AV Receiver
HT-R320
Instruction Manual
Thank you for purchasing an Onkyo AV Receiver.
Please read this manual thoroughly before making
connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new AV Receiver. Please retain
this manual for future reference.
Contents
Before using
Important Safety Instructions ........................... 2
Precautions ........................................................ 3
Features ............................................................. 4
Supplied accessories ......................................... 4
Before Using the HT-R320 .............................. 5

Facilities and connections

Index to parts and controls ............................... 6
Connecting to audio/video equipment ........... 10
Positioning speakers/Connecting speakers .... 12
Connecting antennas ....................................... 14
Connections for remote control (
Enjoying music or videos
Enjoying music or videos with the
HT-R320 ....................................................... 17
Speaker setup .................................................. 18
Changing the default settings according
to your connections ...................................... 21
Listening to the radio ...................................... 22
Various functions common to all the sources .. 24
Enjoying multi channel sources ..................... 27
Enjoying the listening modes ......................... 28
Audio adjust function ..................................... 30
Recording a source ......................................... 32

Remote controller

Using the remote controller with your other
AV components ............................................ 33
Appendix
Troubleshooting .............................................. 35
Specifications ................................................. 37
) ............. 16
E
n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT-S570 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Onkyo HT-S570

Summary of Contents for Onkyo HT-S570

  • Page 1: Facilities And Connections

    AV Receiver HT-R320 Instruction Manual Thank you for purchasing an Onkyo AV Receiver. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new AV Receiver.

  • Page 2: Important Safety Instructions

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING QUALIFIED PERSONNEL.
  • Page 3 2. AC Fuse—The AC fuse inside the HT-R320 is not user- serviceable. If you cannot turn on the HT-R320, contact your Onkyo dealer. 3. Care—Occasionally you should dust the HT-R320 all over with a soft cloth. For stubborn stains, use a soft cloth dampened with a weak solution of mild detergent and water.

  • Page 4: Supplied Accessories

    Features Amplifier Features × • 5 100 W/Channel @ 8Ω, 20–20 kHz, 0.08% THD • WRAT-Wide Range Amplifier Technology • Optimum Gain Volume Circuitry • DTS, Dolby Digital, Dolby Pro Logic II • CinemaFILTER • Non-Scaling Configuration • A-Form–Auto Format Sensing •...

  • Page 5: Before Using The Ht-R320

    Before Using the HT-R320 Installing the Batteries 1 Open the battery compartment, as shown. 2 Insert the two supplied batteries (AA/R6) in accordance with the polarity diagram inside the battery compartment. 3 Close the battery compartment. Notes • The supplied batteries should last for about six months, although this will vary with usage.

  • Page 6: Index To Parts And Controls

    LISTENING MODE buttons [27, 29] Press these buttons to select a listening mode for the current source. Press the DSP button to recall the Onkyo-original DSP modes in sequence. Press the DIRECT, STEREO or SURROUND button to recall the corresponding listening mode directly.
  • Page 7 Index to parts and controls Display DISPLAY button [25] Each time you press the DISPLAY button, the display changes. AUDIO SELECTOR button [26, 27] Press to select an audio input signal format other than FM and AM. Each time this button is pressed, the setting cycles. Input selector buttons (DVD, VIDEO 1, VIDEO 2, VIDEO 3, TAPE, TUNER, and CD) [17, 21-23, 26, 27, 32]...
  • Page 8 Rear panel For operational instructions, refer to the page indicated in brackets. REMOTE CONTROL [16] Connect the Onkyo components that have CD player, and cassette tape deck using the with them. When these components are interconnected, they can be controlled from the remote controller provided with the HT-R320.
  • Page 9 Index to parts and controls Remote controller RC-479S Explanations on this page are for controlling the HT-R320. To operate other components, see “Using the remote controller with your other AV components” on pages 33 through 34. For operational instructions, refer to the page indicated in brackets. SLEEP button [25] For setting the sleep time.

  • Page 10: Connecting To Audio/Video Equipment

    Connecting to audio/video equipment Before connecting • Be sure to always refer to the instruction manual that came with the component that you are connecting. • Do not plug in the power cord until all connections have been made. • For input jacks, red connectors are used for the right channel, white connectors are used for the left channel, and yellow connectors are used for video connection.
  • Page 11 Connecting to audio/video equipment Video Camera, DVD player or component Game Device, etc. with 5.1 ch output (DVD)* (VIDEO 3) AUDIO VIDEO DIGITAL VIDEO FRONT COAXIAL ANTENNA To connect the digital output from satellite tuner etc. connected to the VIDEO 1, VIDEO 2 or VIDEO 3 jacks to the COAXIAL or OPTICAL input jack of this unit, it is...

  • Page 12: Positioning Speakers/Connecting Speakers

    Positioning speakers/Connecting speakers Two speaker systems can be connected to the Receiver. The speaker system A is to be placed in the main room, and the speaker system B is to be placed in a second room. The speaker system A consists of the FRONT SPEAKERS A (L/R), CENTER SPEAKER, SURROUND SPEAKERS (L/R) and SUBWOOFER.
  • Page 13 Positioning speakers/Connecting speakers Before connecting • Refer also to the instruction manuals of the speakers. • Be sure to connect the positive and negative cables for the speakers properly. If they are mixed up, the left and right signals will be reversed and the audio will sound unnatural. •...

