- Page 1 LINK INSTALLATION MANUAL LK-EXPO7PR FORD EXPEDITION 2007-2017 PASSENGER SIDE FRONT FULLY LOADED SEAT...
- Page 2 Seat Fan Base -Right- LK-EXP07R-BK Bolt Kit -Right- LK-EXP07R-AB Air Bag LINK Kit -Right- EW-CK-00 12V Power Supply Wiring Kit LK-UNI-650 Manual Backup Tool Kit PART NUMBER LK-EXP07R DESCRIPTION 1 of 4 LINK Ford Expedition 2007 - 2016 -Right- |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 3 Nylon Spacer id .317" od .500" SN 654-007 Nylon Spacer id .375" od .625" SN 681-129 Wave Disc Spring 0.325 id x 0.546 od x 0.007 thickness PART NUMBER LK-EXP07R DESCRIPTION 2 of 4 LINK Ford Expedition 2007 - 2016 -Right- |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 4 Trim Panel Clip Ø1/4'' x 3/4'' Black PRD 333-107 Nylon Insert Locknut 5/16-18 PRD 339-136P Socket Shoulder Screw Zinc Plated 3/8 x 1/2 x 5/16-18 THD PART NUMBER LK-EXP07R DESCRIPTION 3 of 4 LINK Ford Expedition 2007 - 2016 -Right- |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 5 PRD 332-164P Socket Head Cap Screw Zinc Plated 3/8-16 x 7/8 PRD 332-166P Socket Head Cap Screw Zinc Plated 3/8-16 x 1 1/4 PART NUMBER LK-EXP07R DESCRIPTION LINK Ford Expedition 2007 - 2016 -Right- 4 of 4 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 6 REFERENCES LINK L K- EXP07R *Transfer height: 19”| 3/ 8 inc h hig he r tha n O EM Se a t he ig ht: A ve ra g e insta ll: 6- 8 hrs. 1” O EM shro ud s must b e trim me d .
- Page 7 We have prepared quick, easy and to the point tutorial videos imbedded into the software. Take a moment and watch the video that shows all the features of the tablet. To do this, open the LINK IT app and tap on ‘INFO’.
- Page 8 Remove the passenger side OEM seat and place on a workbench and remove all the plastic shrouds. Remove and keep the OEM seat bolts to install the LINK floor adapters. LINK 2007-2017 FORD EXPEDITION PASSENGER FRONT. p. 3...
- Page 9 2. Disconnect the seat base seat back connectors, and remove the seat back. 3. Disconnect all the wiring connectors, unclip the control box and then remove the wiring. LINK 2007-2017 FORD EXPEDITION PASSENGER FRONT. p. 4...
- Page 10 4. Remove the seat cushion from the seat frame. 5. Remove the seat belt receiver and pre-tensioner. LINK 2007-2017 FORD EXPEDITION PASSENGER FRONT. p. 5...
- Page 11 6. Unclip the seat base fan from the seat cushion supports. 7. Remove the seat base cushion supports. 8. Remove the seat pan from the seat base. Also, remove the seat trim support bracket from the seat base. LINK 2007-2017 FORD EXPEDITION PASSENGER FRONT. p. 6...
- Page 12 (If you wish to keep a record of your wire extensions for reference, you will find a lined sheet at the very end of this manual for that purpose.) WIRING BEFORE EXTENTION LINK 2007-2017 FORD EXPEDITION PASSENGER FRONT. p. 7...
- Page 13 The wiring will have to be opened up to gain access to the wires to be extended. The control box is extended along with the air bag and floor connector and relocated to the floor. The seat back air bag connector is also extended at the same time. LINK 2007-2017 FORD EXPEDITION PASSENGER FRONT. p. 8...
- Page 14 SEAT BACK 10. Run the power from the battery to the LINK. To do this, thread the red power cable (+) under the doorstep moulding and through the firewall. Make sure you pass through a grommet in the firewall to prevent the cable from chaffing. Install the circuit breaker near the battery and then connect the battery to the circuit breaker.
- Page 15 11. Cut and fold back the rear part of the floor carpet. Connect and position the wiring connectors and control box on the floor, then Install the LINK floor adapter # LK-EXP07R-01 using the OEM bolts. 12. Install the provided plastic cover# LK-EXP07RB-05.
