should be done only by authorized service personnel.
HOW TO USE
6
1
Select correct attachment(s)
for mixing task:
•Beaters*-general mixing
•Whisk-whipping, aerating
•Hooks-thick mixtures, dough
*If the mixture becomes too thick while using beaters, switch to using the dough hooks.
5
For least-mess mixing:
Before turning on, insert
attachment(s) into the center
of food at a 90 degree angle.
WARRANTY AND CUSTOMER SERVI CE I NFORM ATION
Three-Year Limited Warranty
(Applies only in the United States and Canada)
For service, repair or any questions regarding your appliance, call the
appropriate 800 number listed within this section. Please DO NOT
return the product to the place of purchase. Also, please DO NOT mail
product back to manufacturer, nor bring it to a service center. You
may also want to consult the website listed in this manual.
What does it cover?
• Any defect in material or workmanship provided; however,
Empower Brands, LLC's liability will not exceed the purchase
price of product.
For how long?
• Three years from the date of original purchase with proof
of purchase.
What will we do to help you?
• Provide you with a reasonably similar replacement product that
is either new or factory refurbished.
How do you get service?
• Save your receipt as proof of date of sale.
• Visit the online service website at www.prodprotect.com/
blackanddecker, or call toll-free 1-800-465-6070, for general
warranty service.
• If you need parts or accessories, please call 1-800-738-0245.
BLACK+DECKER ® and the BLACK+DECKER ® logos are trademarks of The Black & Decker ® Corporation,
used under license by Empower Brands, LLC, a subsidiary of Spectrum Brands, Inc. for its manufacturing and sale of this product. All
rights reserved. All other marks are Trademarks of Empower Brands, LLC.
BLACK+DECKER® y los logotipos BLACK+DECKER® son marcas registradas de Black & Decker® Corporation,
utilizados por Empower Brands, LLC, una subsidiaria de Spectrum Brands, Inc. bajo su licencia para su fabricación y venta de este
producto. Todos los derechos reservados. Todas la Demas marcas son Marcas Registrades de Empower Brands, LLC.
At the end of this product's life, you can mail it to Empower Brands, LLC at
507 Stokely Drive, Deforest, WI 53532 marked "Product Takeback: Please Recycle!"
Al final de la vida útil de este producto, puede enviarlo por correo a Empower Brands, LLC,
507 Stokely Drive, Deforest, WI 53532 marcado "Product Takeback: Please Recycle!"
Made in China.
Fabricado en China.
© 2022 Empower Brands, LLC All rights reserved / Todos los derechos reservados.
T22-9002119-G
Empower Brands, LLC, Middleton, WI 53562
E/S 29298
Please Read and Save this Use and Care Book.
IMPORTANT SAFEGUARDS
may cause fire, electric shock or injury.
• Do not use outdoors.
• Do not let cord hang over edge of table or counter.
• Do not let cord contact hot surface, including the stove.
• Remove beaters from mixer before washing.
• This appliance is not intended for use by persons (including children) with
reduce physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the
appliance.
• The maximum rated wattage for this product was obtained with the
dough hooks. Other recommended attachments may draw significantly
less power or current.
• To avoid overheating the motor, do not use the dough hooks continuously
for more than 2 minutes. After 2 minutes of continuous dough hook
usage, let the unit cool for 15 minutes.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
ELECTRICAL CORD
a) A short power-supply cord is provided to reduce the risks resulting from
becoming entangled in or tripping over a longer cord.
b) Extension cords are available and may be used if care is exercised in
their use.
c) If an extension cord is used:
1) The marked electrical rating of the extension cord should be at least as
great as the electrical rating of the appliance; and
2) The cord should be arranged so that it will not drape over the counter
top or tabletop where it can be pulled on by children or tripped over.
Note: If the power cord is damaged, please contact the warranty
department listed in these instructions.
2 3
With mixer unplugged from NOTE: Match the notched
outlet, insert attachment(s). shapes of the discs to the
correct openings. Push in until
they click.
6 7
NOTE: To avoid getting TIP: To scrape the bowl with
powder inside the unit, mix a spatula, first turn mixer off
at speed 1 until dry and wet then place mixer on heel rest.
ingredients are combined.
Begin all mixing tasks on
speed #1, then increase speed
as needed.
How does state law relate to this warranty?
• This warranty gives you specific legal rights. You may also
have other rights that vary from state to state or province to
province.
What does your warranty not cover?
• Damage from commercial use
• Damage from misuse, abuse or neglect
• Products that have been modified in any way
• Products used or serviced outside the country of purchase
• Glass parts and other accessory items that are packed with the unit
• Shipping and handling costs associated with the replacement of
the unit
• Consequenti al or incidental damages (Please note, however,
that some states do not allow the exclusion or limitation of
consequential or incidental damages, so this limitation may not
apply to you.)
Are there additional warranty exclusions?
• This warranty shall not be valid where it is contrary to
U.S. and other applicable laws, or where the warranty
would be prohibited under any economic sanctions,
export control laws, embargos, or other restrictive trade
measures enforced by the United States or other applicable
jurisdictions. This includes, without limitation, any warranty
claims implicating parties from, or otherwise located in,
Cuba, Iran, North Korea, Syria and the disputed Crimea
region.
4
Once attachment(s) are firmly
inserted, make sure the speed
wheel is turned to O (OFF),
and plug the mixer into an
outlet.
Push
8
When finished, turn speed
wheel to O (OFF) and
unplug mixer. Then press
wheel downwards to eject
attachment(s).
7/20/22 2:53 PM 7/20/22 2:53 PM
