FOR INSTALLATION

1. The openwell submersible pump should be connected to a
single phase, 240 Volts, 50 cycles, AC supply through control
panel.
2. Ensure proper earthing is done at the ground level.
3. The monoblock is normally provided with sufficient length of
cable. If extra cable is to be used number of joints in the cable
should be as minimum as possible.
4. Wires and connections should be properly insulated, to avoid
fatal shocks.
5. Only recommended pipe size should be used. Small pipe size,
nipples, elbows, bends all give rise to head losses and should
either be eliminated or used sparingly.
6. Adequate supports should be provided to delivery pipe.
7. Care should be taken not to submerge the monoblock in clay
or loose soil at the bottom. In the above case, fix the monoblock
in proper frame and ensure that it is placed above the clay or
loose soil.
