- Page 1 AUDIT-BUDDY Gen 2 User Manual “WIFI-BUDDY” August 2022 Questions: 1-774-261-4444 help@purkaylabs.com www.purkaylabs.com/support...
-
Page 2: Table Of Contents
WIFI-BUDDY User Manual About AUDIT-BUDDY Gen 2 - “WIFI-BUDDY” What is a WIFI-BUDDY/ AUDIT-BUDDY? How it Works What is a WI-FI Module? Wi-Fi Adapter Security Stand Placement Scan Modes Best Practices Factory Configured WIFI-BUDDY systems Manual Set Up of WI-FI Modules... - Page 3 WIFI-BUDDY User Manual About WIFI-BUDDY and WIFI-MATE Equipment Required: How to Configure WI-FI Modules WIFI-MATE Configuration Sequence WIFI-MATE Configuration Steps: How to Add Pre-Configured WI-FI Modules WIFI-MATE Sequence to Add Pre-Configured WI-FI Modules WIFI-MATE Add Pre-Configured WI-FI Module Steps: Start Scan Start Scan Overview Default Scan Settings How to Set Up a QuickScan using AUDIT-MATE W2.0...
- Page 4 WIFI-BUDDY User Manual QuickScan Dashboard Screen LongScan Dashboard Screens Read Delta-T Data Disclaimer: How to Export Screens www.purkaylabs.com Page 4...
-
Page 5: About Audit-Buddy Gen 2 - "Wifi-Buddy
PC. What is a WI-FI Module? A WI-FI Module consists of attaching Purkay Labs’ Wi-Fi adapter to the TH1 Module. You can remove the wireless connection by disconnecting the Wi-Fi adapter. Wi-Fi Adapter Security The Wi-Fi Adapter uses: ●... -
Page 6: Stand Placement
WIFI-BUDDY User Manual Stand Placement IMPORTANT: Let AUDIT-BUDDY system acclimate for at least 10 minutes before starting scan The Carbon fiber rod base is designed to be placed as close as 1” away from the server front. Position the Carbon fiber rod as that the TH1 Module fan is pointed closest to the server intake. -
Page 7: Factory Configured Wifi-Buddy Systems
Steps: 1. Place TH1 Module flat with LED screen facing down 2. Using the two holes on the TH1 rear as guide, place the Adapter so that the Adapter slots in over the TH1 Purkay Labs label. www.purkaylabs.com Page 7... -
Page 8: Connection Tips
WIFI-BUDDY User Manual 3. Connect rod clamp to the TH1 and Adapter combo using the provided 1 inch screw 4. Connect the Wi-Fi Adapter to TH1 Module using USB Cable a. Wi-Fi Adapter (USB 2.0 A-Male) to the TH1 Module (USB 2.0 B-Male) b. -
Page 9: Scenario 1: The Green Led Light Does Not Repeatedly Appear
Scenario 1: The Green LED Light does not Repeatedly Appear If the Green LED still does not come on after multiple attempts, the factory stored configuration within the adapter has been lost. Please contact Purkay Labs for assistance. WI-FI Adapter Battery Always check battery strength before scanning as the wi-fi set-up consumes a lot of battery. -
Page 10: Steps
1. Download Program to Computer 2. Register the Program 3. Enter in Product Key a. Please contact Purkay Labs if you do not have the product key. You will need to have the Product Number Available 4. Program has been installed successfully... -
Page 11: How To Change Pc Ip Settings To Static Ip
Can I connect to my Facility Network? Yes, you can connect to the Facility Network using a Dynamic IP Configuration. Please note that Purkay Labs recommends using the Static IP configuration. To use the Dynamic IP Configuration, you need: Security and IT Clearance... -
Page 12: How To Set-Up Wifi-Buddy Using The Wifi-Mate Program
WIFI-BUDDY User Manual How to Set-Up WIFI-BUDDY using the WIFI-MATE program About WIFI-BUDDY and WIFI-MATE Use the WIFI-MATE program to configure, stream and read data from the WIFI-BUDDY. Equipment Required: ● 3 TH1 Module(s) ● 3 WI-FI Adapters ● USB cable ●... -
Page 13: How To Add Pre-Configured Wi-Fi Modules
WIFI-BUDDY User Manual 6. To connect more Modules: connect USB Cable, press “identify” button and disconnect. 7. Validate Module Position (Top, Middle, Bottom) 8. Activate Stand 9. Select Scan Mode and go The WI-FI Modules are now configured to the PC and Network. Users will only have to do this process once. -
Page 14: Start Scan
WIFI-BUDDY User Manual Start Scan For clients who have purchased configured hardware, they have to follow the following steps 1. First assemble the Adapter/TH1 module per instructions. 2. Insert battery in adapter if required 3. Turn on the Router 4. Press the power button on the Adapter and make sure the green LED turns on and goes off. -
