TYCON Solar UPSPro UPS-ST-600 Quick Install Manual

Outdoor ups system

Advertisement

Wireless Base Stations
and Client Devices
Surveillance Cameras
Mission Critical Backup
Power
Remote Sensors
Congratulations! on your purchase of the UPSPro
UPS backup power system. Please take a moment to review this
Qwik Install Guide before assembly or battery installation.
When following the instructions in this guide take extreme care
to avoid contact with overhead power lines, lights and power circuits.
Contact with power lines, lights or power circuits may be fatal. We rec-
ommend to install no closer than 20 feet to any power lines.
Safety:
For your own protection, follow these safety rules.
Perform as many functions as possible on the ground
Do not attempt to install on a rainy, windy or snowy day or if
there is ice or snow accumulation at the install site or if the
site is wet.
Make sure there are no people, pets, etc. below when you are
working on a roof or ladder.
Recommended Tools: Phillips Screwdriver, Flat Blade Screw-
driver, 13mm and 10mm Wrench, 5/16" nut driver,
Please help preserve the environment and return
used batteries to an authorized depot
DANGER! Avoid Powerlines!
You Can Be Killed!
UPS-ST-600
UPSPro
Outdoor UPS System
®
®
Outdoor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UPSPro UPS-ST-600 and is the answer not in the manual?

Questions and answers

Summary of Contents for TYCON Solar UPSPro UPS-ST-600

  • Page 1 UPS-ST-600 ® UPSPro Outdoor UPS System Wireless Base Stations ▫ and Client Devices Surveillance Cameras ▫ Mission Critical Backup ▫ Power Remote Sensors ▫ ® Congratulations! on your purchase of the UPSPro Outdoor UPS backup power system. Please take a moment to review this Qwik Install Guide before assembly or battery installation.
  • Page 2 Qwik Install STEP 1: Add Grounding Wire Between Door and Enclosure: Remove plastic covers on copper studs on inside of door and inside of enclo- sure. Add jumper wire between 2 copper studs and use copper wash- ers and nuts to secure. STEP 2: Remove the bottom cover and replace it with the PowerVent™...
  • Page 3 STEP 6: Insert the battery platform in the bottom of the enclosure. The battery platform has cutouts so wires can be routed under the bat- tery as needed. STEP 7: Attach the Black DIN Rail adapters to the charge controller using the screws provided.
  • Page 4 UPS-ST12-50-600 1 Battery UPS-ST24-50-600 2 Battery UPS-ST24-100-600 4 Battery...
  • Page 5: Specifications

    SPECIFICATIONS Subject to change without notice Battery Voltage (DC) 12V or 24V Load Output Voltage (DC) 11-15VDC / 22-29VDC Suggested Max Load 450W AC Input Voltage 120/240VAC 50/60Hz 5A Max Battery Charge Voltage 14.4V / 28.8V Battery Charge Current 40A / 20A Battery Charge Capacity 600W Capacity (Ah) @ 12V...
  • Page 7 TECH CORNER 1.CONTROLLER: The controller turns off power to the load at 11V (22V if 24V array) and reconnects when the battery reaches 12.6V (25.2V if 24V array). This protects battery from over-discharge and in- creases battery life and performance. 2.
  • Page 8: Limited Warranty

    6. BATTERY HOOKUP: Always connect the battery first and discon- nect the battery last. The controller should not be run without a battery connected. 7. BATTERY MAINTENANCE: The batteries used in the UPSPro sys- tems don’t require any maintenance. They should last up to 5 years in normal use.