  • Page 14: Connecting Antennas

    Connecting antennas Connecting the supplied FM and AM indoor antennas ANTENNA USA, Canada, Mexico Strip away the insulation from the end of the cord. Fully insert the stripped end of the cord. Adjusting the position of the FM indoor antenna The FM indoor antenna is for indoor use only.
  • Page 15 Connecting antennas Connecting an Outdoor FM Antenna If you cannot achieve good reception with the supplied indoor FM antenna, try a commercially available outdoor FM antenna instead. Notes • Outdoor FM antennas work best outside, but usable results can sometimes be obtained when installed in an attic or loft. •...

  • Page 16: Connections For Remote Control ( )

    HT-R320. The other one can be used to daisy chain with another component. • With Onkyo DVD players, you can enter the manufacturer code so that you can operate the DVD player directly with the remote controller without connecting the •...

  • Page 17: Enjoying Music Or Videos With The Ht-R320

    Enjoying music or videos with the HT-R320 Before connecting • Make sure that all the connections from pages 10 to 16 are complete. • Turning on the AV Receiver may cause a momentary power surge, which might interfere with other electrical equipment such as computers.

  • Page 18: Speaker Setup

    (front, center and surround). repeatedly to Home theater in a box It is not neccessary to change this setting when using the supplied speaker system. Front right If you’re not using a subwoofer, bass sounds are output by the other...
  • Page 19 Speaker setup Specifying speaker distances To get the best from surround sound, it’s important that the sound from each speaker reaches the listener at the same time. To achieve this, you need to specify the distance from each speaker to the listening position.

  • Page 20: Setting The Subwoofer Mode

    Speaker setup SUBWOOFER MODE Setting the subwoofer mode Press SUBWOOFER MODE on the unit. With the first press of the button, you can check the present setting. Then each press of the button changes the subwoofer mode as follows (a tip on how to select the right subwoofer mode is in parenthesis): →...

  • Page 21: Changing The Default Settings According To Your Connections

    Changing the default settings according to your connections If equipment couldn’t be connected in accordance with the default settings, or your preferred settings differ from the default settings, you can change the settings as described below. Switch the source from TAPE to MD You can set the AV receiver to show “MD”...

  • Page 22: Listening To The Radio

    Listening to the radio There are two ways to select radio stations: • Manual tuning • Presetting radio stations then selecting the preset channels Tuning into a radio station 1. Press TUNER. The selected band appears in the display. Each time you press the button, the band changes as follows: AM ↔...
  • Page 23 Listening to the radio FM MODE MEMORY TUNER Presetting radio stations You can preset up to 30 stations. 1. Tune in the radio station you wish to preset (refer to the previous page). 2. Press MEMORY. The MEMORY indicator lights and the preset number starts flashing in the display.

  • Page 24: Various Functions Common To All The Sources

    Various functions common to all the sources SPEAKERS A/B PHONES jack Turning on/off the speaker system A/B You can turn on or off the speaker systems connected to the speaker system A and speaker system B connectors individually. Before operating the remote controller, press RCVR/TAPE. Press SPEAKER A on the unit or SP A on the remote controller to turn on or off the speaker system A.
  • Page 25 Various functions common to all the sources DISPLAY DIMMER Changing the display Press DISPLAY. Each time you press DISPLAY, the screen changes as follows: When an input source other than FM or AM is selected Input source + volume Program format* Input source + Listening mode (or Multich)
  • Page 26 Various functions common to all the sources AUDIO SELECTOR Adjusting each speaker’s relative volume balance temporarily You can readjust each speaker’s relative volume balance according to your preference while listening to the sound. The adjusted values will return to the values set on page 20 when the AV Receiver enters standby mode unless you save the values.

  • Page 27: Enjoying Multi Channel Sources

    Enjoying multi channel sources SURROUND AUDIO SELECTOR TAPE Using analog multi channel input The multi channel input refers to a system, which is compatible with a source component equipped with analog 5.1-channel outputs (DVD player, MPEG decoder, etc.), reproducing the left/right front, center and left/right surround channels from five respective speakers and outputting the subwoofer channel from SUB WOOFER (refer to page 13).

  • Page 28: Enjoying The Listening Modes

    The PCM (Pulse Code Modulation) signal is a kind of digital audio signal, which is recorded directly on CD or DVD without being compressed. When an analog or PCM source is played, you can enjoy unique surround modes to Onkyo as listed below. Orchestra This mode is suitable for classical and opera music.
  • Page 29 DTS). A.STEREO button: Set the listening mode to “All Ch St”. DSP button on the front panel: Recall the Onkyo-original DSP mode. Each time this button is pressed, the listening mode cycles; “Orchestra” → “Unplugged” → “Studio Mix” → “TV Logic” →...

