TYCON Solar UPSPro UPS-ST-120 Quick Install Manual

Outdoor ups system

Advertisement

Wireless Base Stations
and Client Devices
Surveillance Cameras
Mission Critical Backup
Power
Remote Sensors
Congratulations! on your purchase of the UPSPro
UPS backup power system. Please take a moment to review this
Qwik Install Guide before assembly or battery installation.
When following the instructions in this guide take extreme care
to avoid contact with overhead power lines, lights and power circuits.
Contact with power lines, lights or power circuits may be fatal. We rec-
ommend to install no closer than 20 feet to any power lines.
Safety:
For your own protection, follow these safety rules.
Perform as many functions as possible on the ground
Do not attempt to install on a rainy, windy or snowy day or if
there is ice or snow accumulation at the install site or if the
site is wet.
Make sure there are no people, pets, etc. below when you are
working on a roof or ladder.
Recommended Tools: Phillips Screwdriver, Flat Blade Screw-
driver, 13mm and 10mm Wrench, 5/16" nut driver,
Please help preserve the environment and return
used batteries to an authorized depot
DANGER! Avoid Powerlines!
You Can Be Killed!
UPS-ST-120
UPSPro
Outdoor UPS System
®
®
Outdoor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UPSPro UPS-ST-120 and is the answer not in the manual?

Questions and answers

Summary of Contents for TYCON Solar UPSPro UPS-ST-120

  • Page 1 UPS-ST-120 ® UPSPro Outdoor UPS System Wireless Base Stations ▫ and Client Devices Surveillance Cameras ▫ Mission Critical Backup ▫ Power Remote Sensors ▫ ® Congratulations! on your purchase of the UPSPro Outdoor UPS backup power system. Please take a moment to review this Qwik Install Guide before assembly or battery installation.
  • Page 2 Qwik Install CAUTION: Be sure to connect the battery to the controller first and disconnect it last. Connecting solar panels to the controller with- out the battery connected could damage the controller. STEP 1: Add Grounding Wire Be- tween Door and Enclosure: Remove plastic covers on copper studs on inside of door and inside of enclo- sure.
  • Page 3 STEP 5: If pole mounting the enclosure, assemble the pole mount kit to the back of the enclosure and mount the enclosure to a pole using the 6 hose clamps provided. The enclosure can also be wall mounted using the 4 holes in the back of the enclosure. STEP 6: Insert the battery platform in the bottom of the enclosure.
  • Page 4 2 Battery 24V Layout 1 Battery 12V Layout...
  • Page 5 SPECIFICATIONS Subject to change without notice Battery Voltage (DC) 12V or 24V Load Output Voltage (DC) 11-15VDC / 22-29VDC Suggested Max Load 100W AC Input Voltage 120/240VAC 50/60Hz 2.5A Max Battery Charge Voltage 14.4V / 28.8V Battery Charge Current 8.3A / 4.35A Battery Charge Capacity 120W Capacity...
  • Page 7 TECH CORNER 1.CONTROLLER: The controller turns off power to the load at 11V (22V if 24V array) and reconnects when the battery reaches 12.5V (25V if 24V array). This protects battery from over-discharge and increases battery life and performance. 2. CAPACITY: With a typical AP running 4W average. A single 12V 52Ah battery should be able to provide backup power for up to 75 hours at room temperature.
  • Page 8 Limited Warranty ® The UPSPro products are supplied with a limited 36 month warranty which covers material and workmanship defects. This warranty does not cover the following: ▫ Parts requiring replacement due to improper installation, misuse, poor site conditions, faulty power, etc. ▫...
