Summary of Contents for VESTEL 32H9520RB

  • Page 1 TELEViZYON User MANUAL 32H9520RB 32” Wi-Fi MOBIL TV...
  • Page 2 Your device will serve you for long years as long as you display the necessary care and maintenance. We hope you enjoy using your device. This product was manufactured in environmentally friendly VESTEL ELEKTRONİK A.Ş. facilities with no harm to the nature.

  • Page 3: Table Of Contents

    Contents Contents .........................2 Safety Information to Be Observed During Transport and Shipping..... 8 Batteries ......................... 8 WARNING........................8 Liability Limitation ......................8 Features .......................... 8 High Dynamic Range (HDR) / Hybrid Log-Gamma (HLG) ......... 9 Accessories Included ....................9 Standby Notifications ....................9 TV Control Button &...
  • Page 4 Using the Channel List ....................37 Configuring Parental Settings ..................37 Electronic Programme Guide ..................38 Teletext Services ......................39 Software Upgrade ......................39 Troubleshooting ......................40 Connectivity .........................43 Wired Connectivity .....................43 Wireless Connectivity ....................44 Networked Standby Mode ..................46 Wireless Display ......................46 Connecting Bluetooth Devices ..................47 Connectivity Troubleshooting ...................
  • Page 5 Safety Information CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. In extreme weather (storms, lightning) and long inactivity periods (going on holiday) disconnect the TV set from the mains.
  • Page 6 Markings on the Product WARNING The following symbols are used on the A television may fall, causing serious product as a marker for restrictions and personal injury or death. Many injuries, precautions and safety instructions. Each particularly to children, can be avoided explanation shall be considered where by taking simple precautions such as: the product bears related marking only.
  • Page 7 IMPORTANT - Please read these WARNING instructions fully before installing Apparatus connected to the protective or operating earthing of the building installation WARNING: Never let people (including through the MAINS connection children) with reduced physical, sensory or or through other apparatus with a mental capabilities or lack of experience connection to protective earthing –...
  • Page 8 • Do not expose the TV to dripping or range of 0 – 45°C when charging and splashing of liquids and do not place -10 – 50°C when discharging. objects filled with liquids, such as vases, • When storing the product for a long cups, etc.

  • Page 9: Safety Information To Be Observed During Transport And Shipping

    Safety Information to ed, it may cause serious burns within your body and death only within 2 hours. Be Observed During • Keep new and used batteries away from Transport and Shipping children. • Your device must be kept in its original • If battery housing doesn’t close properly, package to protect from damage to do not use the product and keep away...

  • Page 10: High Dynamic Range (Hdr) / Hybrid Log-Gamma (Hlg)

    • Back AV inputs for external devices colour and other improvements. It (such as DVD Players, PVR, video delivers the look that filmmakers intended games, etc.) to achieve, showing the hidden areas of dark shadows and sunlight with full clarity, • Stereo sound system colour and detail.

  • Page 11: Tv Control Button & Operation

    standby mode a dialogue window will be displayed. If you do not press any button the TV will switch into the standby mode after a waiting period of about 5 minutes. You can highlight Yes and press OK to switch the TV into standby mode immediately.

  • Page 12: Using Main Tv Menu

    Main menu OSD cannot be displayed via remaining on the main TV menu screen. control button. The green small icons indicate the current status for time, network and sync Operation with the Remote Control for apps. If these icons appear in green, Press the Menu button on your remote it means that the time information is control to display main menu.
  • Page 13 2. Search To cancel an already set timer, highlight that timer, select Delete Selected Timer You can search for Channels, Guide, tab and press OK. A confirmation TV menus, Applications, Web, YouTube message will be displayed. Highlight Yes and Videos using this option. Press OK and press OK to proceed.

  • Page 14: Inserting The Batteries Into The Remote

    3.7. Privacy Settings the cover is screwed on previously. Then remove the battery compartment cover You can access the privacy settings menu to reveal the battery compartment. Insert directly using this option. This option may two 1.5V - size AAA batteries. Make sure not be available depending on the model the (+) and (-) signs match (observing of your TV and the selected country...

  • Page 15: Antenna Connection

    Be sure to ground the connection properly License Notification Connect the ground terminal of the AC adaptor The terms HDMI, HDMI High- with the ground terminal provided at the power outlet using the supplied power adaptor cord. If the Definition Multimedia Interface, and provided plug does not fit your outlet, consult an electrician for replacement of the obsolete outlet.