  • Page 30: Audio Adjust Function

    Audio adjust function PRESET/ADJUST Using the audio adjust functions Before operating the remote controller, press RCVR/TAPE. These functions only work with speaker system A. Audio Adjust provides various functions for adjusting the sound, including several especially for use with Dolby Digital, DTS, and Pro Logic II source.
  • Page 31 Audio adjust function The Audio Adjust functions are explained below. Bass With this function you can boost or cut low-frequency sounds output by the front speakers from –12 dB to +12 dB in 2 dB steps. Treble With this function you can boost or cut high-frequency sounds output by the front speakers from –12 dB to +12 dB in 2 dB steps.

  • Page 32: Recording A Source

    Recording a source To record the input source signal you are currently watching or listening to Recording of video and/or audio signals can be performed on the components connected to the VIDEO 1 OUT and TAPE OUT (audio only) jacks. Input selector buttons 1.

  • Page 33: Using The Remote Controller With Your Other Av Components

    Using the remote controller with your other AV components Connecting your Onkyo CD player, Onkyo DVD player, or Onkyo cassette recorder to the HT-R320’s connector allows you to control it with the HT-R320’s remote controller. Since you only need to point the remote controller at the HT-R320, you can control components that are out of sight, for example, in a cabinet.

  • Page 34: Using The Remote Controller With Your Other Av Components

    Using the remote controller with your other AV components CD mode operation buttons CD input selector Power On/Off. Starts playback of CD. Stops playback, fast forward or fast reverse. Fast forwards of CD. Fast reverses of CD. L e t s p l a y b a c k p a u s e temporarily.

  • Page 35: Troubleshooting

    Remedies • Check the connection of the power cord. • Disconnect the power cord, then connect it again. • Contact your Onkyo Service Center. • Disconnect the power cord, then connect it again. • Deactivate the muting function. • Check the connections to the AV receiver.
  • Page 36 Troubleshooting Symptoms Causes Too much noise is heard or • FM stereo waves may produce a hiss sound is interrupted noise when a certain level is reached. occasionally. (The FM • The position or direction of the FM STEREO indicator does not antenna is incorrect.

  • Page 37: Specifications

    Specifications Amplifier Section Power Output: Front L/R: 100 W + 100 W Center 100 W Surround L/R 100 W + 100 W (8 Ω, 20 Hz~20 kHz, FTC) 230 W + 230 W (3 Ω, Front) Dynamic Power: 170 W + 170 W (4 Ω, Front) 115 W + 115 W (8 Ω, Front) (Total Harmonic Distortion): 0.08 % (Power Rated)
  • Page 38 Memo...
  • Page 39 UNITED KINGDOM Tel: +44-(0)1494-681515 Fax: +44(0)-1494-680452 ONKYO CHINA LIMITED Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung, N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039 SN 29343901 (C) Copyright 2004 ONKYO CORPORATION Japan. All rights reserved. HOMEPAGE http://www.onkyo.com/ Printed in Japan D0407-1...

  • Page 40: Table Of Contents

    CENTER SPEAKER SKM-320S SURROUND SPEAKER Instruction Manual Thank you for purchasing an Onkyo home theater speaker package. Please read this manual thoroughly before using your new speakers. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your speaker package.

  • Page 41: Important Safeguards

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

  • Page 42: Precautions

    22. Heat – The appliance should be situated away from heat sources such as radiators, heat registers, stoves, Package Contents Make sure your box contains all of the items below. If anything is missing, contact the nearest Onkyo dealer. • Front speakers (SKF-320F) • Center speaker (SKC-320C) •...

  • Page 43: Getting To Know Your Speaker Package

    Getting to Know Your Speaker Package Subwoofer (SKW-320X) I Rear STANDBY/ON indicator Red: Subwoofer in standby mode Green: Subwoofer on With the Auto Standby function, the SKW-320X automatically turns on when an input signal is detected in Standby mode. When there’s no input signal for a while, the SKW-320X automatically enters Standby mode. OUTPUT LEVEL control This control is used to adjust the volume of the subwoofer.

  • Page 44: Enjoying Home Theater

    Front left and right speakers These output the overall sound. Their role in a home theater is to provide a solid anchor for the sound image. They should be positioned facing the listener at about ear level, and equi- distant from the TV.

  • Page 45: Connecting The Speaker Cables

    Connecting the Speakers Read the following before connecting your speakers: • Turn off your amp before making any connections. • Pay close attention to speaker wiring polarity. Connect positive (+) terminals to only positive (+) terminals, and negative (–) terminals to only negative (–) termi- nals.

  • Page 46: Caring For Your Speakers

    Caring for Your Speakers Placement • The speaker cabinets are made out of wood and are therefore sensitive to extreme temperatures and humidity, do not put them in locations subject to direct sunlight or in humid places, such as near an air condi- tioner, humidifier, bathroom, or kitchen.

  • Page 47: Specifications

    ONKYO CHINA LIMITED Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung, N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039 SN 29343900 (C) Copyright 2004 ONKYO CORPORATION Japan. All rights reserved. I Center Speaker (SKC-320C) Type: Impedance: Maximum input power:...
