- Page 1 SMART Ultra HD Camera User guide SWC-120UHD C120-1 Was this document helpful? smarttech.com/docfeedback/171866...
- Page 2 © 2023 SMART Technologies ULC. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language in any form by any means without the prior written consent of SMART Technologies ULC. Information in this manual is subject to change without notice and does not represent a commitment on the part of SMART.
-
Page 3: Important Information
20cm between the radiator & your body. Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Unique Identifier: C120-1 Responsible Party – U.S. Contact Information SMART Technologies Inc. 2401 4th Ave, 3rd Floor Seattle, WA 98121 compliance@smarttech.com Innovation, Science, and Economic Development Canada Statement This device complies with CAN ICES-003(A) / NMB-003(A) of the Innovation, Science and Economic Development Canada Rules. - Page 4 2. ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. EU Declaration of Conformity Hereby, SMART Technologies ULC declares that the C120-1 complies with Directive 2014/30/EU. The full text of the EU and UK declaration of conformity is available at the following Internet address: smarttech.com/compliance Hardware environmental compliance SMART ...
-
Page 5: Table Of Contents
Chapter 5 Adjusting on-screen display menu settings Changing settings in the on-screen display menu Setup Exposure Color Image Noise reduction Version Restore Default Chapter 6 Using your camera with SMART Board interactive displays and iQ Chapter 7 Maintaining your camera smarttech.com/kb/171866... -
Page 6: Chapter 1 Welcome
For more information, such as videos, training, and how-to topics, visit support.smarttech.com/docs/redirect/?product=smartultrahdcamera. Features The SMART Ultra HD Camera 120 is a 4K Ultra-HD camera with ePTZ. Easily install the camera on a ® SMART Board interactive display. The camera can automatically frame people meeting in a boardroom. -
Page 7: Components
Supported SMART hardware SMART Board QX Pro series ® SMART Board 6000S and 6000S Pro series SMART Board MX (V4) and MX (V4) Pro series Components Component Notes Indicator light Indicates when the camera is on. Camera cover slider Can cover the camera lens. -
Page 8: Chapter 2 Installing And Connecting Your Camera
OFF (O) position. The switch is located beside the AC power inlet. For a list of SMART Board interactive displays in which you can install the camera, see Supported SMART hardware on page 7. -
Page 9: Chapter 3 Enable Your Camera
Chapter 3 Enable your camera Chapter 3 Enable your camera Once the camera is installed, enable camera mode to use it on your display. 1. Ensure your display is turned on. 2. On the main screen of your display, select Apps. ... -
Page 10: Chapter 4 Using The Remote Control
Chapter 4 Using the remote control Chapter 4 Using the remote control Use the infrared remote control to turn the web camera on or off, to open the on-screen menu, and reposition the camera. Name Procedure Pause Enable or disable the camera. The camera goes into standby mode when it’s paused - it does not turn off. -
Page 11: Using The Preset Buttons
Chapter 4 Using the remote control Using the preset buttons To save a preset 1. Set the camera’s pan, tilt, and zoom position. 2. Press 1, 2, or 3 for 3 seconds to save the camera position. When you release the button, Set preset # displays. -
Page 12: Chapter 5 Adjusting On-Screen Display Menu Settings
Chapter 5 Adjusting on-screen display menu settings Use the on-screen display (OSD) menu to adjust settings for your camera. Note Some video conferencing software mirrors the camera image on the screen, so the on-screen menu will be reversed and difficult to read. Changing settings in the on-screen display menu ... -
Page 13: Exposure
Chapter 5 Adjusting on-screen display menu settings Exposure Option Values Notes Mode Auto Manual Bright Only available when Auto is selected under Mode. EV level EV level is only available when EV is -7<0<+7 enabled and Auto is selected under Mode. -
Page 14: Color
Chapter 5 Adjusting on-screen display menu settings Color Option Values Notes White Auto balance Manual mode Onepush RG tuning -10–10 BG tuning -10–10 Saturation 0%–50% 0–8 High AWB sensitivity can only be set when Auto mode in the Exposure sensitivity menu is enabled. -
Page 15: Noise Reduction
Chapter 5 Adjusting on-screen display menu settings Noise reduction Option Values Notes 2D DNR 2D digital noise reduction 1–7 3D DNR 3D digital noise reduction 1–8 Version Option Values Notes Camera Version Version of camera software. Restore Default Option Values Notes Restore Default? -
Page 16: Chapter 6 Using Your Camera With Smart Board Interactive Displays And Iq
Chapter 6 Using your camera with SMART Board interactive displays and Once you’ve installed the camera, you can use it with video conferencing software, like Microsoft Teams or Zoom. smarttech.com/kb/171866... -
Page 17: Chapter 7 Maintaining Your Camera
Chapter 7 Maintaining your camera Follow these instructions to clean the camera without damaging its components. Use soft cloth or tissue to clean the camera cover. Wipe it with a soft, dry cloth when cleaning the camera lens. ... - Page 18 SMART Technologies smarttech.com/support smarttech.com/contactsupport smarttech.com/kb/171866...
