SOKOYO C00LEX KY-Y-YJ-001 Installation Manual

SOKOYO
Installation Manual For C00LEX
Light up every road back home
All In One Solar Street Light
1.
Instruction
This model includes solar panel, lithium battery, controller and LED light source.
It is easily assembled according to the product label. This model is made of LED module,
and replacement is simple.
2.
Application
Mainly used for lighting in public places such as countryside roads, urban main roads or
slow traffic roads, branch roads, tourism areas, parking lots, parks and public squares.
3.
Specification
Lamp Photo
Model No. KY-Y-YJ-001
1PCS
Module Quantity
18V/130W Mono PV
Solar Panel
Lithium Battery LiFePO4 12.8V/80AH
Rated power 60W
3000K
Color Temperature
Light Efficiency
CRI
Working Environment
Mounting Height 6-8m
1010x680x90mm
Lamp Dimension
IP Rate
Installation Diameter
Ø89
Wind Resistance 40M/S
25KG
Lamp Weight
1087x730x217mm
Packing Dimension
KY-Y-YJ-002 KY-Y-YJ-003
2PCS
36V/260W Mono PV
36V/260W Mono PV
LiFePO4 25.6V/80AH
LiFePO4 25.6V/60AH
80W
4000K 5000K 5700K
130-170LM/W
Ra≥70
℃～ ℃，
-10 +60 10%-90%RH
8-10m
1980x680x90mm
1980x680x90mm
IP65
Ø102
40M/S
41KG
2057x730x217mm 2057x730x217mm
4.
Installation Process
1
the anti-fall steel cable
Insert the MC4 plug to check whether the
system is normal.
3
Install the anti-fall steel cable on the mount
and fix the six hexagonal nuts, spring
washers and flat washers with a wrench.
5
2PCS
120W
Tighten the six fastening screws
6000K
with a wrench to fix the lamp.
There isn't anti-fall steel cable for KY-Y-YJ-001, pls skip this step.
Method to check whether the lamp is working normally:
1. The whole process should be handled with care, pay attention to personnel safety and product
integrity.
10-12m
2. Unbox the lamp, find non transparent sheet to cover the solar panel, so that it cannot be penetrated
by light.
3. Turn on the switch and wait for 10S to start the discharge mode, in the discharge mode the LED
indicator light should be always "ON" and the LED light source should be always "ON".
Ø102
4. After the LED light source was turned on normally, remove the cover off the solar panel, aim the solar
panel at the sunlight or any other strong lighting source, and wait for 10 seconds to start the charging
40M/S
mode.During the charging mode the indicator light should start flashing slowly and the light source goes
44KG off.
5.If the previous steps were going well, it means your product has no problem and it's okay to be
installed.
2
the
anti-fall
steel cable
the MC4 plug
Align the sleeve fixing hole with the screw
hole and place it.
4
Put the lamp into the light
pole to ensure that it can
Lighe pole
work normally before
putting on the light pole.
6
The light pole is erected and the
installation is complete.
