THOMASVILLE LIGHTING Lifetime Limited Warranty
THOMASVILLE LIGHTING FAN MOTORS ARE WARRANTED TO THE END USER TO
BE FREE OF ELECTRICAL AND/OR MECHANICAL DEFECTS FOR A LIFETIME FROM
DATE OF SALE. PULL CHAIN SWITCHES, REVERSE SWITCHES, CAPACITORS AND
METAL FINISHES ARE WARRANTED FOR A PERIOD OF 1 YEAR. WARPING OF
WOODEN OR PLASTIC BLADES IS NOT COVERED BY THIS WARRANTY.
THE END USER HAS THE OPTION OF RETURNING THE DEFECTIVE FAN TO THE
PLACE OF PURCHASE DURING THE FIRST 30 DAYS FOR A REPLACEMENT. AFTER
30 DAYS, THE PURCHASER MUST CONTACT THOMASVILLE LIGHTING FOR
REPAIR OR REPLACEMENT. THE END USER ALSO BEARS THE RESPONSIBILITY
FOR ALL COSTS IN THE REMOVAL, SHIPPING AND REINSTALLATION OF FANS OR
PARTS FOR REPAIR OR REPLACEMENT.
THOMASVILLE LIGHTING WILL NOT ASSUME LIABILITY OR RESPONSIBILITY
FOR DAMAGES (INCLUDING
INCIDENTAL OR CONSEQUENTIAL) CAUSED BY
THE IMPROPER INSTALLATION OR OPERATION OF THE UNIT OR ITS COMPONENT
PARTS, OR BY THE FAILURE OF SUPPORTING HARDWARE NOT SUPPLIED BY
THOMASVILLE LIGHTING. THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHER
GUARANTEES, WHETHER EXPRESSED OR IMPLIED, AND IS VOIDED IN CASES OF
ABUSE, MISUSE OR IMPROPER HANDLING, NEGLIGENCE, SHIPPING DAMAGE,
UNAUTHORIZED REPAIRS (MADE OR ATTEMPTED) OR UNUSUAL APPLICATION.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS OR THE EXCLUSION OR LIMITATIONS OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS AND EXCLUSIONS
MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC RIGHTS AND
YOU MAY HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
THOMASVILLE LIGHTING Lifetime Limited Warranty
Date Purchased
Store Purchased
UL Model No.
P2528
Serial No.
5523
Vendor No.
UPC
785247148288

Advertisement

loading
Need help?

Need help?

Do you have a question about the P2528 and is the answer not in the manual?

Questions and answers

Summary of Contents for THOMASVILLE LIGHTING P2528

  • Page 1 THOMASVILLE LIGHTING Lifetime Limited Warranty THOMASVILLE LIGHTING FAN MOTORS ARE WARRANTED TO THE END USER TO BE FREE OF ELECTRICAL AND/OR MECHANICAL DEFECTS FOR A LIFETIME FROM DATE OF SALE. PULL CHAIN SWITCHES, REVERSE SWITCHES, CAPACITORS AND Date Purchased METAL FINISHES ARE WARRANTED FOR A PERIOD OF 1 YEAR. WARPING OF WOODEN OR PLASTIC BLADES IS NOT COVERED BY THIS WARRANTY.
  • Page 2: Table Of Contents

    Safety Rules Unpacking Your Fan Installing Your Fan Operating Your Fan Operating Your Remote Control Care of Your Fan Troubleshooting Specifications Table of Contents...
  • Page 3: Safety Rules

    READ AND SAVE THESE INSTRUCTIONS To reduce the risk of electric shock, insure electricity has To avoid personal injury or damage to the fan and other been turned off at the circuit breaker or fuse box before items, be cautious when working around or cleaning the fan. beginning.
  • Page 4: Unpacking Your Fan 2

    Unpack your fan and check the contents. You should have the following items. 9. Finial Blade Attachment Hardware 1. Mounting Plate (inside Canopy) (15 washer head screws) 10. Blade Bracket Set (5) 2a. Downrod and Ball Assembly (12”) 11. Decorative Motor Collar Cover Extra Blade Bracket Hardware (with hanger pin and locking pin (1 screw and lockwasher)
  • Page 5: Installing Your Fan

    To hang your fan where there is an MAY NEED TO BE REPLACED. CONSULT QUALIFIED ELECTRICIAN existing fixture but no ceiling joist, DOUBT. you may need an installation hanger 3.Installing Your Fan bar as shown in Figure 4 (available at your Thomasville Lighting Retailer).
  • Page 6 Remove the hanger pin and locking and secure the three screws from the top Hanging the Fan pin from downrod assembly. of arm support ring into the decorative Route the wires exiting the top of arms (Figure A). the fan motor through the decorative REMEMBER to turn off the power.
  • Page 7 1. Remove the hanger ball by loosening CONNECTING SAFETY the set screw at the top of the 12" CABLE downrod assembly which holds the Place the looped end of the safety hanger ball to the downrod (This is not cable around the untightened wood screw the screw with green wire attached).
  • Page 8 from the fan assembly. WARNING Connect the black wire (To Motor L) WHEN USING STANDARD from the receiver unit to the black wire BALL/DOWNROD MOUNTING, THE TAB IN THE RING AT THE BOTTOM OF THE from the fan assembly. CANOPY MUST REST IN THE GROOVE OF 6.
  • Page 9 Finishing Attaching Installation Blades 1. Attach blade to blade bracket using 1. Carefully lift the canopy up to the the screws as shown in Figure 11. Please mounting plate . Make sure the tab in the note that the rubber washers are pre- ring at the bottom of the canopy is attached to the blade bracket.
  • Page 10 point on the ceiling. Measure this Attaching the Support distance as shown in Figure 13. Rotate the fan until the next blade is positioned Plate / Bottom Cover for measurement. Repeat for each blade. Remove screw from Measurements deviation should be within mounting adaptor below the fan motor 1/8".
  • Page 11: Operating Your Fan

    3. Replace the bulb with 7W, 120VAC Cool weather- (Reverse) An upward Lighted Housing Bulb candelabra base bulb only. airflow moves warm air off the ceiling Replacement Re-attach the glass access cover to area as shown in Figure 17. This allows WHILE PERFORMING BULB...
  • Page 12: Operating Your Remote Control 10

    Blue Receiver Wire(FOR LIGHT) Blue Light Wire Setting the Code NOTE: If other fan or supply wires are different color, have This unit has 16 different code combinations. this unit installed by a licensed electrician. To set the code, perform the following steps. B.
  • Page 13: Care Of Your Fan

    Here are some suggestions to help you There is no need to oil your fan. maintain your fan. The motor has permanently lubricated Because of the fan's natural sealed ball bearings. movement, some connections may become loose. Check the support WARNING connections, brackets, and blade MAKE SURE THE POWER IS OFF AT THE...
  • Page 14: Troubleshooting 12

    Problem Solution 1. Check main and branch circuit fuses or breakers. Fan will not start. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. 3. Check battery in the transmitter. Does the red LED light come on? Are you standing close enough to the fan (normal range is 10-20 feet)? Are the dip switch settings the same on the transmitter (hand unit) and receiver? REMEMBER TO TURN OFF POWER SUPPLY BEFORE CHECKING THE DIP SWITCH SETTINGS IN RECEIVER.
  • Page 15: Specifications

    12.7 29.9 37.4 Med. 0.48 32.0 58” High 0.64 76.5 These are approximate measures. They do not include Amps and Wattage used by the light kit. 2007 Thomasville Lighting Inc. 701 Millennium Blvd., Greenville, SC 29607 All Rights Reserved 13.Specifications...
