  • Page 1 3 rack swiss made power...
  • Page 2 Este next3 ha sido diseñado, designed and manufactured fabricado, ensamblado y probado en nuestra fábrica en Suiza. Es elegible para una by studer in Switzerland extensión de garantía (10+5) con studentcare+.
  • Page 3: General Information

    Studer disclaims all responsibility and liability for damage, costs or losses resulting from an installation that does not comply with the instructions, a faulty operation or inadequate maintenance. The use of studer equipment is in any case under the responsibility of the customer.
  • Page 4: Mounting And Installation

    Mounting and installation Storage and content Fixing and dimensions 60°C 58 kg forced cooling to -20°C ensure the maximum power electronics performance 19" min. 130mm (3u) free for ventilation 175mm (4u) 350mm (8u) 72 kg 350mm (8u) Mounting place The next3 and the batteries should only be installed by qualified personnel. min.
  • Page 5: Battery Connection

    Wiring CAN BMS Communication Communication with Lithium studer nx communication bus batteries 2x RJ45 black cable: Connector included Check list nx interface RS485i multi-units Modbus communication connector included Auxiliary contacts 2 auxiliary contacts (outputs) Remote entries connectors included 16A 250Vac/24Vdc...
  • Page 6: Display System

    Communication and power up Display 1 nx interface required in the communication bus Display system on – AC source present and working CAN BMS RS 485i on – solar PV producing O = not connected T = connected on – AC flex (source) present and working on –...
  • Page 7 Configuring the next Multi units nx interface Up to 2x nx3 in parallel Con guration wizard 1 internal transfer, common battery 1 Remote control Devices connected to battery 1 nx3 1600-48 st Separate solar inputs 2 Devices Communicating battery 3 General Manufacturer name To be set Remote...
  • Page 8: Technical Data

    Technical data Maintenance and recycling Maintenance and recycling IP 30 inverter nx3 rack 16000-48 st Except for the periodic check of the connections (tightening, general Protection Continuous Power 15000 VA condition), the next does not require any particular maintenance. To Class I dispose of this product, please use the service for the collection of Power 30min...
  • Page 9 Serial Number : Installed by : Date : Signature : Call our specialists +41 27 205 60 80 or visit studer-innotec.com/support Studer Innotec SA rue des Casernes 57 1950 Sion, Switzerland info@studer-innotec.com © All rights reserved Studer Innnotec SA – V1.2...