  • Page 16: Disposal Information

    Microsoft or an authorized Microsoft subsidiary. Disposal Information This product contains technology subject [European Union] to certain intellectual property rights These symbols indicate that the electrical of Microsoft. Use or distribution of and electronic equipment and the battery this technology outside of this product with this symbol should not be disposed is prohibited without the appropriate of as general household waste at its end-...

  • Page 17: Specification

    Specification [Other Countries outside the European Union] PAL BG/I/DK These symbols are only valid in the TV Broadcasting SECAM BG/DK European Union. VHF (BAND I/III) - UHF Receiving Channels (BAND U) - HYPERBAND Contact your local authority to learn Fully integrated digital about disposal and recycling.
  • Page 18 Wireless LAN Transmitter Specifications Frequency Ranges Max Output Power 2400 - 2483,5 MHz (CH1-CH13) < 100 mW 5150 - 5250 MHz (CH36 - CH48) < 200 mW 5250 - 5350 MHz (CH52 - CH64) < 200 mW 5470 - 5725 MHz (CH100 - CH140) <...

  • Page 19: Remote Control

    Remote Control Standby (*): Standby / On (press briefly) Reset / Power Off (press and hold) Numeric buttons: Switches the channel, enters a number or a letter in the text box on the screen Language: Switches among sound modes (analogue TV), displays and changes audio/subtitle language and turns subtitles on or off (digital TV, where available) Mute: Completely turns off the volume of the TV...

  • Page 20: Remote Control- 2

    Remote Control- 2 Standby (*): Standby / On (press briefly) Reset / Power Off (press and hold) Menu: Displays TV menu Directional buttons: Helps navigate menus, content, etc. and displays the subpages in TXT mode when pressed Right or Left 4.

  • Page 21: Connections

    Connections See the illustrations on the left Connector Type Cables Device side. You can use YPbPr to VGA cable to enable YPbPr signal via VGA input. You cannot use VGA Connection and YPbPr at the same time. To (back) enable PC/YPbPr audio, you will need to use the back audio PC/YPbPr inputs with a YPbPr/ PC audio...

  • Page 22: Switching On/Off

    Switching On/Off First Time Installation To Switch the TV On When turned on for the first time, the language selection screen is displayed. Connect the power adaptor to a power Select the desired language and press source such as a wall socket (100-240V OK.
  • Page 23 environmentally friendly select Natural On next screen you can set broadcast and press OK to continue. You can types to be searched, set your encrypted change your selection later using the channel searching and time zone Mode option in the Settings>Picture (depending on the country selection) menu.
  • Page 24 Tivibu Option (optional) accordingly. Press OK to proceed. The TV will start to search for available You can search and store Tivibu channels broadcasts. if the Satellite broadcast search option is turned on. Before the channel search D-Smart Option (optional) starts, a menu will be displayed where You can search and store D-Smart you can select to install Tivibu channels.
  • Page 25 • S ingle Satellite Cable: If you have If wanted TKGS Installation can be applied manually after the First Time multiple receivers and a single satellite Installation. Press the Menu button. cable system, select this antenna type. Press OK to continue. Configure Highlight Installation in the Settings menu and press OK.

  • Page 26: Using Satellite Channel Table Feature

    not. If any changes are detected, TV that, some options may not be available starts to update. When the update is depending on the country selection. completed a message will be displayed In the TKGS system, channels can be to inform the user about the changes. blocked by the service provider and Manual: An update can be started audio/video transmission will not be...

  • Page 27: Media Playback Via Usb Input

    Media Playback via USB Input one of the USB inputs located on the side of the TV. You can connect 2.5” and 3.5” inch (HDD After connecting a USB storage device with external power supply) external hard to your TV Media Browser menu will be disk drives or USB memory stick to your displayed on the screen.

  • Page 28: Cec

    Note: If you perform a First Time Loop/Shuffle Mode Operation Installation the TV will return to using the All files in the list will be default logo, if any. continuously played in Start playback and activate original order (*) Images should be in jpeg file formats. The same file will be played Start playback and activate continuously (repeat)
  • Page 29 of the connected HDMI ports name(such it is not already set. The TV speakers as DVD Player, Recorder 1 etc.). will be muted and the sound of the watched source will be provided from the The TV remote is automatically able connected sound system.

