ION Party Rocker Max - Rechargeable Bluetooth Speaker Quick Start

Box Contents

  • Party Rocker Max
  • Microphone & Cable
  • 1/8" Stereo Aux Cable
  • Power Cable (IEC)
  • Quickstart Guide/Safety & Warranty Information

Rechargeable Batteries

Rechargeable lead-acid batteries are the same type used in automobiles. As with your car battery, how you use this battery has a significant impact on its lifespan. With proper use and treatment, a lead-acid battery can last for years. Here are some recommendations for getting the longest life from the internal battery.

General Usage Fully charge the battery before using it.
Charge the battery completely after each use.
Storage For best product longevity, do not store at exceedingly hot (greater than 90°F/32°C) or exceedingly cold (less than 32°F/0°C) temperatures. It is acceptable to leave your sound system plugged in. This will not overcharge the battery. If you leave the battery level low and do not charge it for 6 months, it may permanently lose capacity.
Repair If the battery fails to charge, check your fuse near the power cable input. If your fuse is intact and it still will not charge, contact ION Audio at ionaudio.com.
Disposal Bring the unit to a recycling center or dispose of in accordance with local ordinances.

Features

Features

  1. Aux Input (1/8")
  2. Mic Inputs (1/4")
  3. Power/Charge LED
  1. Bluetooth LED
  2. Bluetooth Disconnect
  3. All Lights On/Off
  1. Party Lights Mode
  2. Speaker Light Mode
  3. Light Buttons
  1. Echo
  2. Main Volume Control
  3. Power On/Off Switch
  1. Power Cable Input (IEC)

Quick Setup

  1. Make sure all items listed under Introduction > Box Contents at the beginning of this guide are included in the box.
  2. Read safety instruction booklet before using the product.
  3. For optimal performance, place Party Rocker Max in the center of the room so it is unobstructed by walls, furniture, etc.
  4. Turn down the Main Volume on the Party Rocker Max.
  5. Turn on Party Rocker Max.
  6. Connect your music player with an audio cable or Bluetooth.
  7. Adjust the volume on your music player and on Party Rocker Max as needed.
  8. Adjust the Light Mode buttons on Party Rocker Max as needed.
  9. Turn off Party Rocker Max when not in use.

Pairing a Bluetooth Device

  1. Turn on your Bluetooth device.
  2. Power on Party Rocker Max and it will automatically go into pairing mode to search for Bluetooth devices. You will know you are in pairing mode when the Bluetooth LED is off.
  3. If your Bluetooth device is not able to pair to Party Rocker Max, press the Bluetooth Disconnect button on the unit to break previous Bluetooth connections and reset the Bluetooth module.
  4. Navigate to your Bluetooth device's setup screen, find Party Rocker Max and connect.
    Note: If your Bluetooth device prompts for a pairing code, enter 0000.
  5. The Bluetooth LED will light up solid when it is "paired."
    Note: If you experience trouble pairing or playing music, update your device's OS.
  6. To disconnect pairing, press the Bluetooth Disconnect button on Party Rocker Max.
  7. To connect to another Bluetooth device, repeat steps 3-4.
    Note: Maximum range will be achieved when using devices with Bluetooth 4.0.

Support

At ION, your entertainment is as important to us as it is to you. That's why we design our products with one thing in mind—to make your life more fun and more convenient.
For the latest information about this product (documentation, technical specifications, system requirements, compatibility information, etc.) and product registration, visit ionaudio.com.
For additional product support, visit ionaudio.com/support.


Do not expose Party Rocker Max to rain or standing water.

Light Modes

There are five modes to select from for how the dome lights react to the music by pressing the Party Lights button:

  • Beat Sync: The dome lights spin and change color to the beat of the music playing.
  • Auto: The dome lights spin and change color with a predetermined pattern regardless of the beat of the music playing.
  • Single Color: The lights change one color at a time and do not move.
  • Freeze: All colors remain on and unmoving until a new mode is selected.
  • Off: The dome lights turn off.

Speaker Light Mode: Press this button to cycle through these different light effects:

  • EQ Bars (reactive to music)
  • Vertical Lights Wipe (non-reactive to music)
  • Diagonal Lights Wipe (non-reactive to music)
  • Vertical Lights Scrolling (non-reactive to music)
  • Snowflake/Square Lights (non-reactive to music)
  • Moving Block Bar (reactive to music)
  • Pulsating Block (reactive to music)
  • Horizontal Pulsating Bar (reactive to music)
  • Diagonal with Changing Colors (reactive to music)
  • Cross with Changing Colors (reactive to music)
  • Solid Color (reactive to music)
  • Pulsating Block with Spinning Block (reactive to music)
  • Snowflake/Square Lights Fill (non-reactive to music)
  • Spinning Crosses and Expanding Square (non-reactive to music)
  • Vertical Pulsating Bar (reactive to music)
  • Moving Diagonal (non-reactive to music)

Troubleshooting

If the sound is distorted

Try lowering the volume control of your sound source or musical instrument. Also, try to reduce the overall volume of Party Rocker Max.

If there is too much bass

Try adjusting the tone or EQ control on your sound source to lower the bass level. This will allow you to play the music louder before clipping (distortion) occurs.

If there is a high-pitched whistling noise when using microphones: This is probably feedback. Point the microphone away from the speaker.

If you can't hear the microphone over the music volume: Turn down the music volume from your source.

Technical Specifications

Output Power: 100 W (peak)
Frequency Response: 65 Hz – 20 kHz (+3 dB)
Drivers:
Low-Frequency: 8.0" / 203 mm woofer
High-Frequency: 3.0" / 76 mm tweeter
Bluetooth:
Profile: A2DP, AVRCP
Range: Up to 100 ft. (30.5 m) *
Transmitter Frequency Range: 2402 MHz - 2480 MHz
Maximum Transmitter Power: < 8 dBm (EIRP)
* Bluetooth range is affected by walls, obstructions, and movement. performance, place the product in the center of the room so it is unobstructed by walls, furniture, etc.
** Battery life may vary based on temperature, age, and volume usage of product.
Microphone Type: Dynamic (included)
Battery Life (when fully charged):
Up to 75 hours (with music only)
Up to 6 hours (with lights and music)
Recharge Time: 10 hours
Power:
Connection: IEC
Input Voltage: 100–240 VAC, 50/60 Hz 120 W
Dimensions (DxWxH):
15.0" x 11.0" x 17.25" / 381 x 279 x 438 mm
Weight: 24.6 lbs. / 11.16 kg
