Aquasub engineering TEXMO ASM SP Series Installation & Spare Parts Manual page 5

Part No
2 Suction Bracket
2-1 Strainer
3 Suction Flange
3-1 Suction Flange Washer
4 Delivery Flange
4-1 Delivery Flange Washer
6 Casing
7 Impeller
7-1 Key - Impeller
7-4 Lock Nut Impeller
9 Front Cover
9-2 Sand Guard
9-3 Oil seal
9-4 Bush - Carbon (Front)
9-5 Plug - Drain
9-8 Eye Bolt
11 Frame
12 Stator Assembly
13 Base Frame
14-1 Bush - Carbon (Rear)
15 Cable
15-1 Cable Gland
15-2 Cable Bush
16 Rear Cover
18-1 Thrust Ring - Front
18-3 Thrust Ring - Rear (Hylam)
18-4 Thrust Coupling - Front
18-5 Thrust Coupling Collar - Rear
18-6 Key - Thrust coupling
19 Shaft
19-7 Rotor
21 Winding Set
SPARE PARTS LIST :
ASMSP Series
Part Name
Quantity
Required
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1 / 2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
Material
Cast Iron
Stainless Steel
Cast Iron
Rubber
Cast Iron
Rubber
Cast Iron
Cast Iron / Stainless Steel
Stainless Steel
Extruded Brass
Cast Iron
Nylon GFN
Rubber
Carbon
Mild Steel
Forged Steel
Cast Iron
-
Mild Steel
Carbon
-
Extruded Brass
Rubber
Cast Iron
Stainless Steel
Hylam Fabric
Cast Iron with Carbon
Stainless Steel
Stainless Steel
Stainless Steel
Aluminium
PP Wire Set