  • Page 30: Battery Menu Content

    Battery Menu Content Set your Power Mode preference. Normal, Eco and Eco Plus options are available. If the power adaptor is connected, TV will operate as if in normal mode without any restriction. Normal: TV will operate without any restriction. Power Mode Eco: The backlight level will be set to 12 (72lum).

  • Page 31: Settings Menu Content

    Settings Menu Content Picture Menu Content You can change the picture mode to suit your preference or requirements. Picture mode can Mode be set to one of these options: Cinema, Game(optional), Sports, Dynamic and Natural. Contrast Adjusts the light and dark values on the screen. Brightness Adjusts the brightness values on the screen.
  • Page 32 Films are recorded at a different number of frames per second to normal television programmes. Film Mode Turn this feature on when you are watching films to see the fast motion scenes clearly. Skin Tone Skin tone can be changed between -5 and 5. Colour Shift Adjust the desired colour tone.
  • Page 33 Sound Menu Content Smart, Movie, Music, News and Off options will be available. Set as Off to disable. Dolby Audio Note: Some items in Sound menu will be grayed out and unavailable if set to an option other than Off. Surround Sound Surround Sound mode can be changed as On or Off.
  • Page 34 Network Menu Content Network Type Disable the network connection or change the connection type. Scan Wireless Start a search for wireless networks. This option will be available if the Network Type Networks is set as Wireless Device. If your modem/router device has WPS, you can directly connect to it using this option. Press WPS on your Highlight this option and press OK.
  • Page 35 System Menu Content Conditional Access Controls conditional access modules when available. Language You may set a different language depending on the broadcaster and the country. Manage your privacy privileges for smart TV related applications. Press OK to enter Privacy Settings the menu and set according to your preferences.
  • Page 36 Click Sound This option enables the key click sound on TV menu. Set to On to enable. Highlight programmes with If this option is enabled and if any electronic programme guide event has "Subtitle" [S] Subtitle access service, this events will be highlighted with another colour. [SL] Sign If this option is enabled and if any electronic programme guide event has "Sign Language...
  • Page 37 Application Displays current software version. Version Sets the desired time for the TV to automatically go into standby mode when not Auto Power Down being operated. This option can be set from 1 to 8 hours in steps of 1 hour. You can also disable this option by setting as Off.

  • Page 38: General Tv Operation

    General TV Operation You can use the filtering function in the Channels menu to filter the channels in Using the Channel List the channel list permanently according to your preferences. For instance, using the The TV sorts all stored stations in the options of the Filter tab, you can set one channel list.

  • Page 39: Electronic Programme Guide

    be disabled. Set to OFF to release these Use the directional buttons to navigate applications again. through the programme guide. Use the Back/Return button to use the tab Set PIN: Defines a new PIN number. options on the upper side of the screen. Default CICAM PIN: This option will Timeline Schedule appear as greyed out if no CI module is...

  • Page 40: Teletext Services

    Teletext Services Now/Next Schedule In this layout option, only the current and Press the Text button to enter. Press next events of the listed channels will be again to activate mix mode, which allows displayed. You can use the directional you to see the teletext page and the TV buttons to scroll through the list of the broadcast at the same time.

  • Page 41: Troubleshooting

    If your device does not resume normal operation still, contact Vestel Commu- nication Center. You can find authorized services list and contact information from the web site. English - 40 -...
  • Page 42 PROBLEM CAUSE REMEDY Power cable might be unplugged. Make sure it's plugged into the wall plug. Device doesn't turn on. Batteries of remote control- Replace the batteries of remote controller with ler might be discharged. new ones. Press the On/Off button on TV. Correct TV system might Make sure you have selected right TV system.
  • Page 43 PROBLEM CAUSE REMEDY Displaying, To cancel the mute option, press the TV might be muted. button or turn up the volume. no sound. Screen resolution and set- Display is bad in Change resolution informa- tings of computer and TV computer mode. tion on your computer.

  • Page 44: Connectivity

    Connectivity Wired Connectivity To Connect to a Wired Network • You must have a modem/router connected to an active broadband connection. • Connect your TV to your modem/ 1. Network wall socket router via an Ethernet cable. There is a 2. LAN input on the rear side of the TV LAN port at the rear (back) of your TV.