- Page 16 13. Remove the LINK from the shipping box and set it on a table or workbench. Connect auxiliary 12V power to the LINK. The LINK will ‘beep’ during the installation. (See LINK Audible Warnings chart for further references.) 14. Next, connect the LINK to the Android tablet via Bluetooth. Connect the Bluetooth module (small, blue and white, 4 pronged connector) to the LINK pendant plug.
- Page 17 15. Place the LINK in the vehicle on the floor adapter. Use the four (4) 3/8’’-16 x 1¼’’ socket cap bolts to secure the LINK by the pivot, and use the four (4) 3/8’’-16 x 7/8’’ to secure the interior of the LINK. Be careful not to pinch the LINK wire harness between the LINK and the floor adapter.
- Page 18 17. The seat fan will have to modified and relocated to fit. There are plastic tabs that will have to be removed to gain clearance. REMOVE REMOVE REMOVE LINK 2007-2017 FORD EXPEDITION PASSENGER FRONT. p. 13...
- Page 19 18. Reinstall the fan, place it under the seat cushion supports with the vent above the wire supports. Use the provided plastic # LK -EXP07R-06 to hold it in position and then attach the plastic with the provided zip ties. LINK 2007-2017 FORD EXPEDITION PASSENGER FRONT. p. 14...
- Page 20 20. Using the ‘BYPASS’ mode on the tablet, tilt the seat up to be able to install the seat cushion onto the LINK seat adapter. Attach the plastic clips with zip ties to ensure they do not un-clip. LINK 2007-2017 FORD EXPEDITION PASSENGER FRONT. p. 15...
- Page 21 Pass the seat back fabric flap underneath the seat and clip to the wire seat supports. NOTE: make sure that it fits snuggly so that it will not get caught in the mechanism of the LINK. LINK 2007-2017 FORD EXPEDITION PASSENGER FRONT. p. 16...
- Page 22 22. Reconnect the seatback seatbelt and seat fan connectors. Attach all the wires securely under the seat with zip ties to prevent them coming into contact with the mechanism of the LINK. Leave enough slack to be able to reconnect the seat adjustment seat connectors.
- Page 23 Verify the positioning of the wire to make sure there is no chance of it pinching or binding once the seat moves. 25. The right hand side plastic trim will have to be modified to allow clearance for the LINK. Then reinstall the trim.
- Page 24 26. The front plastic trim support will also have to be modified on the right and left sides. Cut along the red doted lines. RIGHT RIGHT LEFT LEFT 27. Reconnect the seat adjustment switch and reinstall the plastic trims. LINK 2007-2017 FORD EXPEDITION PASSENGER FRONT. p. 19...
- Page 25 If the LINK is slightly off its ‘HOME’ position or the starting point of its movements, there is a strong chance that the LINK will not fit through the doorway properly and/or will cause problems with the preset of the LINK.
- Page 26 Bluetooth module and plug in the hand pendant. Make sure the LINK hand pendant is working properly. Cycle the LINK in and out a few times, both with and without a passenger to make sure all shrouds are properly installed and that nothing is rubbing or requires adjustment. Make a visual inspection while the LINK is in movement that all the wiring follows the seat and does not risk being severed at any time.
- Page 27 9 Vo lt Ba tte ry T he LINK is designed to run off of the vehicle’s 12 vo lt b a tte ry. It is e q uip p e d with ma ny sa fe g ua rd s to e nsure tha t the c o ntro lle r b o x a lwa ys re ta ins its p ro g ra ming se q ue nc e .
-
Page 28: Normal Use
All systems functional and ready to go. Power Reduce Mode To exit, simply run the LINK a full cycle. Major Problem Do not use the LINK - contact your Mobility Equipment Dealer No Response No 12V Power DIAG NO ST IC MO DE... -
Page 29: Year Limited Warranty
( LINK ) inste a d o f re p a iring o r re p la c ing the o rig ina l e q uip me nt. - Page 30 LINK 2007-2017 FORD EXPEDITION PASSENGER FRONT. p. 25...