Page 15: How To Set Up A Quickscan Using Audit-Mate W2.0
WIFI-BUDDY User Manual Sample Run Time (Number of (User Defined) (User Defined) Samples) Scan Start Time Immediately Immediately Immediately Scan Will Stop: (Number of (Scan Run Time) (Scan Run Time) Samples) How to Set Up a QuickScan using AUDIT-MATE W2.0 About QuickScan Mode You can learn more about the QuickScan mode here. -
Page 16: Option 2: Customize Quickscan Settings
WIFI-BUDDY User Manual The following settings will be uploaded to the AUDIT-BUDDY TH1 Modules. Default Settings QuickScan Sample Rate 20 Seconds Wait Time 30 Seconds Sample Run Time (Number of Samples) Scan Start Time Immediately Scan Will Stop: (Number of Samples) Option 2: Customize QuickScan Settings If users select the Blue >... -
Page 17: How To Create A Static Heat Map
WIFI-BUDDY User Manual Scan Start Choose to start collecting immediately or set a delayed start time. Scan Stop Time This is when the scan will likely stop based on the number of samples selected. Scan Direction When facing the scan location, are you starting from the Right or Left of the area? Off/Set from Zero This Is the distance from the edge of your starting... -
Page 18: How To Assign Rack Names
WIFI-BUDDY User Manual Module Positions What are the heights of the Stand Settings Page three TH1 Modules on the Carbon Fiber Rod. Scan Direction When facing the scan QuickScan Settings Page location, are you starting from the Right or Left of the area? Off/Set from Zero Is the distance from the... -
Page 19: How To Set Up A Longscan Using Audit-Mate
WIFI-BUDDY User Manual Tile Location AA1, AB2, AB3 Uses Tile Locations How to Set Up a LongScan using AUDIT-MATE LongScan Set Up Sequence About the Express LongScan Page This screen allows users to select default LongScan settings. On this page, users can select: ●... -
Page 20: Customize Longscan Settings
WIFI-BUDDY User Manual Sample Rate 1 Minute Wait Time Sample Run Time (User Defined) Scan Start Time Immediately Scan Will Stop: (Scan Run Time) Customize LongScan Settings If users select the Blue > button, they will be able to customize the LongScan settings. Users will be able to set: Test Name This will be used to identify this scan and used in the File... -
Page 21: How To Create A Time-Trend Graph
WIFI-BUDDY User Manual How to Create a Time-Trend Graph The time-trend graph shows how the data collect changes over time. The time-trend graph will automatically be generated after a LongScan or Delta-T collection. How to Set Up a Delta-T Scan using AUDIT-MATE Please note that you must use two stands to conduct a Delta-T scan. -
Page 22: Customize Delta-T Settings
WIFI-BUDDY User Manual Delta-T Sample Rate 1 Minute Wait Time Sample Run Time (User Defined) Scan Start Time Immediately Scan Will Stop: (Scan Run Time) Customize Delta-T Settings If users select the Blue > button, they will be able to customize the DeltaT Scan settings. -
Page 23: Download Data
WIFI-BUDDY User Manual Scan Start Choose to start collecting immediately or set a delayed start time. Scan Stop Time This is when the scan will likely stop based on the number of samples selected. CRAC Settings If more than one CRAC unit, use this page to enter in the different CRAC Settings. - Page 24 Purkay Labs cannot be held liable for changes made by users interpreting the metrics results. The tool is designed to illustrate an indicative data hall air performance and should not be reproduced externally for commercial purposes without www.purkaylabs.com...
- Page 25 WIFI-BUDDY User Manual the permission of Purkay Labs. For assistance using the tool, interpreting the results and implementing improvements please contact info@purkaylabs.com Delta-T Dashboard Screens Dashboard See an overview of the Delta-T Scan, quick Analysis of Cooling Performance, the Cost Impact, Required CFM and PUE...
- Page 26 WIFI-BUDDY User Manual How to Export Screens Go to Drop down section and select file to select export options. There are two export options: 1. Export Single Screen Shot - available at every screen at all times 2. Export All Parameters - Available after a scan is complete. This function exports a series of scans pertaining to a particular screen.