  • Page 45: Wireless Connectivity

    Wireless Connectivity speed are the theoretical maximum values for the wireless standards. They To Connect to a Wireless Network are not the actual speeds of data The TV cannot connect to the networks transmission. with a hidden SSID. To make your • The location where the transmission is modem’s SSID visible, you should change most effective differs depending on the...
  • Page 46 Highlight Internet Speed Test and press network and select the security type using the OK button to check your internet the related options to connect. connection speed. Highlight Advanced Note: If the modem supports N mode, Settings and press the OK button to you should set N mode settings.

  • Page 47: Networked Standby Mode

    Highlight the Audio Video Sharing at least once while the TV is on. If the option in the Sources menu and press TV is powered off, the connection should OK, available media server devices in be re-established, the next time it is the network will be displayed.

  • Page 48: Connecting Bluetooth Devices

    the OK button to open the related to the instruction manual of your mobile device for detailed information. menu. Using this menu you can discover and connect the devices that use the Scan for devices. After you select your Bluetooth wireless technology and start TV and connect, the screen of your to use them.

  • Page 49: Connectivity Troubleshooting

    the file is suitable. Press the Exit button Note: Wireless devices may operate to terminate displaying the image. within the same radio frequency range and may interfere with one another. To The audio will be routed through the improve the performance of your wireless speakers of the TV, after confirmation device place it at least 1 meter away from is given.

  • Page 50: Using Audio Video Sharing Network Service

    compatible devices. Try changing the problems while browsing files in Audio active channel on the WLAN router. Video Sharing mode. Internet Connection Not Available / Using Audio Video Sharing Audio Video Sharing Not Working Network Service If the MAC address (a unique identifier Audio Video Sharing feature uses a number) of your PC or modem has been standard that eases the viewing process of...

  • Page 51: Apps

    press OK to continue. The media browser Market option in the TV menu and press will then be displayed. OK. Available apps will be displayed. You can also access the application market Refer to the Media Browser menu from within the More Apps menu. section for further information on file playback.

  • Page 52: Hbbtv System

    options bar, move the cursor to the Enter keyword/s into the search/address top of the page. History, Tabs and bar and highlight the Enter button on Bookmarks options and the browser bar the virtual keyboard and press the OK which contains previous/next buttons, the button to start a search for the related refresh button, the address/search bar, websites.

  • Page 53: Smart Center

    voting, games, social networking and both ways or one of them. If the platform other multimedia applications. does not have an operational broadband connection, the platform can still launch HbbTV applications are available on applications transmitted on broadcast. channels where they are signalled by the broadcaster.
  • Page 54 MY CHANNELS: The programmes of tablet as a remote control for your TV and share media files. first four channels from the channel list retrieved from the TV are shown. You Note: Being able to use all functions of can change the listed channels. Press on this application depends on the features the channel thumbnail and hold.
  • Page 55 A u t o - e n a b l e F o l l o w M e T V: programme. Also there are links to FollowMeTV function (if available) Facebook and Twitter pages of the will start automatically when this setting programme selected.

  • Page 56: Dvb Functionality Information

    4. Smart Center app.(to be found on If the Media Share widget is pressed, a online application stores based on screen is displayed where you can select Android and iOS platforms) the media file type to share with your TV. 5.

  • Page 57: Ac Adaptor Specifications

    AC Adaptor Specifications Manufacturer Name SHENZHEN HUNTKEY ELECTRIC CO., LTD Model Identifier HKA12024038-6B Input Voltage (V) 100-240 Input AC Frequency (Hz) 50-60 Output Voltage (V) 24,0 Output Current (A) 3,75 Average Active Efficiency % 88,0 Efficiency at Low Load (%10) % 85,0 No-load Power Consumption (W) 0,21...

  • Page 58: Pc Input Typical Display Modes

    Although this DVB receiver conforms 1920x1080 60Hz to the latest DVB specifications at the time of manufacture, we cannot AV and HDMI Signal guarantee compatibility with future DVB Compatibility transmissions due to changes that may be implemented in broadcast signals and Source Supported Signals Available...

  • Page 59: Supported File Formats For Usb Mode

    Supported File Formats for USB Mode Video File Formats Extension Video Codec Max. Resolution & Frame Rate & Bit Rate .mpg, .mpeg, .dat, .vob MPEG1/2, H.264, VC1 .ts, .trp, .m2ts .avi MPEG1/2, MPEG4, H.264, MJPEG .mp4, .m4a, .m4v, .mov, .qt, MPEG1/2, H.263, MPEG4, H.264 .3gp, .3g2, .3gpp .mkv...

