Summary of Contents for Storex SlimBox
- Page 1 QUICK INSTALLATION GUIDE SlimBox Page 1/24...
- Page 2 SlimBox Page 2/24...
- Page 3 Unplug the product from the wall socket before cleaning it, Clean the product's surface as well as the remote control with a soft and dry cloth. Never use rough materials, scourer powder or solvents such as alcohol or spirits. SlimBox Page 3/24...
- Page 4 Plasma screen televisions and projector screens are particularly sensitive. SAFETY – ENVIRONMENT Your STOREX product has been laboratory tested; it complies to European guidelines corresponding to the CE labelling in force at the time of its launch. Your STOREX product's components are tracable; this demonstrates the product's compliance to environmental guidelines (RoHS) in force at the time of its launch.
-
Page 5: Table Of Contents
REAR PANEL ..........................7 SIDE ............................7 REMOTE CONTROL DETAILS ...................... 8 CONNECTING THE "SLIMBOX" GATEWAY TO THE TV ..............10 CONNECTING A PERIPHERAL TO YOUR "SLIMBOX" ................11 READING A FILE ........................12 READING FROM A MEMORY CARD .................... 13 SHORTCUT BAR ........................ -
Page 6: Introduction
INTRODUCTION Your "SlimBox" is a multimedia gateway allowing you to watch photos and videos in high definition, or listen to music. OPERATION - Once connected to the TV, you can watch multimedia files from your USB peripheral or SD/MMC memory card in high definition on your "SlimBox". -
Page 7: Product Details
4. COAXIAL: To connect a coaxial cable (from your SlimBox to your audio amplifier). 5. AV TV: To connect your SlimBox to your TV using the provided AV cable. 6. HDMI: To connect a HDMI cable (from your SlimBox to your TV). -
Page 8: Remote Control Details
REMOTE CONTROL DETAILS REAL REMOTE CONTROL KEYPAD NUMBERING SlimBox Page 8/24... - Page 9 TOUCHE FONCTION TASKBAR Allows the user to call the shortcut bar while viewing a file. STANDBY Turning the SlimBox on/off MUTE Allows the user to activate/deactivate the sound. DIRECTIONNAL Allows the user to browse between the different files and folders.
-
Page 10: Connecting The "Slimbox" Gateway To The Tv
(AV1, AV2, EXT1, EXT2…) once connected to the TV. 3. Connect the power adaptor to the "SlimBox" and switch the commuter (under the product) to 4. Press the "Standby" key on your remote control. -
Page 11: Connecting A Peripheral To Your "Slimbox
CONNECTING A PERIPHERAL TO YOUR "SLIMBOX" The "SlimBox" gateway is equipped with "USB Host" ports allowing the user to connect a USB stick or a USB hard drive directly to the "SlimBox", to browse it and read the multimedia content stored in it. -
Page 12: Reading A File
3. Press the " " key to show the following shortcut bar: You will be shown the following shortcuts in respective order: 1. Previous 2. Pause 3. Rotation 4. Zoom 5. Background music 6. Photo display 7. Next SlimBox Page 12/24... -
Page 13: Reading From A Memory Card
" key to change your reading peripheral. Each time you press the key the reading peripheral will change and be displayed in blue. 3. Select the directories and files with the directional pad and confirm the selection by pressing “ENTER”. SlimBox Page 13/24... -
Page 14: Shortcut Bar
6. Zoom 7. Fast Forward 8. Next 2. MUSIC 1. Previous 2. Rewind 3. Play/Pause 4. Stop 5. Sequential or random play 6. Repeat all, repeat directory or repeat one. 7. Fast Forward 8. Next SlimBox Page 14/24... -
Page 15: Slimbox" Settings
Press the " " key to hide the shortcut bar. "SLIMBOX" SETTINGS On this page you can perform several adjustments, including the language and the display resolution. 1. Press the “SETUP” key on the remote control to enter the settings menu. -
Page 16: Wireless Network (Wifi)
Wireless network (WIFI) 1. The WIFI is optional for the "SlimBox", please contact your retailer or refer to the http://www.e-storex.com website to purchase a compatible WiFi key. 2. Connect the USB WiFi key (optional) to one of the USB HOST ports. - Page 17 5. Select your WiFi network and press "ENTER" 6. Enter your key according to safety settings (WEP in this example) with the virtual digital number pad. Press "ENTER" to confirm. 7. Once you have entered your key, select "CONFIRM" and press "ENTER". SlimBox Page 17/24...
- Page 18 NOTE We recommend setting up the network after properly connecting the USB WiFi stick to the SlimBox. Please ensure that the antivirus or firewall aren't blocking this unit's access to the network. You may experience a temporary cut and a freeze of the AV content via the WiFi network due to the network speed, the input capacity or AV files including HD files.
-
Page 19: Terms Of Guarantee
TERMS OF GUARANTEE STOREX's available guarantee is valid for 1 year for the "S limBox " gateway and 3 months for its accessories (remote control, AV cables, power supply…). STOREX guarantees your product against any manufacturing or assembling faults. This guarantee applies to the first hand purchase of a "S limBox "... -
Page 20: Storex Website
STOREX WEBSITE You will find a SUPPORT section associated with each STOREX product on STOREX's website. Log on to http://www.storex.eu. Select "Multimedia Gateway" and "S limBox ". You will be able to download the latest complete version of the manual, software updates, and refer to the frequently asked questions section. Before contacting our technical support team or our after-sales service, please check the "Forum"... - Page 21 Remote handling "Hello, I can't install my external hard drive" Using the STORwebEX platform allows the Hotline technicians to connect remotely to the customer's computer, in order to resolve installation issues pertaining to a STOREX product. SlimBox Page 21/24...
- Page 22 SlimBox Page 22/24...
- Page 23 SlimBox Page 23/24...
- Page 24 SlimBox Is part of the product range manufactured by www.storex.eu © STOREX –2010 All mentioned brand names are patented by their respective owners. SlimBox Page 24/24...