  • Page 60: Subtitle File Formats

    Subtitle File Formats External Subtitles Extension Specification .ssa SubStation Alpha .ass Advanced SubStation Alpha .srt Subripper .sub Micro DVD / SubViewer .sub + .idx VOBSub .txt Micro DVD / TMPlayer / MPL2 .mpl MPL2 .smi Sami .jss JACOSUB .ttml TTML .txt / .sub DVDSUBTITLE .lrc...

  • Page 61: Supported Dvi Resolutions

    Supported DVI Resolutions When connecting devices to your TV’s connectors by using DVI converter cable(DVI to HDMI cable - not supplied), you can refer to the following resolution information. 56Hz 60Hz 66Hz 70Hz 72Hz 75Hz 640x400 640x480 800x600 832x624 1024x768 1152x864 1152x870 1280x768...

  • Page 62: Disposing Of Your Appliance And Battery In An Environment-Friendly Way

    Recommendations for Disposing Of Your Energy Saving Appliance and Battery In An Environment-Friendly Way Environmental Information This television is designed to consume less This symbol on the product energy to help protection of environment. or package implies that the You can follow the below steps to reduce product should not be energy consumption: treated as domestic waste.
  • Page 63 NOTE: Screen Off option is not available if the Mode is set to Game. • Turn off the device by switching to standby position when you don’t use your device. If you won’t use the device for a long period, disconnect the device from mains plug.

  • Page 64: Important Warnings

    IMPORTANT WARNINGS 1. Rights reserved by the manufacturer: The manufacturer reserves the right to change the features stated in the product or in the user’s manual of the product without giving any information, when required by the improvements in technology. 2.
  • Page 65 sharpness and resolution of the image may be low; some effects may arise on the screen. This is not a failure. If your appliance supports high definition, it is recom- mended that you use high definition broadcast sources in order to achieve a high screen performance as a requirement of the high definition (HD) technology.

  • Page 66: Optional Rights Of Customer

    Optional Rights of Customer Consumer may exercise any of his/her optional rights below within two years of expiry period starting with the date of delivery of the good to the consumer if the good is found to be defective as per the provisions of Law on the Protection of Consumers no. 6502, even if the defect is found later;...
  • Page 67 TR: İşbu belgede; VESTEL Elektronik Sanayi ve Ticaret VESTEL Elektronik Sanayi ve Ticaret A.Ş., igazolja, hogy A.Ş., telsiz ekipmanı tipi TFT IDTV ’nin 2014/53/AB a TFT IDTV típusú rádióberendezés megfelel a 2014/53/ sayılı direktife uygun olduğunu beyan eder. AB uygunluk EU irányelvnek.
  • Page 68 TR: İşbu belgede; VESTEL Elektronik Sanayi ve Ticaret VESTEL Elektronik Sanayi ve Ticaret A.Ş., igazolja, hogy A.Ş., telsiz ekipmanı tipi TFT IDTV ’nin 2014/53/AB a TFT IDTV típusú rádióberendezés megfelel a 2014/53/ sayılı direktife uygun olduğunu beyan eder. AB uygunluk EU irányelvnek.
  • Page 69 SiZiN iÇiN BURADAYIZ! Ürününüzü iyi günlerde kullanmanızı diliyoruz. Bize ulaşmak isterseniz, 7/24 aşağıdaki iletişim kanallarında sizin için buradayız. Aradığınız pek çok cevabı cozumuvar.vestel.com.tr internet sitemizde bulabilirsiniz. Sorun çözüm ve bilgilendirici videolarımıza ulaşabilir, yetkili servis kaydı açabilir, kaydınızı takip edebilir, ürününüze ait güncel teknik belgelere ulaşabilirsiniz.
  • Page 72 Üretici Firma: Cihazınızın T.C. Gümrük ve Ticaret Bakanlığı Tüketicinin Korunması ve Piyasa Gözetimi Vestel Elektronik Sanayi ve Ticaret A.Ş. Genel Müdürlüğü’nce tespit ve ilan edilen kullanım ömrü (cihazın fonksiyonlarını Organize Sanayi Bölgesi 45030 yerine getirebilmesi için gerekli yedek parça bulundurma süresi) 10 yıldır.
